Frigidaire FRS20ZRG Factory Parts Catalog

Frigidaire frs20zrg: supplementary guide.


PRODUCT NO.
BASE MODEL NO.
FRS20ZRGB8
FRS20ZRG
FRS20ZRGD8
FRS20ZRG
FRS20ZRGW8
FRS20ZRG
MARKET
North America
WIRING DIAGRAM - # 218903201
OWNER'S GUIDE - # 218955100
SERVICE DATA SHEET - # 218909400
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a
black
R134a
almond
R134a
white
Publication No.
5995340857
000707
-EN/SERVICE /ECL
357
SIDE BY SIDE
REFRIGERATOR
VOLTS
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS20ZRG
©2000 White Consolidated Industries, Inc.
All rights reserved

Summary of Contents

  • Page 1

    PRODUCT NO. BASE MODEL NO. FRS20ZRGB8 FRS20ZRG FRS20ZRGD8 FRS20ZRG FRS20ZRGW8 FRS20ZRG MARKET North America WIRING DIAGRAM - # 218903201 OWNER’S GUIDE - # 218955100 SERVICE DATA SHEET - # 218909400 101 Masters Blvd. Anderson, SC 29624 FACTORY PARTS CATALOG REFRIGERATOR...

  • Page 2

    Publication No. FRS20ZRG 5995340857 FREEZER DOOR 07/00...

  • Page 3

    A = FRS20ZRG (FRS20ZRGW8) B = FRS20ZRG (FRS20ZRGD8) C = FRS20ZRG (FRS20ZRGB8) POS. NO 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZRG FREEZER DOOR PART NO DESCRIPTION 215734311 A B - Gasket-frzr door,white ,magnetic 215734321 - - C...

  • Page 4

    Publication No. FRS20ZRG 5995340857 REFRIGERATOR DOOR 07/00...

  • Page 5

    A = FRS20ZRG (FRS20ZRGW8) B = FRS20ZRG (FRS20ZRGD8) C = FRS20ZRG (FRS20ZRGB8) POS. NO 37A* 37A* # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZRG REFRIGERATOR DOOR PART NO DESCRIPTION 215734312 A B - Gasket-refr door,white ,magnetic 215734322 - - C...

  • Page 6

    Publication No. FRS20ZRG 5995340857 CABINET 07/00...

  • Page 7

    A = FRS20ZRG (FRS20ZRGW8) B = FRS20ZRG (FRS20ZRGD8) C = FRS20ZRG (FRS20ZRGB8) POS. NO 10A* 30A* 101* # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZRG CABINET PART NO DESCRIPTION 218748901 A B C Cover-air duct 5303209814 A B C Nut,"U"...

  • Page 8

    Publication No. FRS20ZRG 5995340857 SHELVES 07/00...

  • Page 9

    A = FRS20ZRG (FRS20ZRGW8) B = FRS20ZRG (FRS20ZRGD8) C = FRS20ZRG (FRS20ZRGB8) POS. NO 100A 100B # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZRG SHELVES PART NO DESCRIPTION 5303300707 A B C Trim-basket 218298005 A B C Shelf-freezer,sliding ,wire...

  • Page 10

    Publication No. FRS20ZRG 5995340857 CONTROLS 07/00...

  • Page 11

    A = FRS20ZRG (FRS20ZRGW8) B = FRS20ZRG (FRS20ZRGD8) C = FRS20ZRG (FRS20ZRGB8) POS. NO 13 # 17A* 21 # 23 # 114# 138* # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZRG CONTROLS PART NO DESCRIPTION 215028605 A B C...

  • Page 12

    Publication No. FRS20ZRG 5995340857 SYSTEM 07/00...

  • Page 13

    A = FRS20ZRG (FRS20ZRGW8) B = FRS20ZRG (FRS20ZRGD8) C = FRS20ZRG (FRS20ZRGB8) POS. NO 13 # 14 # 15 # 21 # 29 # 55 # 60 # # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZRG SYSTEM PART NO...

  • Page 14

    Publication No. FRS20ZRG 5995340857 DISPENSER 07/00...

  • Page 15

    A = FRS20ZRG (FRS20ZRGW8) B = FRS20ZRG (FRS20ZRGD8) C = FRS20ZRG (FRS20ZRGB8) POS. NO 12A* 17A* 35 # 38A# 38B# # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZRG DISPENSER PART NO DESCRIPTION 5308010366 A B C Tube-water inlet,0.25 OD x 93" ,plastic...

  • Page 16

    Publication No. FRS20ZRG 5995340857 ICE CONTAINER 07/00...

  • Page 17

    A = FRS20ZRG (FRS20ZRGW8) B = FRS20ZRG (FRS20ZRGD8) C = FRS20ZRG (FRS20ZRGB8) POS. NO 45 # # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZRG ICE CONTAINER PART NO DESCRIPTION 5304404344 A B C Auger-ice 5304404343 A B C Cam-drive...

  • Page 18

    Publication No. FRS20ZRG 5995340857 ICE MAKER 07/00...

  • Page 19

    A = FRS20ZRG (FRS20ZRGW8) B = FRS20ZRG (FRS20ZRGD8) C = FRS20ZRG (FRS20ZRGB8) POS. NO 11 # 12 # 13 # 15 # 17 # 55 # 141* # = Fast-moving Parts * = Non-Illustrated Parts FRS20ZRG ICE MAKER PART NO...

  • Page 20

    Publication No. FRS20ZRG 5995340857 WIRING SCHEMATIC 07/00...

  • Page 21

    FRS20ZRG Publication No. 5995340857 WIRING DIAGRAM # = Fast-moving Parts 07/00 * = Non-Illustrated Parts...
