Frigidaire FRS26ZSH Factory Parts Catalog

Frigidaire FRS26ZSH Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS26ZSH:
Table of Contents

Advertisement

Quick Links

See also: Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRS26ZSHB5
FRS26ZSH
FRS26ZSHW5
FRS26ZSH
MARKET
North America
WIRING DIAGRAM - # 218903201
OWNER'S GUIDE - # 218953800
SERVICE DATA SHEET - # 218909401
101 Masters Blvd.
Anderson, SC 29624
FACTORY PARTS CATALOG
SERIES
COLOR
R134a System
stainless/black
R134a System
stainless/white
Publication No.
5995347068
001205
-EN/SERVICE/KHB
357FRS26ZSH

SIDE BY SIDE

REFRIGERATOR
VOLTS
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26ZSH
©2000 White Consolidated Industries, Inc.
All rights reserved

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRS26ZSH

Summary of Contents for Frigidaire FRS26ZSH

  • Page 1: Side By Side

    FACTORY PARTS CATALOG SIDE BY SIDE REFRIGERATOR PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS26ZSHB5 FRS26ZSH R134a System stainless/black FRS26ZSHW5 FRS26ZSH R134a System stainless/white MARKET North America WIRING DIAGRAM - # 218903201 OWNER’S GUIDE - # 218953800 SERVICE DATA SHEET - # 218909401 SIDE BY SIDE REFRIGERATOR 101 Masters Blvd.
