Korg X5DR AI2 SYNTHESIS MODULE Owner's Manual page 141

Reference Guide
23: Harmonic Chorus
This effect splits the signal into two bands:
HF (high frequency) and LF (low
frequency). The HF band is then fed to the
quadrature type chorus, and the LF band is
fed directly to the output. This effect is useful
for low frequency instruments such as bass.
17A Harmo.Cho
D1T004 D2T012
LCD
Delay Time1 (D1T)
17A
Delay Time 2 (D2T)
Mod Depth (Mod)
17B
Mod Speed (ModSP)
Frequency Split Point
17C
(F.Split Point)
For effect 23, dynamic modulation (16C) can be used to control the Mod Speed.
128
ø 17B Harmo.Cho ø
Mod99 ModeSP=35
17A 17B
Parameter Range
0–500 ms
0–500 ms
0–99
1–99
0–18
Left
Split
Mod
Split
Right
ø
17C Harmo.Cho
F.Split Point=01
17C
Channel 1 delay time
Channel 2 delay time
Modulation depth
Modulation speed
The frequency at which the input signal is split into HF and LF
bands
Mix
LF
Chorus 1
HF
Chorus 2
Chorus 1
HF Chorus 2
LF
Mix
Description
