CAD-1610-SE
OPERATING MANUAL
NOTE:
Before installing your new CAD-1610-SE, please read this manual carefully as it will inform you
of the CAD-1610-SE's specifications, proper installation and operation procedures. Also
included in this manual are guidelines on how to properly service and care for your new CAD-
1610-SE.
Advertisement
Table of Contents
Related Manuals for Cary Audio Design CAD-1610-SE
Summary of Contents for Cary Audio Design CAD-1610-SE
- Page 1 CAD-1610-SE OPERATING MANUAL NOTE: Before installing your new CAD-1610-SE, please read this manual carefully as it will inform you of the CAD-1610-SE's specifications, proper installation and operation procedures. Also included in this manual are guidelines on how to properly service and care for your new CAD- 1610-SE.
- Page 2 CAD-1610-SE is an air gap design with full bias running on a continual basis. The output transformer in the CAD-1610-SE is the most important component in the amplifier and has been specifically designed by Cary Audio Design for use in the CAD-1610’s. We have taken the approach in the output transformer design the use oxygen free copper wire.
- Page 3 coupling capacitor along with supplying bias for the 300B tube. The 300B gain stage is supplied voltage on the anode by a high inductance voltage choke. This choke takes the place of a conventional resistor used in most amplifiers. The choke allows the 300B to swing a much greater amount of amplified AC audio signal to the output T-1610 tube.
- Page 4 loud music passages it would be found there is no more than a volt or so change from soft to loud passages. Another technical feature of the new CAD-1610-SE amplifier is stability. The CAD-1610-SE’s may be operated with no load (without speaker) without damage to the amplifier, output transformer or tubes.
- Page 5 Model: CAD-1610-SE Serial Number: _____________ _____________...
-
Page 6: Specifications
The operation of the CAD-1610-SE mono block amplifier is a simple procedure since each unit is designed for long term stability in virtually any home operating situation. Therefore, if the unit is operated outside the parameters outlined in the Operating Manual, damage may result. Please read the Operating Manual carefully before operating the CAD-1610-SE amplifier. - Page 7 TUBES : 1 - KR-1610 output 2 - 6SN7 input 2 - 6BL7 driver 2 - 5R4 rectifier 1 - WE 300B driver OUTPUT TRANSFORMER : 200% Duty Cycle 100 watt special custom design for 1610 tube RESISTORS : 1% Metal Film CAPACITORS : Oil Filled Coupling FILTER CHOKES...
-
Page 8: Front Panel Features
FRONT PANEL FEATURES... - Page 9 REAR APRON FEATURES...
-
Page 10: Power Requirements
CAD-1610-SE PLACEMENT The CAD-1610-SE is designed for use inside homes. It must be protected from the elements and temperature extremes. For example, avoid placing the amplifier in extremely hot locations such as near radiators or other heating units. Its location among the user’s audio components is not critical; however, certain precautions must be taken. -
Page 11: Warranty Card
Cary Audio Design within 10 days of the purchase. Cary Audio Design also suggests that the original packing cartons be maintained in the event it is necessary to ship the amplifiers at a later date. Warranty restrictions apply. -
Page 12: Factory Service
NON-WARRANTY REPAIRS Cary Audio Design will provide repair service for its products charging on a time and expense basis for the repairs. WARNINGS... - Page 13 CAD-1610-SE TROUBLESHOOTING GUIDE SYMPTOM CAUSE REMEDY Hum or “Buzzing” through -Ground loop -Install 2-pin adapter on A.C. speakers cord to float the ground. -T1610 tube with high plate current -Check bias of T1610. If high, readjust to proper bias setting. -Intermittent or poor connection of interconnect -Replace interconnect ground...
- Page 14 -Reconnect UNITED STATES LIMITED WARRANTY Cary Audio Design, Inc. warrants to the original United States purchaser for use in the United States, that this product shall be free from defects in material (except tubes and AF output transistors) or workmanship for: Amplifiers and Preamplifiers, Three (3) years from the date of the original purchase.
