4. Making connections

Before you make connections, be sure to turn off the power of your other equipment, or turn the volume down to
zero. Connecting cables are sold separately.
Hard disk recorder etc.
Mono output - mono 1/4" jack/stereo
output - two mono 1/4" jacks
Guitar amp / powered monitor (*1)
Mono 1/4" jack - mono 1/4" jack
AC adapter (*2) to AC outlet
*1: The OUTPUT/PHONES jack is a stereo output. If you use a mono phone cable to connect the AX1G to a
guitar amp, only the L (left) sound will be output.
*2: If you use batteries, the AC adapter is not necessary. If you use an AC adapter, be sure to use only the
specified model (DC9V
OUTPUT/PHONES
DC9V
).
Audio system
Stereo 1/4" jack - stereo RCA
(phone) jack
Headphones (*1)
Mono 1/4" jack - mono 1/4" jack
INPUT
Introduction
Guitar
9
