Frigidaire FEB30S5D Factory Parts Catalog

Frigidaire FEB30S5D Factory Parts Catalog

Single electric wall oven
Hide thumbs Also See for FEB30S5D:
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual See also: Factory Parts Catalog
FEB30S5DC.tif CFEB30S5DSA.eps BFEB30S5DSA.eps DFEB30S5DCA.eps
318046237.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FEB30S5DCC
38254331E40S3
Series
30" single
Color
stainless
Market
North America
Wiring Diagram
318046237
Owner's Guide
318200924
Installation Instructions 316201514
Service Data Sheet
316047413
Timer Guide
318200189
Publication No.
5995456893
05/12/21
(EN/SERVICE/ECL)
377
SINGLE ELECTRIC

WALL OVEN

Model No.
FEB30S5D
©
Copyright
2005 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

Related Manuals for Frigidaire FEB30S5D

Summary of Contents for Frigidaire FEB30S5D

  • Page 1: Wall Oven

    Product No. FEB30S5DCC 38254331E40S3 Series 30" single Color stainless Market North America Wiring Diagram 318046237 Owner's Guide 318200924 Installation Instructions 316201514 Service Data Sheet 316047413 Timer Guide 318200189 SINGLE ELECTRIC FEB30S5DC.tif CFEB30S5DSA.eps BFEB30S5DSA.eps DFEB30S5DCA.eps WALL OVEN 318046237.eps Electrolux Major Appliances Model No.

  • Page 2: Control Panel

    Publication No: 5995456893 FEB30S5DCC CONTROL PANEL 12/05...
  • Page 3 FEB30S5DCC Publication No: 5995456893 CONTROL PANEL POS. NO PART NO. DESCRIPTION 318257300 Shield, oven top 318260100 Cover, box 318274601 Control Panel Assembly, glass, black, w/touch pad 20 # 316418522 Clock/Timer, electronic, ES350W1 316021107 Screw, hex head, 8-32, silver 5303211311 Screw, 8 x 0.500 12/05 # Functional Parts * Non-Illustrated Parts...
  • Page 4 Publication No: 5995456893 FEB30S5DCC BODY 12/05...
  • Page 5 FEB30S5DCC Publication No: 5995456893 BODY POS. NO PART NO. DESCRIPTION 318259202 Back, main 318258902 Shield, insulation, upper 318262502 Rack, oven 5303317977 Pan, broiler 5303317976 Insert, broiler pan 12 # 318089917 Switch, light 318224000 Receptacle, oven light 318268099 Insulation, oven light 5303013071 Bulb/Lamp, light 3201911...
  • Page 6 Publication No: 5995456893 FEB30S5DCC DOOR 12/05...
  • Page 7 FEB30S5DCC Publication No: 5995456893 DOOR POS. NO PART NO. DESCRIPTION 318260401 Trim, oven door, side, (2) 318262101 Cover, rear door, black, (2) 318260500 Baffle, door 318285057 Insulation, oven door 318285062 Insulation, oven door 316117500 Glass, oven door, heat barrier 318259605 Liner, door 5304452028 Screw, handle mtg, 10-14 x 1/2, (2)

  • Page 8: Wiring Diagram

    Publication No: 5995456893 FEB30S5DCC WIRING DIAGRAM 12/05...
