Frigidaire FRS23W3A Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS23W3A:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRS23W3AQ9
FRS23W3A
FRS23W3AW9
FRS23W3A
MARKET
North America
WIRING DIAGRAM - 240389612
OWNER'S GUIDE - 240389311
SERVICE DATA SHEET - 240389612
ELECTROLUX HOME PRODUCTS, INC
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a
bisque
R134a
white
Publication No.
5995394656
030825
-EN/SERVICE/DCS
357
PARTS CATALO
VOLTS
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS23W3A
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
G

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRS23W3A

Summary of Contents for Frigidaire FRS23W3A

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS23W3AQ9 FRS23W3A R134a bisque FRS23W3AW9 FRS23W3A R134a white MARKET North America WIRING DIAGRAM - 240389612 OWNER’S GUIDE - 240389311 SERVICE DATA SHEET - 240389612 SIDE BY SIDE REFRIGERATOR ELECTROLUX HOME PRODUCTS, INC Model No.

  • Page 2: Freezer Door

    Publication No. FRS23W3A 5995394656 FREEZER DOOR 08/03...
  • Page 3 FRS23W3A Publication No. 5995394656 FREEZER DOOR A = FRS23W3A (FRS23W3AQ9) B = FRS23W3A (FRS23W3AW9) POS. NO PART NO DESCRIPTION 240390604 Gasket-frzr door, white 240367301 Bin-door, frzr-upper 240359001 Bin-door 240451822 Door-frzr, bisque, complete assy 240451818 Door-frzr, white, complete assy 240537104 Door Stop, bisque, frzr 240537102 Door Stop, white, frzr 218762706...

  • Page 4: Refrigerator Door

    Publication No. FRS23W3A 5995394656 REFRIGERATOR DOOR 08/03...
  • Page 5 FRS23W3A Publication No. 5995394656 REFRIGERATOR DOOR A = FRS23W3A (FRS23W3AQ9) B = FRS23W3A (FRS23W3AW9) POS. NO PART NO DESCRIPTION 240390603 Gasket-refr door, white, magnetic 240363701 Bin-door, 2-liter 240338303 Door, dairy, clear 240537103 Door Stop, bisque, ref 240537101 Door Stop, white, ref 240451915 Door-refr, bisque, complete assy 240451911...
  • Page 6 Publication No. FRS23W3A 5995394656 CABINET 08/03...
  • Page 7 FRS23W3A Publication No. 5995394656 CABINET A = FRS23W3A (FRS23W3AQ9) B = FRS23W3A (FRS23W3AW9) POS. NO PART NO DESCRIPTION 240435901 Cover-air duct 240475901 Cover-evap coil,lower 5303208309 Plug-hole,factory test 14 # 240505801 Switch,light/lamp 14A# 215486600 Switch-light/lamp 218252200 Screw,#8 truss hd ,10-32CA x 0.500 240457701 Plate-door closer 240402701...
  • Page 8 Publication No. FRS23W3A 5995394656 SHELVES 08/03...
  • Page 9 FRS23W3A Publication No. 5995394656 SHELVES A = FRS23W3A (FRS23W3AQ9) B = FRS23W3A (FRS23W3AW9) POS. NO PART NO DESCRIPTION 240434603 Trim-basket 240338801 Shelf-freezer,flip-up 240338701 Shelf-freezer,fixed wire 240338703 Shelf-freezer,fixed wire 240373107 Frame-refr shelf,cantilever 240354502 Cover-crisper pan,upper 240354602 Cover-crisper pan,lower 240354706 Pan-crisper,upper 240354806 Pan-crisper,lower 240357705 Trim-shelf,front...
  • Page 10 Publication No. FRS23W3A 5995394656 CONTROLS 08/03...
  • Page 11 FRS23W3A Publication No. 5995394656 CONTROLS A = FRS23W3A (FRS23W3AQ9) B = FRS23W3A (FRS23W3AW9) POS. NO PART NO DESCRIPTION 5308000010 Fan Blade, red, evaporator fan 5300157666 Bushing-motor mtg, (2) 5303292396 Bracket-motor mtg, front 13 # 240315803 Motor-evap fan 215474201 Washer,"slinger" ,nylon ,evap fan shaft 5303292397 Bracket-motor mtg,rear 240436702...
  • Page 12 Publication No. FRS23W3A 5995394656 SYSTEM 08/03...
  • Page 13 FRS23W3A Publication No. 5995394656 SYSTEM A = FRS23W3A (FRS23W3AQ9) B = FRS23W3A (FRS23W3AW9) POS. NO PART NO DESCRIPTION 240333602 Condenser 218679606 Block-evap coil, styrofoam, (2) 218944001 Drier-filter, R134a System 240346402 Harness-wiring, machine compt 240449601 Harness-wiring 241508102 Harness-wiring, control box 14 # 5303918253 Defrost Heater Kit 15 #...
  • Page 14 Publication No. FRS23W3A 5995394656 DISPENSER 08/03...
  • Page 15 FRS23W3A Publication No. 5995394656 DISPENSER A = FRS23W3A (FRS23W3AQ9) B = FRS23W3A (FRS23W3AW9) POS. NO PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 5304429705 Cover-module, bisque 5304428805 Cover-module, white 5304422144 Module-dispenser, bisque 5304421823 Module-dispenser, white 5304426649 Spring-torsion 240323909...

  • Page 16: Ice Container

    Publication No. FRS23W3A 5995394656 ICE CONTAINER 08/03...
  • Page 17 FRS23W3A Publication No. 5995394656 ICE CONTAINER A = FRS23W3A (FRS23W3AQ9) B = FRS23W3A (FRS23W3AW9) POS. NO PART NO DESCRIPTION 5304428402 Auger-ice 5304404343 Cam-drive 218815300 Container-ice,bucket only 5304404346 Drum-ice disp 218815400 Front-ice container 5304404337 Bar-drive 5304404359 Gate 5303001179 Light Bulb/Lamp,40 W 5303289050 Socket-light/lamp 5304404345...

  • Page 18: Ice Maker

    Publication No. FRS23W3A 5995394656 ICE MAKER 08/03...
  • Page 19 FRS23W3A Publication No. 5995394656 ICE MAKER A = FRS23W3A (FRS23W3AQ9) B = FRS23W3A (FRS23W3AW9) POS. NO PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 240561701 Seal-water inlet, inlet valve to ice maker 5304420650 Spring,shut-off arm 3206299 Label,ID plate 3206301...

  • Page 20: Wiring Schematic

    Publication No. FRS23W3A 5995394656 WIRING SCHEMATIC 08/03...

  • Page 21: Wiring Diagram

    FRS23W3A Publication No. 5995394656 WIRING DIAGRAM # = Fast-moving Parts 08/03 * = Non-Illustrated Parts...
