Black Widow BW 3650 Owner's Manual

5-BUTTON / 6 RELAY SERIES
VEHICLE SECURITY SYSTEM
Button 1
Button 3
5-Button
Transmitter
Standard Features:
Status indicator (green LED)
Valet / override switch
Multi-tone siren
Dual stage impact detector
Remote panic
Remote chirp mute
Remote sensor/trigger bypass
Passive or active arming
Optional Features:
Flashing parking lights
Starter disable
Keyless entry
Remote trunk or hatch release
Illuminated entry
Hood and trunk protection
Remote auto start
Power window roll up
Back-up battery w/charging circuit
Glass break sensor
Plug-in radar sensor
Note: Some features may require additional parts
and labor, and may not be appropriate for certain
vehicles. Consult your authorized dealer.
Owner's Manual

System Operation

Button 2
ARMING OPERATION
Button 5
To arm the system press transmitter button 1:
Button 4
• The siren will chirp once.
• The parking lights will flash once.*
• The doors will lock.*
• The LED will turn solid for 10 seconds
then start flashing slowly.
seconds the system is armed.
After Arming, if the system detects a bad sensor
or an open zone, the siren will chirp 4 times to
indicate a zone is open. The system will ignore
that input, but keep all other areas protected.
While the system is Armed, the system will
trigger if:
• The doors are opened.
• The shock sensor detects an impact to
the vehicle.
• An optional sensor is disturbed.
• The hood or trunk is opened.
When triggered, the siren will sound, the horn
will honk, and the parking lights will flash. If the
system is triggered by the ignition, doors, hood,
or trunk, the system will alarm for 30 seconds.
If the same input triggers the system 4 times
during a single arming cycle,the system will bypass
that input, keeping the other zones protected,
until the next time the system is armed.
If the shock sensor detects a light impact to the
car or the radar sensor detects an exterior
zone disturbance, the system win sound 5
chirps to warn away the potential intruder.
*
Optional Feature
1
After 10
