COOL MODEL
ROOM AIR CONDITIONER
WALL MOUNTED TYPE
Indoor Unit
ASTA18JCC
ASTA24JCC
ASTA30JCC
ASTA34JCC
Outdoor Unit
AOTR18JCC
AOTR24JCC
AOTR30JCT
AOTR34JCT
KEEP THIS OPERATION MANUAL
FOR FUTURE REFERENCE
FUJITSU GENERAL LIMITED
07H093_9315345141-01_En_cover
1
OPERATING MANUAL
R410A
REFRIGERANT
This Air Conditioner contains and operates
with refrigerant R410A and Polyol Ester oil.
THIS PRODUCT MUST ONLY BE INSTALLED OR SERVICED
BY QUALIFIED PERSONNEL.
Refer to Commonwealth, State, Territory and local legislation,
regulations, codes, installation & operation manuals, before
the installation, maintenance and/or service of this product.
2007.08.10, 16:08
P/N9315345141-01
Advertisement
Table of Contents
Related Manuals for Fujitsu ASTA18JCC
Summary of Contents for Fujitsu ASTA18JCC
-
Page 1: Operating Manual
BY QUALIFIED PERSONNEL. Refer to Commonwealth, State, Territory and local legislation, regulations, codes, installation & operation manuals, before KEEP THIS OPERATION MANUAL the installation, maintenance and/or service of this product. FOR FUTURE REFERENCE FUJITSU GENERAL LIMITED P/N9315345141-01 07H093_9315345141-01_En_cover 2007.08.10, 16:08... -
Page 2: Table Of Contents
CONTENTS SAFETY PRECAUTIONS .......... 1 ADJUSTING THE DIRECTION OF FEATURES AND FUNCTIONS ......... 2 AIR CIRCULATION ..........10 NAME OF PARTS ............4 SWING OPERATION ..........11 PREPARATION ............5 CLEANING AND CARE ........... 12 OPERATION .............. 6 TROUBLESHOOTING ..........14 TIMER OPERATION .......... -
Page 3: Features And Functions
FEATURES AND FUNCTIONS INVERTER REMOVABLE OPEN PANEL At the start of operation, a large power is used to bring the The indoor unit’s Open Panel can be removed for easy clean- room quickly to the desired temperature. Afterwards, the ing and maintenance. unit automatically switches to a low power setting for eco- nomic and comfortable operation. - Page 4 Fig. 1 Fig. 2 Fig. 3 Fig. 5 Fig. 4 Fig. 6 Fig. 7 To facilitate explanation, the accompanying illustra- tion has been drawn to show all possible indicators; in actral operation, however, the display will only show those indicators appropriate to the current op- eration.
-
Page 5: Name Of Parts
NAME OF PARTS Fig. 1 Indoor Unit Fig. 6 Remote Control Unit 1 Operating Control Panel (Fig. 2) J SLEEP button 2 MANUAL AUTO button K MODE button ● L SET TEMP. button ( When kept on pressing the MANUAL M Signal Transmitter AUTO button for more than 10 seconds, the forced cooling operation will start. -
Page 6: Preparation
PREPARATION Load Batteries (R03/LR03 × × × × × 2) CAUTION! ● Take care to prevent infants from accidentally swallowing batteries. Press and slide the battery compartment lid on the re- ● When not using the Remote Control Unit verse side to open it. for an extended period, remove the batteries to avoid possible leakage and Slide in the direction of the arrow while pressing the... -
Page 7: Operation
OPERATION To Select Mode Operation Press the START/STOP button (Fig.6 Q). The indoor unit’s OPERATION Indicator Lamp (red) (Fig. 3 5) will light. The air conditioner will start operating. Press the MODE button (Fig.6 K) to select the desired mode. MODE Each time the button is pressed, the mode will change in the following order. - Page 8 To Stop Operation Press the START/STOP button (Fig. 6 Q). The OPERATION Indicator Lamp (red) (Fig. 3 5) will go out. About AUTO CHANGEOVER Operation ● When AUTO CHANGEOVER operation first selected, the fan will oper- AUTO: ate at very low speed for about one minute, during which time the unit detects the room conditions and selects the proper operating mode.
-
Page 9: Timer Operation
TIMER OPERATION Before using the timer function, be sure that the Remote Control Unit is set to the correct current time (☞ P. 5). To Use the ON timer or OFF timer Press the START/STOP button (Fig. 6 Q) To Cancel the Timer Use the TIMER button to select “CANCEL”. -
Page 10: Sleep Timer Operation
SLEEP TIMER OPERATION Unlike other timer functions, the SLEEP timer is used to set the length of time until air conditioner operate is stopped. To Use the SLEEP Timer To Cancel the Timer: While the air conditioner is operating or stopped, press the Use the TIMER MODE button to select SLEEP button (Fig. -
Page 11: Adjusting The Direction Of Air Circulation
ADJUSTING THE DIRECTION OF AIR CIRCULATION ● Adjust the up, down, left, and right AIR directions with the AIR DIRECTION buttons on the Remote Control Unit. ● Use the AIR DIRECTION buttons after the Indoor Unit has started operating and the airflow-direction louvers have stopped moving. -
Page 12: Swing Operation
SWING OPERATION Begin air conditioner operation before performing this procedure. To select SWING Operation Press the SWING button (Fig. 6 T). The SWING Display (Fig. 7 b) will light. Each time the SWING button is pressed, the swing operation will change in the following order. -
Page 13: Cleaning And Care
CLEANING AND CARE ● Before cleaning the air conditioner, be sure to turn it off and disconnect the Power Supply Cord. CAUTION! ● Be sure the Intake Grille (Fig. 1 8) is installed securely. ● When removing and replacing the air filters, be sure not to touch the heat exchanger, as per- sonal injury may result. - Page 14 CLEANING AND CARE Air Cleaning Filter Installation Replacing dirty Air cleaning filters Replace filters with the following components (purchased 1. Open the Intake Grille and remove the Air separately). filters. ● POLYPHENOL CATECHIN AIR CLEANING FILTER : UTR-FA13-1 ● Negative air ions deodorizing filter: UTR-FA13-2 1.
-
Page 15: Troubleshooting
TROUBLESHOOTING In the event of a malfunction (burning smell, etc.), immediately stop operation, turn off the elec- WARNING! trical breaker or disconnect the power supply plug, and consult authorized service personnel. Merely turning off the unit’s power switch will not completely disconnect the unit from the power source. -
Page 16: Operating Tips
TROUBLESHOOTING Symptom Items to check See Page ● Is the Power Supply Plug disconnected its outlet? CHECK ONCE Doesn’t operate at all: MORE ● Has there been a power failure? — ● Has a fuse blown out, or a circuit breaker been tripped? ●... - Page 17 OPERATING TIPS Temperature and Humidity Range Dry Mode Cooling Mode Outdoor temperature About 18 to 46 °C About 18 to 46 °C Indoor temperature About 18 to 32 °C About 18 to 32 °C ● If the air conditioner is used under higher temperature conditioner than those listed, the built-in protection circuit may operate to prevent internal circuit damage.
