- Page 3 _______ _ _______ _ POLAR IZED PLUGS CAUTIO N will fit way. fit, Record in space provided below the Serial No. and Model No. of this applianc e. The Serial No. is located on Bed Plate. The Model No. is located on Rating Plate. Serial Model No.
- Page 4 CONTE NTS Name of Parts Accessories Removing the extension table Before sewing (Power supply and Sewing amp) Fitting shank and Quilting seam gtiide. Fitting of presser feet Winding the bobbin Removing bobbin case and bobbin Inserting bobbin into bobbin case Inserting bobbin case into shuttle race Changing needle Threading upper thread &...
- Page 5 OF PARTS (FRONT SIDE) NAME 1 Pattern selector dial 2 Take up lever 3 Tread tension dial 4 Tread guide for upper threading 5 Presser foot 6 Shuttle cover 7 Extension table 8 Spool pin Top cover 10 Stitch length dial Reverse button 12 Bobbin winder spindle 13 Bobbin winder stopper...
- Page 6 ACCESSORI ES Bobbin Felt Zigzag foot Button hole foot (On machine) Button foot Machine Oil Zipper foot Button hole cutter Screw driver Needle...
- Page 7 — —...
- Page 8 BEFORE SEWING 1. Fit the machine into the machine. the machine to the 2. Plug power supply. Sewing speed can be varied by the speed controller. SURE CORRECT PLUG TO SUPPLY CORD) 1. Remove or install lamp from inside of face cover. 2.
- Page 9 Raise the presser foot. Pull the one-touch SEAM lever towards you and the foot will be released. Centre new foot under shank. Raise the presser bar and fit shank as shown. (1) Insert quilting/seam guide Lower shank until groove is directly carefully so as not to damage the holding above and touching the pin.
- Page 11 REMOVING BOBBIN CASE AND BOBBIN Hinged latch 1. Raise needle to its highest hinged 2. Open bobbin case and pull bob- open position bin case out of machine. shuttle race cover, 3. Release the latch and bob bin will fall out easily. INSERTING BOBBiN INTO BOBBIN CASE SLOT 1.
- Page 23 THREE STEP ZIG-ZAG The three step zig-zag stitch has a wide range of sewing applications, such as patching, darning, repairing tears, mending, sewing on elastic and lace, oversew ing edges etc. on a wide range of fabrics. The illustration shows patching, where the stitches are to the edge of the patch and a tear, where the stitches go firstly over the centre of the tear and then to either side but overlapping slighly on the first row.
- Page 26 SEWING ON BUTTONS darning pate as described on page 12. Use button presser foot and attach firmly 3. Place button between presser foot and fabric and lower presser foot. 4. Manuaily turn hand wheel towards you ensuring that the needle enters into both holes of button without obstruction.
- Page 28 BUTTON HOLE SEWING Ft the button hole foot. Set the s:tch length dial within the green marking to achieve the correct density satin sttch. (1) Sew in the sequence illustrated (1) selecting (closeness) of patterns 18, 19, 20 and 19 again. USER TIPS Always sew a sample buttonhole on some spare fabric as settings will change according to the fabric used.
