NOX1010/NOX606
NOX404/NOX303
NOX202
NOX404 Front Panel
NOX404 Rear Panel
POWER switch
XFADE CURVE
knob adjusts fade
steepness between
source A and B
REV button MODE button
switches selects
assignment between
of signals at XFADE
either side of CURVE A or B
crossfader
Stereo FX
LOOP SEND
jacks to external
FX device(s)
(1/4" TRS, Stereo AUX
balanced) OUT jacks (RCA)
IEC POWER Stereo FX LOOP
socket RETURN jacks
from external FX
device(s) (1/4" TRS,
balanced)
Stereo AUX IN PHONO/LINE
jacks (RCA) source switch
USB socket MAIN
OUTPUTS
(RCA)
Headphones jack
PHONO LINE PHONO
ground INPUTs INPUTs
terminal (RCA) (RCA)
MAIN MIC input
OUTPUTS (1/4" TRS,
(XLR) balanced)
