Behringer EURORACK UB1204-PRO User Manual page 14

14
EURORACK UB1204FX-PRO/UB1204-PRO User Manual
EQ Mono Channels
Low
Mid
High
EQ Stereo Channels
Low
Mid
High
Aux Sends
Type
Impedance
Max. output level
Stereo Aux Returns
Type
Impedance
Max. input level
Main Outputs
Type
Impedance
Max. output level
Control Room Outputs
Type
Impedance
Max. output level
Headphones Output
Type
Max. output level
DSP
Converter
Sampling rate
80 Hz / ±15 dB
2.5 kHz / ±15 dB
12 kHz / ±15 dB
80 Hz / ±15 dB
2.5 kHz / ±15 dB
12 kHz / ±15 dB
1/4" TS connector, unbalanced
approx. 120 Ω
+22 dBu
1/4" TRS connector,
electronically balanced
approx. 20 kΩ bal. / 10 kΩ unbal.
+22 dBu
XLR, electronically balanced
approx. 240 Ω bal. / 120 Ω unbal.
+28 dBu
1/4" TS connector, unbal.
approx. 120 Ω
+22 dBu
1/4" TRS connector, unbalanced
+19 dBu / 150 Ω (+25 dBm)
24-bit Texas Instruments
24-bit Sigma-Delta,
64/128-times oversampling
40 kHz
Main Mix System Data 2
Noise
Main mix @ -∞,
Channel fader @ -∞
Main mix @ 0 dB,
Channel fader @ -∞
Main mix @ 0 dB,
Channel fader @ 0 dB
Power Supply
Mains voltage
Power consumption
Fuse
Mains connection
Physical
UB1204FX-PRO
Dimensions (H x W x D)
Weight (Net)
UB1204-PRO
Dimensions (H x W x D)
Weight (Net)
Measuring conditions:
1: 1 kHz rel. to 0 dBu; 20 Hz - 20 kHz; line input; main output; unity gain.
2: 20 Hz - 20kHz; measured at main output. Channels 1 - 4 unity gain; EQ flat; all channels on main mix;
channels 1/3 as far left as possible, channels 2/4 as far right as possible. Reference = +6 dBu.
BEHRINGER is constantly striving to manintain the highest professional standards. As a result of these efforts,
modifications may be made from time to time to existing products without prior notice. Specifications and
appearance may differ from those listed or illustrated.
-105 dB / -108 dB A-weighted
-95 dB / -97 dB A-weighted
-82.5 dB / -85 dB A-weighted
100 to 240 V~, 50/60 Hz
40 W
100 - 240 V ~: T 1.6 A H
Standard IEC receptacle
approx. 3 7/8 x 9 11/16 x 13 5/32"
approx. 97 x 247 x 334 mm
approx. 8.6 lbs / 3.9 kg
approx. 3 7/8 x 9 11/16 x 13"
approx. 97 x 247 x 328 mm
approx. 8.1 lbs / 3.7 kg
