FEB27T7DC.eps CFEB30T7DCA.eps BUFEB27T6DSB.eps BLFEB27T6DSB.eps
DFEB30T7DCA.eps
318046119.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FEB27T7DCB
37054781F40S2
Series
27" double
Color
stainless
Market
North America
Wiring Diagram
318046119
Owner's Guide
318200924
Installation Instructions 318201514
Timer Guide
318200132
Publication No.
5995455267
05/12/05
(EN/SERVICE/ECL)
377
DOUBLE ELECTRIC
WALL OVEN
Model No.
FEB27T7D
©
Copyright
2005 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Table of Contents
Related Manuals for Frigidaire FEB27T7DCB
Summary of Contents for Frigidaire FEB27T7DCB
-
Page 1: Wall Oven
U p p er O ven Low er O ven Speed Bake O vens Speed Speed Bake Cl ear Speed Speed Bake Cl ear Bake Bake bake cl ean ti m e / Off bake cl ean ti m e / Off Control s Control s... -
Page 2: Control Panel
Publication No: 5995455267 FEB27T7DCB CONTROL PANEL 12/05... - Page 3 FEB27T7DCB Publication No: 5995455267 CONTROL PANEL POS. NO PART NO. DESCRIPTION 318257301 Shield, oven top 318260102 Cover, box 318271508 Control Panel Assembly, steel/glass, stainless/black, w/touch pad 20 # 316429704 Control, electronic, 5800W2, dual oven 316021107 Screw, hex head, 8-32, silver 318262900 Bracket, control mtg., (2) 316429800...
-
Page 4: Upper Oven
Publication No: 5995455267 FEB27T7DCB UPPER OVEN 12/05... - Page 5 FEB27T7DCB Publication No: 5995455267 UPPER OVEN POS. NO PART NO. DESCRIPTION 318259210 Back, main 318258910 Shield, insulation, upper 318262602 Rack, oven, (2) 5303317977 Pan, broiler 5303317976 Insert, broiler pan 12 # 318089917 Switch, light 318224000 Receptacle, oven light 318268099 Insulation, oven light 5303013071 Bulb/Lamp, light 3201911...
-
Page 6: Lower Oven
Publication No: 5995455267 FEB27T7DCB LOWER OVEN 12/05... - Page 7 FEB27T7DCB Publication No: 5995455267 LOWER OVEN POS. NO PART NO. DESCRIPTION 318259210 Back, main 318258910 Shield, insulation, upper 318262602 Rack, oven, (2) 12 # 318089917 Switch, light 318224000 Receptacle, oven light 318268099 Insulation, oven light 5303013071 Bulb/Lamp, light 3201911 Cover, oven light, glass 5304400195 Retainer, light cover 318147411...
- Page 8 Publication No: 5995455267 FEB27T7DCB DOORS 12/05...
- Page 9 FEB27T7DCB Publication No: 5995455267 DOORS POS. NO PART NO. DESCRIPTION 318260401 Trim, oven door, side, (2) 318262101 Cover, rear door, black, (2) 318260510 Baffle, door 318285057 Insulation, oven door 318212200 Glass, oven door, heat barrier 318259615 Liner, upper door 5304400794 Screw, handle mtg, 10-32 x 3/4 318053125 Seal, door...
-
Page 10: Wiring Diagram
Publication No: 5995455267 FEB27T7DCB WIRING DIAGRAM 12/05...
