Chapter
Data Communication
10
Data communications capabilities let you transfer data between two CASIO
PV Units, between a PV Unit and a BN-10/BN-20 Unit, or between a PV
Unit and a BN-10A/BN-20A/BN-40A Unit. You can also receive data from a
CASIO SF, CSF, or NX Series Unit, and communicate with a personal
computer using PC sync for Windows.
See the manual that comes with PC sync for Windows for details on
connecting to a computer and setting up for communication.
Using the Cradle ............................................................................ 122
To connect the PV Unit to the cradle ........................................................ 122
To detach the PV Unit from the cradle ..................................................... 123
Data Communications Between Two PV Units .......................... 123
To connect two PV Units .......................................................................... 123
To send data from the host unit to the terminal unit ................................. 124
To receive data from the terminal unit on the host unit ............................ 126
Data Communications Between a PV Unit and a BN Unit ....... 129
To connect a PV Unit to a BN Unit .......................................................... 129
To send data from the PV Unit to the BN Unit ........................................ 130
To receive data from the BN Unit on the PV Unit .................................... 132
Receiving Data From an SF/CSF/NX Series Unit ...................... 134
To connect a PV Unit and an SF/CSF/NX Series Unit ............................. 134
To make communication parameter settings ............................................ 135
To receive data from an SF/CSF/NX Series Unit ..................................... 137
10
121

Advertisement

Table of Contents
loading

Summary of Contents for Casio PV-250X

  • Page 1 PV Units, between a PV Unit and a BN-10/BN-20 Unit, or between a PV Unit and a BN-10A/BN-20A/BN-40A Unit. You can also receive data from a CASIO SF, CSF, or NX Series Unit, and communicate with a personal computer using PC sync for Windows.
  • Page 2: Using The Cradle

    Using the Cradle The PV Unit comes with a cradle that helps to make data communications quicker and easier. The following procedures describe how to attach the PV Unit to and detach it from the cradle. To connect the PV Unit to the cradle 1.
  • Page 3: To Detach The Pv Unit From The Cradle

    Chapter 10 Data Communication To detach the PV Unit from the cradle 1. Turn off PV Unit power. 2. Lift up on the PV Unit while holding down the cradle’s Release button. Release button Data Communications Between Two PV Units This section describes how to set up and communicate between two PV Units.
  • Page 4: To Send Data From The Host Unit To The Terminal Unit

    3. Use an optional SB-90 9-9 pin connector to connect the two cradles to each other. Host unit Terminal unit Start button Cradles SB-90 9-9 pin connector • All data communication settings must be made on only one of the PV Units only.
  • Page 5 Chapter 10 Data Communication 3. Tap the Menu Bar icon to display the menu bar, and then tap System – Data communication. 4. Tap the button next to Pocket Viewer to specify the data communication configuration. 5. Tap the button next to Send. 6.
  • Page 6: To Receive Data From The Terminal Unit On The Host Unit

    8. After everything is the way you want it, tap Set. 9. Turn on the power of the terminal unit and then press the Start button on its cradle to start the data transfer operation. To receive data from the terminal unit on the host unit 1.
  • Page 7 Chapter 10 Data Communication 3. Tap Set. 4. Tap the check boxes to specify the data you want to receive (checked) and the data you do not want to receive (unchecked). 5. After everything is the way you want it, tap Set. 6.
  • Page 8 Notes • The above procedures can be used to send or receive all data in specific modes only. You cannot send or receive individual data items. • Data communication can be interrupted at any time by pressing Esc. This causes the message Stopped! to appear on the displays of both units.
  • Page 9: Data Communications Between A Pv Unit And A Bn Unit

    Chapter 10 Data Communication Data Communications Between a PV Unit and a BN Unit This section describes how to set up and communicate between a PV Unit and a BN Unit (BN-10/BN-20 or BN-10A/BN-20A/BN-40A). To connect a PV Unit to a BN Unit 1.
  • Page 10: To Send Data From The Pv Unit To The Bn Unit

    To send data from the PV Unit to the BN Unit 1. After connecting the two units, turn on the PV Unit. • BN Unit power should still be off at this time. 2. Display the list view in a mode whose data can be sent with this setup. •...
  • Page 11 Chapter 10 Data Communication 6. Tap Set. 7. Tap the check boxes to specify the data you want to send (checked) and the data you do not want to send (unchecked). 8. After everything is the way you want it, tap Set. 9.
  • Page 12: To Receive Data From The Bn Unit On The Pv Unit

    • The following shows the relationship between data when sent from the PV Unit to a BN Unit. Mode PV Unit BN Unit Contacts Untitled 1-5 PERSONAL • Check Contacts (1-5) as the data type to send this data. Category names Not transferred Item (field) names Not transferred...
  • Page 13 Chapter 10 Data Communication 3. Tap Set. 4. Tap the check boxes next to specify the data you want to receive (checked) and the data you do not want to receive (unchecked). 5. After everything is the way you want it, tap Set. 6.
  • Page 14: Receiving Data From An Sf/Csf/Nx Series Unit

    • Transferring data from the PV-200A/PV-250X/PV-400A/PV-450X to the BN Unit causes all euro symbols to be replaced by spaces. • The following shows the relationship between data when received by the PV Unit from a BN Unit. Mode BN Unit PV Unit Contacts PERSONAL...
  • Page 15: To Make Communication Parameter Settings

    Chapter 10 Data Communication 4. Use an optional SB-90 9-9 pin connector to connect the PV Unit cradle to the other unit’s cable. PV Unit SF/CSF/NX Series Unit Cradle SB-90 3-9 pin cable SB-90 9-9 pin connector To make communication parameter settings 1.
  • Page 16 3. Tap the Menu Bar icon to display the menu bar, and then tap System – Data communication. 4. Tap the button next to SF/CSF/NX. 5. Press the button next to Set up parameters and then tap Set. 6. Tap the buttons under Parity, Bit length, and BPS to make the settings you want.
  • Page 17: To Receive Data From An Sf/Csf/Nx Series Unit

    Chapter 10 Data Communication To receive data from an SF/CSF/NX Series Unit 1. After connecting the two units, turn on the PV Unit. 2. Display the list view in a mode whose data can be received with this setup. • This configuration supports receipt of Contacts, Memo, Schedule and To Do data.
  • Page 18 • Data cannot be received from the following CASIO units: SF-A Series, SF-5580, 5780, 5980, 5580E, 5780E, 5980E, 5590SY, 5790SY, 5990SY, 5590SYE, 5790SYE, 5990SYE, 6500SY, 6700SY, 6900SY, 7100SY, 7200SY.
