NOX1010/NOX606
NOX404/NOX303
NOX202
6 Line and USB inputs, 4 Phono/Line
plus 2 Mic/Line inputs—all channels
with Gain control, switchable EQ and
level meter
2 XENYX mic preamps with
"corrective" EQs and 4 premium
phono preamps for superior detail
and ultimate punch
Powerful "asymmetric" 4-band EQs on
all line channels with +6 dB boost to
preserve headroom and -26 dB cut
for creative mixing
VCA-controlled faders for utmost
reliability and noise-free performance
2 stereo Aux sends selectable
pre-/post-fader on all channels
2 balanced mix XLR outputs with
Level control, secondary "music only"
outputs for recording plus post fader
mono output
Sophisticated Monitor section
includes 2 Headphone outputs,
split cue, mix to cue balance and post
EQ switch
Rack mount brackets included for
ultimate flexibilit
NOX1010: Premium 5-Channel 19" DJ
Mixer with infinium "Contact-Free" VCA
Crossfader, Beat-Syncable FX and USB/
Audio Interface
Premium 5-channel club DJ mixer for
the most demanding turntablist,
remixer and digital DJ
Beat-syncable FX section with
2 parameter controls assignable to
Mic, 1, 2, CFA, CFB or Master
Awesome 3-band EQ with full-kill
filters plus 8-element level meters
with peak hold function per channel
NOX202 Top Panel
FX ON FREQUENCY
button knob adjusts
MIC EQ activates effect's
knobs adjust digital frequency or
channel effects time-based
equalization processor parameter
MIC GAIN MIC ON GAIN knob
knob controls button controls
sensitivity of
channel input
mic input sensitivity
INPUT CHANNEL EQ
SELECT knobs boost/
switch selects cut high,
channel mid and low
audio source frequencies
KILL buttons CHANNEL
remove high, FADER
mid and low controls
frequencies volume of
from A or B channel in
crossfader mix overall mix
TAP button FX ASSIGN
allows knob
effect's determines
tempo which
parameter to sources are
be manually affected
entered by effect
FX
INTENSITY FX SELECT
DISPLAY fader adjusts knob scrolls
indicates effect's mix through
selected or resonance available
effect parameter effects,
pressing knob
confirms
selection
XFADE
CF REVERSE CURVE knob
button adjusts fade
reverses steepness
assignment between
of crossfader source A
signals and B
CROSSFADER
fades
between
sources
assigned to
either side
Page 4 of 20
CUE MODE
MASTER switch
knob determines
controls whether
RCA channels 1 and
MAIN and 2, FX, or Master
BALANCED signal are
OUTPUT heard in cue/
level headphone mix
CUE GAIN CUE MIX
knob adjusts fader allows
cue signal gradual
volume and blend
sensitivity between
channel 1
and 2
CHANNEL
VU METER
displays
input source
signal level
MASTER
VU METER
displays
master
output and/
or cue signal
level
