Frigidaire FRS23KF5C Factory Parts Catalog
Side-by-side
refrigerator
Hide thumbs
Also See for FRS23KF5C:
- Factory parts catalog (21 pages) ,
- Factory parts catalog (22 pages) ,
- Factory parts catalog (24 pages)
Table of Contents
Advertisement
Quick Links
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet 240389616
N58L00001.eps N58FCCBBB2.eps N58RCCBBB9.eps N58BAAAAA0.eps
N58SACAAD11.eps N58TAAAAB3.eps N58CAAAAA4.eps N58XDAAAA1.eps
N58YBAAAA1.eps N58I115.eps W241526901A.eps S241526901A.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
FRS23KF5CB5 FRS23KF5CQ5 FRS23KF5CS2 FRS23KF5CW5
R134a
R134a
R134a
black
bisque
stain/blk
115
115
115
241526901
241526901
241526901
240581300
240581300
240581300
North America North America
North America North America
240572166
240572166
240598633
240389616
240389616
Publication No.
5995414116
04/08/02
(EN/SERVICE/DCS)
357
R134a
white
115
241526901
240581300
240572166
240389616
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS23KF5C
©
Copyright
All rights reserved.
Advertisement
Table of Contents
Related Manuals for Frigidaire FRS23KF5C
Summary of Contents for Frigidaire FRS23KF5C
- Page 1 Product No. FRS23KF5CB5 FRS23KF5CQ5 FRS23KF5CS2 FRS23KF5CW5 Series R134a R134a R134a R134a Color black bisque stain/blk white Volts Wiring Diagram 241526901 241526901 241526901 241526901 Owner's Guide 240581300 240581300 240581300 240581300 Market North America North America North America North America Energy Guide 240572166 240572166 240598633...
-
Page 2: Freezer Door
Publication No: 5995414116 FRS23KF5C FREEZER DOOR N58FCCBBB2 08/04... - Page 3 FRS23KF5C Publication No: 5995414116 FREEZER DOOR Model Index: A FRS23KF5C (FRS23KF5CB5) B FRS23KF5C (FRS23KF5CQ5) C FRS23KF5C (FRS23KF5CS2) D FRS23KF5C (FRS23KF5CW5) POS. NO PART NO. DESCRIPTION 241569808 A - C - Gasket-frzr door, black, magnetic 241569804 - B - D Gasket-frzr door, white, magnetic 240367301 A B C D Bin-door, frzr-upper...
-
Page 4: Refrigerator Door
Publication No: 5995414116 FRS23KF5C REFRIGERATOR DOOR 08/04... - Page 5 FRS23KF5C Publication No: 5995414116 REFRIGERATOR DOOR Model Index: A FRS23KF5C (FRS23KF5CB5) B FRS23KF5C (FRS23KF5CQ5) C FRS23KF5C (FRS23KF5CS2) D FRS23KF5C (FRS23KF5CW5) POS. NO PART NO. DESCRIPTION 241569807 A - C - Gasket, refr door seal, black, magnetic 241569803 - B - D Gasket-refr door, white, magnetic 240363701 A B C D...
- Page 6 Publication No: 5995414116 FRS23KF5C CABINET 08/04...
- Page 7 FRS23KF5C Publication No: 5995414116 CABINET Model Index: A FRS23KF5C (FRS23KF5CB5) B FRS23KF5C (FRS23KF5CQ5) C FRS23KF5C (FRS23KF5CS2) D FRS23KF5C (FRS23KF5CW5) POS. NO PART NO. DESCRIPTION 240435905 A B C D Cover-air duct 240475906 A B C D Cover-evap coil, lower 5303208309 A B C D Plug-hole, factory test 14 #...
- Page 8 Publication No: 5995414116 FRS23KF5C SHELVES N58SACAAD11 08/04...
- Page 9 FRS23KF5C Publication No: 5995414116 SHELVES Model Index: A FRS23KF5C (FRS23KF5CB5) B FRS23KF5C (FRS23KF5CQ5) C FRS23KF5C (FRS23KF5CS2) D FRS23KF5C (FRS23KF5CW5) POS. NO PART NO. DESCRIPTION 241510603 A B C D Trim-basket 240338801 A B C D Shelf-freezer, flip-up 240338701 A B C D Shelf-freezer, fixed wire 240338703 A B C D...
- Page 10 Publication No: 5995414116 FRS23KF5C CONTROLS 08/04...
- Page 11 FRS23KF5C Publication No: 5995414116 CONTROLS Model Index: A FRS23KF5C (FRS23KF5CB5) B FRS23KF5C (FRS23KF5CQ5) C FRS23KF5C (FRS23KF5CS2) D FRS23KF5C (FRS23KF5CW5) POS. NO PART NO. DESCRIPTION 5308000010 A B C D Fan Blade, red, evaporator fan 5300157666 A B C D Bushing-motor mtg, (2) 5303292396 A B C D Bracket-motor mtg, front...
- Page 12 Publication No: 5995414116 FRS23KF5C SYSTEM N58CAAAAA4 08/04...
- Page 13 FRS23KF5C Publication No: 5995414116 SYSTEM Model Index: A FRS23KF5C (FRS23KF5CB5) B FRS23KF5C (FRS23KF5CQ5) C FRS23KF5C (FRS23KF5CS2) D FRS23KF5C (FRS23KF5CW5) POS. NO PART NO. DESCRIPTION 240333602 A B C D Condenser 218679606 A B C D Block-evap coil, styrofoam, (2) 218944001 A B C D Drier-filter, R134a System 241527401...
-
Page 14: Ice And Water Dispenser
Publication No: 5995414116 FRS23KF5C ICE & WATER DISPENSER 08/04... - Page 15 FRS23KF5C Publication No: 5995414116 ICE & WATER DISPENSER Model Index: A FRS23KF5C (FRS23KF5CB5) B FRS23KF5C (FRS23KF5CQ5) C FRS23KF5C (FRS23KF5CS2) D FRS23KF5C (FRS23KF5CW5) POS. NO PART NO. DESCRIPTION 218976409 A B C D Tube-water 218976901 A B C D Tube-water inlet, inlet valve, to ice maker 218976903 A B C D Tube-water inlet, inlet valve, to filter...
-
Page 16: Ice Container
Publication No: 5995414116 FRS23KF5C ICE CONTAINER 37A 34 34 33 N58YBAAAA1 08/04... - Page 17 FRS23KF5C Publication No: 5995414116 ICE CONTAINER Model Index: A FRS23KF5C (FRS23KF5CB5) B FRS23KF5C (FRS23KF5CQ5) C FRS23KF5C (FRS23KF5CS2) D FRS23KF5C (FRS23KF5CW5) POS. NO PART NO. DESCRIPTION 5304428402 A B C D Auger-ice 5304404343 A B C D Cam-drive 218815300 A B C D Container-ice, bucket only 5304404346 A B C D...
-
Page 18: Ice Maker
Publication No: 5995414116 FRS23KF5C ICE MAKER 08/04... - Page 19 FRS23KF5C Publication No: 5995414116 ICE MAKER Model Index: A FRS23KF5C (FRS23KF5CB5) B FRS23KF5C (FRS23KF5CQ5) C FRS23KF5C (FRS23KF5CS2) D FRS23KF5C (FRS23KF5CW5) POS. NO PART NO. DESCRIPTION 218976409 A B C D Tube-water 218976901 A B C D Tube-water inlet, inlet valve, to ice maker 218976903 A B C D Tube-water inlet, inlet valve, to filter...
- Page 20 Publication No: 5995414116 FRS23KF5C ICE MAKER 08/04...
- Page 21 FRS23KF5C Publication No: 5995414116 ICE MAKER Model Index: A FRS23KF5C (FRS23KF5CB5) B FRS23KF5C (FRS23KF5CQ5) C FRS23KF5C (FRS23KF5CS2) D FRS23KF5C (FRS23KF5CW5) POS. NO PART NO. DESCRIPTION 55 # 240531101 A B C D Valve-water, triple solenoid 218709100 A B C D Screw, hex head, 10-32 x 0.500 240363601 A B C D...
-
Page 22: Wiring Schematic
Publication No: 5995414116 FRS23KF5C WIRING SCHEMATIC 08/04... -
Page 23: Wiring Diagram
FRS23KF5C Publication No: 5995414116 WIRING DIAGRAM 08/04 # Functional Parts * Non-Illustrated Parts...
