Summary of Contents for Frigidaire FRS20ZGG
- Page 1 FRS20ZGGB2 FRS20ZGG GALLERY R134a black FRS20ZGGD2 FRS20ZGG GALLERY R134a almond FRS20ZGGW2 FRS20ZGG GALLERY R134a white 101 Masters Blvd. Anderson, SC 29624 Publication No. 5995311916 ©1998 White Consolidated Industries, Inc. All rights reserved 980831 -EN/SERVICE /JLT...
-
Page 2: Freezer Door
Publication No. FRS20ZGG 5995311916 FREEZER DOOR 08/98... - Page 3 FRS20ZGG Publication No. 5995311916 FREEZER DOOR A = FRS20ZGG (FRS20ZGGW2) B = FRS20ZGG (FRS20ZGGD2) C = FRS20ZGG (FRS20ZGGB2) 215734311 A - - Gasket-frzr door,white ,magnetic 215734301 - B - Gasket-frzr door,almond ,magnetic 215734321 - - C Gasket-frzr door,black ,magnetic 5303288950 A B C Support-door rack,RH/LH 5303323484...
-
Page 4: Refrigerator Door
Publication No. FRS20ZGG 5995311916 REFRIGERATOR DOOR 08/98... - Page 5 FRS20ZGG Publication No. 5995311916 REFRIGERATOR DOOR A = FRS20ZGG (FRS20ZGGW2) B = FRS20ZGG (FRS20ZGGD2) C = FRS20ZGG (FRS20ZGGB2) 215734312 A - - Gasket-refr door,white ,magnetic 215734302 - B - Gasket-refr door,almond ,magnetic 215734322 - - C Gasket-refr door,black ,magnetic 218749301 A B C Panel-inner door,refr 5303320230...
- Page 6 Publication No. FRS20ZGG 5995311916 CABINET 08/98...
- Page 7 FRS20ZGG Publication No. 5995311916 CABINET A = FRS20ZGG (FRS20ZGGW2) B = FRS20ZGG (FRS20ZGGD2) C = FRS20ZGG (FRS20ZGGB2) 218748901 A B C Cover-air duct 5303209814 A B C Nut,"U" type ,8-15(A) ,fan mtr mtg 218751301 A B C Cover-evap coil,lower 5303208309 A B C Plug-hole,factory test 215230400...
- Page 8 Publication No. FRS20ZGG 5995311916 SHELVES 08/98...
- Page 9 FRS20ZGG Publication No. 5995311916 SHELVES A = FRS20ZGG (FRS20ZGGW2) B = FRS20ZGG (FRS20ZGGD2) C = FRS20ZGG (FRS20ZGGB2) 218747101 A B C Handle-frzr basket 218298005 A B C Shelf-freezer,sliding ,wire 218159700 A B C Spacer-shelf 5304405990 A B C Shelf-freezer,fixed wire 218746001 A B C Shelf-"Spill-Safe",sliding ,(3)
- Page 10 Publication No. FRS20ZGG 5995311916 CONTROLS 08/98...
- Page 11 FRS20ZGG Publication No. 5995311916 CONTROLS A = FRS20ZGG (FRS20ZGGW2) B = FRS20ZGG (FRS20ZGGD2) C = FRS20ZGG (FRS20ZGGB2) 5303307883 A B C Knob-damper control,white/teal line 5308000010 A B C Fan Blade,red 5308000124 A B C Ring-fan orifice 5300157666 A B C Bushing-motor mtg,(2) 5303205118 A B C...
- Page 12 Publication No. FRS20ZGG 5995311916 SYSTEM 08/98...
- Page 13 FRS20ZGG Publication No. 5995311916 SYSTEM A = FRS20ZGG (FRS20ZGGW2) B = FRS20ZGG (FRS20ZGGD2) C = FRS20ZGG (FRS20ZGGB2) 218787700 A B C Condenser 5303289026 A B C Spacer-tube 5303289029 A B C Clip-cond mtg,(4) 218679603 A B C Block-evap coil,styrofoam ,(2) 218541000 A B C Drier-filter...
- Page 14 Publication No. FRS20ZGG 5995311916 DISPENSER 08/98...
- Page 15 FRS20ZGG Publication No. 5995311916 DISPENSER A = FRS20ZGG (FRS20ZGGW2) B = FRS20ZGG (FRS20ZGGD2) C = FRS20ZGG (FRS20ZGGB2) 5318582501 A B C Tube-water inlet,93" ,plastic ,cut-to-size 218832201 - - - Tube-water inlet,filter ,to filter valve,w/elbow 218859801 - - - Tube-water inlet,inlet valve ,to filter 215294101 A B C Tube-water inlet,formed ,plastic ,dispenser...
-
Page 16: Ice Container
Publication No. FRS20ZGG 5995311916 ICE CONTAINER 08/98... - Page 17 FRS20ZGG Publication No. 5995311916 ICE CONTAINER A = FRS20ZGG (FRS20ZGGW2) B = FRS20ZGG (FRS20ZGGD2) C = FRS20ZGG (FRS20ZGGB2) 5304404344 A B C Auger-ice 5304404343 A B C Cam-drive 218815300 A B C Container-ice 5304404346 A B C Drum-ice disp 218815400 A B C Front-ice container 5304404337...
-
Page 18: Ice Maker
Publication No. FRS20ZGG 5995311916 ICE MAKER 08/98... - Page 19 FRS20ZGG Publication No. 5995311916 ICE MAKER A = FRS20ZGG (FRS20ZGGW2) B = FRS20ZGG (FRS20ZGGD2) C = FRS20ZGG (FRS20ZGGB2) 5318582501 A B C Tube-water inlet,93" ,plastic , cut-to-size 218832201 - - - Tube-water inlet,filter , to filter valve,w/elbow 218859801 - - - Tube-water inlet,inlet valve ,to filter 3206348 A B C...
