SERVICE MANUAL
MODEL: PT-1900/1910/1850

Advertisement

Table of Contents
loading

Related Manuals for Brother PT-1900

Summary of Contents for Brother PT-1900

  • Page 1 SERVICE MANUAL MODEL: PT-1900/1910/1850...
  • Page 2 PREFACE This publication is a service manual covering the specifications, general mechanisms, disassembly/reassembly procedure, and troubleshooting and error message of the Brother PT- 1900/1910/1850. It is intended for service personnel and other concerned persons to accurately and quickly provide after-sale service for our PT-1900/1910/1850.

  • Page 3: Table Of Contents

    CONTENTS CHAPTER I SPECIFICATIONS................. I-1 MECHANICAL SPECIFICATIONS ................ I-1 1.1.1 External Appearance ..................I-1 1.1.2 Keyboard......................I-2 1.1.3 Display ......................I-2 1.1.4 Printing Mechanism..................I-2 1.1.5 Tape Cassette ....................I-3 1.1.6 Tape Cutter ....................I-3 ELECTRONICS SPECIFICATIONS ..............I-10 1.2.1 Character Generator..................
  • Page 4 MAIN PCB......................II-11 2.3.1 Block Diagram....................II-11 2.3.2 Solder Points....................II-12 POWER SUPPLY PCB ..................II-13 CHAPTER III DISASSEMBLY & REASSEMBLY ..........III-1 DISASSEMBLY PROCEDURE................III-1 [ 1 ] Removing the Battery Lid and Batteries............III-1 [ 2 ] Removing the Tape Cassette and Tape Separator Stick......III-2 [ 3 ] Removing the Bottom Cover ...............
  • Page 5 CHAPTER IV TROUBLESHOOTING AND ERROR MESSAGE ....... IV-1 TROUBLESHOOTING ..................IV-1 4.1.1 Precautions ....................IV-1 4.1.2 After Repairing ....................IV-1 4.1.3 Troubleshooting Flows..................IV-2 [ 1 ] Tape feeding failure..................IV-2 [ 2 ] Printing failure ..................... IV-4 [ 3 ] Powering failure (Nothing appears on the LCD.) ..........

  • Page 6: Chapter Ispecifications

    CHAPTER I SPECIFICATIONS MECHANICAL SPECIFICATIONS 1.1.1 External Appearance (PT-1900/1910) (PT-1850) Fig. 1.1-1 PT-1900/1850 Dimensions (W x D x H) 181 x 232.5 x 61.4 mm (7.13" x 9.15" x 2.42") Weight Machine proper Approx. 800 g In package Approx. 1.31 kg (PT-1900 (U.S.A./AUS)) Approx.

  • Page 7: Keyboard

    1.1.2 Keyboard Entry system Rubber key pad Number of alphanumeric and symbol keys Number of function keys 12 (including “On/Off ( ) ” key) Key arrangement See Fig. 1.1-2. Navigation dial (PT-1850) Rotary switch : 24 positions / cycle Set key : 1 1.1.3 Display Display type...

  • Page 8: Tape Cassette

    1.1.5 Tape Cassette Cassette Cartridge type Types of tape cassettes • Laminated tape cassette Laminate tape, ink ribbon, and adhesive base tape • Non-laminated tape cassette Non-laminate tape and ink ribbon • Instant lettering tape cassette Instant lettering tape and ink ribbon •...
  • Page 9 PT-1900 U.S.A. / CANADA PT-1910 U.S.A. Fig. 1.1-2 Key Arrangement (1)
  • Page 10 PT-1900 AUSTRALIA Fig. 1.1-2 Key Arrangement (2)
  • Page 11 PT-1850 FRENCH Fig. 1.1-2 Key Arrangement (3)
  • Page 12 PT-1850 GERMAN Fig. 1.1-2 Key Arrangement (4)
  • Page 13 PT-1850 U.K. Fig. 1.1-2 Key Arrangement (5)
  • Page 14 PT-1850 BELGIUM Fig. 1.1-2 Key Arrangement (6)

  • Page 15: Electronics Specifications

    ELECTRONICS SPECIFICATIONS 1.2.1 Character Generator Internal characters U.S.A./CAN (PT-1900/1910) 179 characters U.K./ FRA/ BEL (PT-1850) 198 characters GER (PT-1850) 211 characters Internal font HELSINKI, BRUSSELS Internal memory Text buffer 99 characters (PT-1900/1910/1850) File memory 300 characters (PT-1900/1910/1850) 1.2.2 Power Supply Automatic power off Normal mode : 5 min.

  • Page 16: Chapter Ii General Mechanisms

    CHAPTER II GENERAL MECHANISMS MAIN MECHANISM 2.1.1 Print Mechanism Structure of Thermal Head This machine uses thermal transfer printing. The thermal print head has a heat generator consisting of 112 heating elements which are vertically aligned as shown in Fig. 2.1-1. Each heating element is 0.195 mm wide by 0.141 mm high.
  • Page 17 [For stamp tape cassettes] If the selected heating element(s) generates heat, the porous-stamp tape will be melted so that a pore (pores) will be formed in the tape. The tape is advanced and the next heating cycle is repeated, thus forming a character of pores on the tape. The printed stamp tape can be used as the face of a stamp.

  • Page 18: Roller Holder Assy Setting & Retracting Mechanism

    2.1.2 Roller Holder ASSY Setting & Retracting Mechanism This mechanism consists of the roller release lever, roller holder release rod, and roller holder ASSY. The roller holder ASSY supports the platen and the tape feed sub roller so that they can move perpendicularly to the head ASSY and the tape feed roller, respectively, as well as rotating freely.

  • Page 19: Tape & Ribbon Feed Mechanism

    2.1.3 Tape & Ribbon Feed Mechanism This mechanism consists of a DC motor, gear train, and roller holder ASSY. Tape Feeding When you load a tape cassette and close the cassette cover, the tape feed roller inside the cassette and the tape feed sub roller in the roller holder ASSY sandwich the tape (the laminate tape and adhesive base tape when using laminated tape cassettes) inbetween, as described in Subsection 2.1.2.
  • Page 20 Adhesive Base Tape Feeding (only for laminated tape cassettes) A laminated tape cassette contains both a transparent laminate tape roll and a separate adhesive base tape roll. When a transparent laminate tape and an adhesive base tape pass through the contact point (between the tape feed roller and tape feed sub roller), they are then bonded together into a single, printed tape.

  • Page 21: Automatic Tape Cutter Mechanism (Pt-1900/1910

    2.1.4 Automatic Tape Cutter Mechanism (PT-1900/1910) The cutter ASSY consists of a stationary blade and a movable blade driven by the cutter motor. Upon completion of printing and tape feeding, the CPU activates the cutter motor whose clockwise rotation is transmitted via the idle gears to the cutter moving gear. As the cutter moving gear rotates counterclockwise, its boss "X"...

  • Page 22: Tape Cutter Mechanism (Pt-1850

    2.1.5 Tape Cutter Mechanism (PT-1850) The cutter unit consists of a stationary cutter and a movable cutter. Pressing the cutter lever actuates the movable cutter so that the cutter cuts the printed tape routing through the movable and stationary cutters, just like a scissors. Attached to the cutter lever, the cutter sensor arm turns up so that its tip comes into contact with the switch of the cutter sensor circuit on the cutter sensor holder ASSY, stopping printing and tape feeding.

  • Page 23: Roller Holder Assy & Cassette Cover Interlocking Mechanism

    2.1.6 Roller Holder ASSY & Cassette Cover Interlocking Mechanism Closing the cassette cover pushes down the roller release lever and brings the top of the lever into the hooked section provided on the inside of the cassette cover. As described in Subsection 2.1.2 “Roller Holder ASSY Setting & Retracting Mechanism”, the roller release lever shifts the roller holder release rod so that the roller holder ASSY is pressed towards the head ASSY side.
  • Page 24 (PT-1900/1910) Hooked section Cassette cover Cassette cover (PT-1850) Hooked section Cassette cover Cassette cover Fig. 2.1-8 Roller Holder ASSY & Cassette Cover Interlocking Mechanism Opening the cassette cover pulls up the roller release lever placed in the hooked section of the cassette cover, which shifts the roller holder release rod so that the roller holder ASSY is retracted from the head ASSY side by the roller holder release spring.

  • Page 25: Outline Of Control Electronics

    OUTLINE OF CONTROL ELECTRONICS 2.2.1 Configuration of the Electronic Part Fig. 2.2-1 shows a block diagram of the control electronics of the PT-1900/1910/1850. The control electronics consists of three printed circuit boards (main PCB, motor PCB, and power supply PCB), a tape feed motor, a cutter motor (PT-1900/1910), and a thermal print head assembly. 2.2.2 Main PCB This manages all the PT-1900/1910/1850 components including an LCD, key pad, two DC motors...

  • Page 26: Main Pcb

    MAIN PCB 2.3.1 Block Diagram Fig. 2.3-1 shows a block diagram of the main PCB. The main PCB consists of the following: ROM (Masked) Key contacts matrix and solder points Power ON/OFF circuit and power saving circuit DC motor driver circuit Cutter motor driver circuit (PT-1900/1910) Thermal head drive circuit Voltage detector circuit and temperature sensor circuit...

  • Page 27: Solder Points

    2.3.2 Solder Points Solder points 1 through 5 customize the machine for the destination. Solder points A through C are used for the individual thermal head properties. The CPU reads the solder point status once in the powering-on sequence to recognize the customization.

  • Page 28: Power Supply Pcb

    POWER SUPPLY PCB C1 for the logic circuitry and the thermal print head and motor drive sources. Connecting the AC adapter plug with the AC jack J1 cuts off the power fed from the batteries and feeds power from the AC adapter. Fig.

  • Page 29: Chapter Iii Disassembly & Reassembly

    CHAPTER III DISASSEMBLY & REASSEMBLY DISASSEMBLY PROCEDURE [ 1 ] Removing the Battery Lid and Batteries Turn the machine upside down. Press section “A” of the battery lid to remove, then take out batteries. Section “A” Bottom cover Battery lid Batteries Bottom cover Fig.

  • Page 30: Removing The Tape Cassette And Tape Separator Stick

    [ 2 ] Removing the Tape Cassette and Tape Separator Stick Place the machine rightside up and open the cassette cover fully. Pull the tape cassette up and out of the machine. (PT-1900/1910) Cassette cover Tape cassette (PT-1850) Cassette cover Tape cassette Fig.
  • Page 31 Pull the tape separator stick up. (PT-1900/1910) Tape separator stick Hook (PT-1850) Tape separator stick Hook Fig. 3.1-3 Removing the Tape Separator Stick III-3...

  • Page 32: 3 ] Removing The Bottom Cover

    [ 3 ] Removing the Bottom Cover Close the cassette cover while pressing down section “B”. Turn the machine upside down. Remove four screws from the bottom cover. Apply your fingers to the bottom cover and pull it up. (PT-1900/1910) Section “B”...
  • Page 33 (PT-1850) Section “B” Cassette cover Section “B” Screws Bottom cover Screws Fig. 3.1-5 Removing the Bottom Cover (1) (PT-1850) III-5...
  • Page 34 Separate the bottom cover from the upper cover. Open the bottom cover to the left as shown below. Discharge the condenser (C1) on the main PCB unit with tool like a flat screwdriver. Disconnect the power supply harness from the main PCB unit. Remove the screw that secures the grounding wire to the main frame ASSY.

  • Page 35: 4 ] Removing The Cassette Cover, Main Frame Assy

    [ 4 ] Removing the Cassette Cover, Main Frame ASSY CAUTION: During the following job, handle the connectors and harnesses gently so as not to damage them. Take off the cassette cover from the upper cover. The roller release lever will pop up. Cassette cover Roller release lever Upper cover...
  • Page 36 Remove the switch ASSY harness which is soldered at 6 places, from the main PCB unit. Note: However, if only the main frame ASSY is removed, the soldered switch ASSY must not be removed. (PT-1900/1910) Main frame ASSY Switch ASSY harness Upper cover Main PCB unit (PT-1850)
  • Page 37 Disconnect the following harnesses from the main PCB unit. - Cutter motor harness (PT-1900/1910 only) - Full cutter sensor harness (PT-1900/1910 only) - Cutter sensor harness (PT-1850 only) Remove the harness the DC motor PCB by melting the solder. - DC motor harness Disconnect the head cable from the main PCB unit.
  • Page 38 Remove the cutter lever from the upper cover. (PT-1850 only) (PT-1850) Screws DC motor harness Main frame ASSY Head cable Cutter sensor harness Cutter lever Upper cover Main PCB unit Fig. 3.1-10 Removing the Main Frame ASSY (2) (PT-1850) III-10...
  • Page 39 (PT-1900/1910) Power supply harness Head cable Full cutter sensor harness DC motor harness Cutter motor harness Main PCB unit Switch ASSY harness (PT-1850) Head cable Power supply harness Cutter sensor harness DC motor harness Main PCB unit Switch ASSY harness Fig.
  • Page 40 Disassembling the Main Frame ASSY Removing the roller holder release rod, roller release lever, roller holder ASSY, and head ASSY Remove the retaining ring from the roller holder ASSY. Lift up the roller release lever as shown below and pull up the roller holder ASSY together with the roller release lever and roller holder release rod, making sure that the roller holder release spring does not go flying off.
  • Page 41 Removing the DC motor ASSY Remove two screws from the main frame ASSY, then take off the DC motor ASSY. DC motor ASSY Screw Main frame ASSY Screw Fig. 3.1-13 Removing the DC Motor ASSY III-13...
  • Page 42 Removing the cutter ASSY, cutter motor ASSY, and full cutter sensor PRO ASSY WARNING: Be careful with the cutter blades. Remove screw “a” and take off the cutter ASSY. Remove the washer (by using a pin) and take off the cutter moving gear and cutter double gears.
  • Page 43 Removing the cutter ASSY and cutter sensor folder ASSY WARNING: Take care not to touch the cutter of the cutter ASSY. Remove screw “a” and take off the cutter sensor folder ASSY. Release the three hooks to remove the cutter sensor arm. Remove the spring.

  • Page 44: Removing The Main Pcb Unit And Rubber Key Pad

    [ 5 ] Removing the Main PCB Unit and Rubber Key Pad When you handle the PCB, it is recommended that an anti-static mat be used. If you have built up a static charge, touching the PCB without any anti-static control may damage the LSI and other electronic devices.
  • Page 45 Remove the navi dial from the DC motor PCB. (PT-1850) Navi dial DC motor PCB (Main PCB) Fig. 3.1-17 Removing the Main PCB Unit and DC Motor PCB (2) Lift up the rubber key pad. Remove the emblem from the upper cover. (PT-1900/1910) (PT-1900/1910) Rubber key pad Upper cover...

  • Page 46: 6 ] Removing The Switch Assy

    [ 6 ] Removing the Switch ASSY Remove the switch ASSY harness from “A” position of the upper cover. Remove the switch ASSY from the upper cover by pulling the three pawls outwards. Switch ASSY “A” Upper cover Pawls Fig. 3.1-19 Removing the Switch ASSY [ 7 ] Removing the Blind Cover Remove the blind cover from the bottom cover by pulling the three pawls outwards.

  • Page 47: 8 ] Removing The Power Supply Pcb

    [ 8 ] Removing the Power Supply PCB Remove the positive (+) and negative (-) terminals of the battery power cords from the bottom cover. Note: When handling those terminals, do not grip the cords but the terminal plates. Remove the one screw from the power supply PCB. Screw Grounding wire Negative (-) terminal...

  • Page 48: 9 ] Removing The Battery Terminals

    [ 9 ] Removing the Battery Terminals Remove the battery terminal “A” as shown below (left). As shown below (right), remove the battery terminal “B” while pressing section “A” with the tip of a flat screwdriver. Section “A” Battery terminal “A” Battery terminal “B”...

  • Page 49: Reassembly Procedure

    REASSEMBLY PROCEDURE [ 1 ] Installing the Battery Terminals Place the bottom cover upside down and fit battery terminal “A” into the bottom cover as shown below (left). Make sure that pawled sections “A” catches the bottom cover. Fit a battery terminal “B” into the bottom cover as shown below (right). Section “A”...

  • Page 50: 2 ] Installing The Power Supply Pcb

    [ 2 ] Installing the Power Supply PCB Fit the positive (+) and negative (-) terminals of the battery power cords into the bottom cover. Note 1: When handling those terminals, do not grip the cords but the terminal plates. Note 2: Route the battery power cords through the two ribs provided on the bottom cover.
  • Page 51 Fig. 3.2-3 Installing the Power Supply PCB (2) III-23...

  • Page 52: 3 ] Installing The Blind Cover

    [ 3 ] Installing the Blind Cover Fit two holes “A” of the blind cover over the pins provided on the bottom cover and push down the blind cover until pawls “B” catch the hooks on the bottom cover. Pawl “B” Pawl “B”...

  • Page 53: 4 ] Installing The Switch Assy

    [ 4 ] Installing the Switch ASSY Put the switch ASSY into the upper cover so that the switch ASSY is hooked onto the three pawls of the upper cover completely. Hook the switch ASSY harness into the two ribs on the upper cover. Switch ASSY Pawls Upper cover...

  • Page 54: 5 ] Installing The Rubber Key Pad

    [ 5 ] Installing the Rubber Key Pad Assemble the emblem onto the upper cover. Place the rubber key pad so that it is fitted over the two bosses and two pins provided on the upper cover. (PT-1900/1910) Rubber key pad Boss Upper cover Emblem...

  • Page 55: 6 ] Installing The Main Pcb Unit

    [ 6 ] Installing the Main PCB Unit Put the navi dial onto the DC motor PCB. (PT-1850 only) Navi dial DC motor PCB (Main PCB) Fig. 3.2-8 Installing the Main PCB Unit (1) III-27...
  • Page 56 Pull the positions “A” outwards to put the LCD with the main PCB unit into the position “B”. Check that there is no foreign material or dust on the key contacts on the main PCB unit. Note : Make sure that the two latches of the upper cover catch the main PCB unit. Secure the DC motor PCB onto the upper cover with three screws.

  • Page 57: 7 ] Installing The Main Frame Assy

    [ 7 ] Installing the Main Frame ASSY If the main frame ASSY has been disassembled, assemble the components by referring to the following pages. Assemble the cutter lever onto the upper cover. Pull down the roller release lever to the vertical position and set the main frame ASSY onto the upper cover.
  • Page 58 (PT-1900/1910) Screws DC motor harness Head cable Main frame ASSY Full cutter sensor harness DC motor harness “A” Cutter motor harness Switch ASSY harness “A” Black DC motor harness Upper cover Switch ASSY harness Main PCB unit Main frame ASSY Cutter motor ASSY Head cable Full cutter sensor PRO ASSY...
  • Page 59 (PT-1850) Screws DC motor harness Head cable Main frame ASSY Cutter sensor harness DC motor harness Cutter lever “A” Switch ASSY harness “A” Cutter lever Black DC motor harness Upper cover Switch ASSY harness Main PCB unit Main frame ASSY Cutter sensor DC motor harness Head cable...
  • Page 60 Solder the six switch ASSY harnesses onto the main PCB unit. Note: Be careful to the direction of the switch ASSY harness and not to stick out from the designated place when soldering switch ASSY harness. CAUTION: When soldering, use the lead-free solder. (PT-1900/1910) Main frame ASSY Black...
  • Page 61 Assembling the Components of the Main Frame ASSY Installing the full cutter sensor PRO ASSY, cutter motor ASSY, and cutter ASSY Fit the actuator into the hole provided in the chassis ASSY 2300 and turn it clockwise. Secure the full cutter sensor PRO ASSY to the chassis ASSY 2300 with screw “c”. Tightening torque: 147±49 mN•m (1.5±0.5 kgf•cm) Secure the cutter motor ASSY with two screws “b”...
  • Page 62 Installing the cutter sensor folder ASSY and cutter ASSY WARNING: Take care not to touch the cutter of the cutter ASSY. Secure the cutter ASSY to the chassis ASSY 1850 with screws“b”. Tightening torque: 588±98 mN•m (6±1 kgf•cm) Hook the spring as shown below. Make sure that the cutter ASSY is fittes on the side of the chassis ASSY 1850 without any gap.
  • Page 63 Installing the DC motor ASSY Install the DC motor ASSY to the chassis ASSY with two screws, taking care not to damage the gear. Tightening torque: 147±49 mN•m (1.5±0.5 kgf•cm) DC motor ASSY Screw Chassis ASSY Screw Fig. 3.2-15 Installing the DC Motor ASSY III-35...
  • Page 64 Installing the head ASSY, roller holder ASSY, and roller holder release rod, roller release lever Secure the head ASSY to the main frame ASSYwith screw. Tightening torque: 490±98 mN•m (5±1 kgf•cm) Apply half of a rice-sized pinch of grease (Silicon grease G501) to the roller holder ASSY (slideway for the roller holder release rod).

  • Page 65: 8 ] Installing The Bottom Cover

    [ 8 ] Installing the Bottom Cover Connect the power supply harness to the main PCB unit. Align the front edge of the bottom cover with that of the upper cover, then push down the bottom cover until it snaps into place. Note: Take care not to pinch the cords between those covers.
  • Page 66 Secure the bottom cover with four screws. Tightening torque: 392±98 mN•m (4±1 kgf•cm) (PT-1900/1910) Screws Bottom cover Screws (PT-1850) Screws Bottom cover Screws Fig. 3.2-18 Installing the Bottom Cover (2) III-38...

  • Page 67: 9 ] Installing The Cassette Cover

    [ 9 ] Installing the Cassette Cover Place the machine rightside up. Lift up the roller release lever. Hold the cassette cover at an angle shown below and slide down its hinges until they become fitted into the bottoms of the grooves provided in the bottom cover. Close the cassette cover.

  • Page 68: 10 ] Installing The Tape Cassette And Tape Separator Stick

    [ 10 ] Installing the Tape Cassette and Tape Separator Stick Fully open the cassette cover. The roller release lever pops up. Insert the tape separator stick into the right side of the main body. Load a tape cassette. Close the cassette cover. (The roller holder ASSY will be pressed against the head.) (PT-1900/1910) Hook Tape separator stick...

  • Page 69: 11 ] Loading Batteries And Installing The Battery Lid

    [ 11 ] Loading Batteries and Installing the Battery Lid Load batteries. Fit the front end of the battery lid into the bottom cover and push down the lid. Batteries Bottom cover Bottom cover Battery Lid Fig. 3.2-21 Loading Batteries and Installing the Battery Lid III-41...

  • Page 70: 12 ] Demonstration Print And Final Check

    [ 12 ] Demonstration Print and Final Check Starting the Inspection Mode First, press the “ON/OFF” key while pressing the “Code” and “R” keys, and release the “ON/OFF” key, then “Code” and “R” keys so that the RAM is cleared, and the machine performs normally.
  • Page 71 2.1.1 Country Display The country display shows the country specification as designated by the solder points (1 to Country LCD Display Solder Points Specification Specification U.S.A./CAN/AUS U.K. GERMAN FRENCH BELGIUM 2.1.2 Head Rank Display The head rank shows the rank as designated by the solder points (A to C). The “B”...
  • Page 72 The LCD check 2 as shown in Fig. 6 is displayed by pressing the “ ” key. (All guidance is ON.) All guidance on Fig. 6 Shift to “2.2. Cassette Sensor Inspection Mode” by pressing the “ ” key. (Fig.7 display) 2.2 Cassette Sensor Inspection Mode The display as shown in Fig.7 is indicated by pressing the “...
  • Page 73 Press the “Print” key, (1 row) L R, (2 row) R L, (3 row) L R, (4 row) R row) L R in this order. The key to be pressed is displayed on the LCD (Fig.10 display), and the key to be pressed next is displayed if pressing the key correctly.
  • Page 74 2.4 Cut Mode The display as shown in Fig.14 is indicated by pressing the “ ” key or “4” key in the display of Fig.13. Fig. 14 The display as shown in Fig.15 is indicated by pressing the “ ” key, and the tape is fed. After the tape is fed, cut the tape automatically (or manually).
  • Page 75 2.5 Print 1 Mode The display as shown in Fig.18 is indicated by cutting the tape or pressing the “5” key in the display of Fig.17. Fig. 18 Printing is started by pressing the “ ” key. (Fig.18 display) After printing, all memory is initialized, and the power is turned OFF. 87.2±4.4mm 61.2±3.1mm Fig.

  • Page 76: Chapter Iv Troubleshooting And Error Message

    CHAPTER TROUBLESHOOTING AND ERROR MESSAGE 4.1 TROUBLESHOOTING This section gives the service personnel some of the troubleshooting procedures to be followed if an error or malfunction occurs with this machine. It is impossible to anticipate all of the possible troubles which may occur in future and determine the troubleshooting procedures, so this chapter covers some sample troubles.

  • Page 77: Troubleshooting Flows

    4.1.3 Troubleshooting Flows [ 1 ] Tape feeding failure IV - 2...
  • Page 78 IV - 3...

  • Page 79: 2 ] Printing Failure

    [ 2 ] Printing failure IV - 4...
  • Page 80 IV - 5...

  • Page 81: 3 ] Powering Failure (Nothing Appears On The Lcd

    [ 3 ] Powering failure (Nothing appears on the LCD.) IV - 6...
  • Page 82 IV - 7...

  • Page 83: 4 ] No Key Entry Possible

    [ 4 ] No key entry possible IV - 8...

  • Page 84: 5 ] Tape Cutting Failure

    [ 5 ] Tape cutting failure IV - 9...

  • Page 85: 6 ] Abnormal Lcd Indication

    [ 6 ] Abnormal LCD indication IV - 10...

  • Page 86: 7 ] Tape Cassette Type Not Identified

    [ 7 ] Tape cassette type not identified IV - 11...

  • Page 87: Error Message

    4.2 ERROR MESSAGE 4.2.1 Error Message List The error message list is shown as follows. Error Conditions Display U.K./BELGIUM FRENCH GERMAN U.S.A./ CANADA AUSTRALIA When the power is ON PROBLEME ROM - PROBLÈME (CODE+K): PROBLEM! ROM! FEHLER! PROBLEM! ROM! Check system finds any problem in the ROM.
  • Page 88 Error Conditions Display U.K./BELGIUM FRENCH GERMAN U.S.A./ CANADA AUSTRALIA While printing: REPLACE REMPLACER BATTERIEN REPLACE REMPLACER The batteries are empty. BATTERIES! PILES! WECHSELN! BATTERIES! PILES! (The message is displayed while printing.) <Supplement> After the message is disappeared, the machine returns to the text input mode.
  • Page 89 Error Conditions Display U.K./BELGIUM FRENCH GERMAN U.S.A./ CANADA AUSTRALIA Symbol input mode: BUFFER MEMOIRE SPEICHER BUFFER MÉMOIRE When pressing the “Set” FULL! PLEINE! VOLL! FULL! PLEINE! The text buffer memory is full. <Supplement> After the message is disappeared, the machine returns to the text input mode.
  • Page 90 Error Conditions Display U.K./BELGIUM FRENCH GERMAN U.S.A./ CANADA AUSTRALIA Text input mode: LINE TROP MAX. # # # # # # # # # # # # # # # # # # # # When pressing the # # # # # # # # # # # # # # # # # # # # LIMIT! LIGNES!
  • Page 91 Error Conditions Display U.K./BELGIUM FRENCH GERMAN U.S.A./ CANADA AUSTRALIA Function select mode: BUFFER MEMOIRE SPEICHER # # # # # # # # # # # # # # # # # # # # When pressing the “Set” # # # # # # # # # # # # # # # # # # # # EMPTY! VIDE!
  • Page 92 Error Conditions Display U.K./BELGIUM FRENCH GERMAN U.S.A./ CANADA AUSTRALIA Function select mode: TAPE BAND # # # # # # # # # # # # # # # # # # # # When pressing the “Set” # # # # # # # # # # # # # # # # # # # # EMPTY! RUBAN!
  • Page 93 Error Conditions Display U.K./BELGIUM FRENCH GERMAN U.S.A./ CANADA AUSTRALIA Final number setting TEXT TOO TROP TEXT TEXT TROP mode: LONG! LONG! LANG! TOO LONG! LONG! When pressing the “Print” or “Set” keys The text length is longer than the label length to be set.
  • Page 94 Error Conditions Display U.K./BELGIUM FRENCH GERMAN U.S.A./ CANADA AUSTRALIA Function select mode: LINE TROP ZUVIELE # # # # # # # # # # # # # # # # # # # # When pressing the “Set” # # # # # # # # # # # # # # # # # # # # LIMIT! LIGNES!
  • Page 95 Error Conditions Display U.K./BELGIUM FRENCH GERMAN U.S.A./ CANADA AUSTRALIA Tab setting mode: LENGTH LONGUEUR LENGTH LONGUEUR When pressing the “Set” LIMIT! LIMITE! LANG! LIMIT! LIMITÉE! The setting you try to set is out of the possible range. (Out of the specified range) Function select mode: # # # # # # # # # #...
  • Page 96 Error Conditions Display U.K./BELGIUM FRENCH GERMAN U.S.A./ CANADA AUSTRALIA Text input mode: KEINE When pressing the FILES! FICHIER! PHRASE! FILES! FICHIER! “Recall” key No file is registered in the text memory. Text input mode: When pressing the “M. DEL” key No file is registered in the text memory.
  • Page 97 Error Conditions Display U.K./BELGIUM FRENCH GERMAN U.S.A./ CANADA AUSTRALIA * To recover from the CUTTER ERREUR MESSER CUTTER ERREUR error, turn the power ERROR! COUPE! FEHLER! ERROR! COUPE! OFF/ON. The error has priority over the no tape error. Text input mode: TAB .
