SPLIT TYPE
ROOM AIR CONDITIONER
WALL MOUNTED TYPE
Indoor unit
ASYB24LDC
ASYB24LDC
CONTENTS
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . 1
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . . . 2
REFRIGERANT SYSTEM DIAGRAM . . . . . 3
CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . . . . 4
INDOOR PCB CIRCUIT DIAGRAM . . . . . .
OUTDOOR PCB CIRCUIT DIAGRAM . . . .
ERROR CONTENTS . . . . . . . . . . . . . . . . .
DISASSEMBLY ILLUSTRATION . . . . . . . . 14
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . . . 20
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . .
Outdoor unit
AOYS24LDC
AOYS24LDL
5
8
13
22
Advertisement
Table of Contents
Related Manuals for Fujitsu AOYS24LDL
Summary of Contents for Fujitsu AOYS24LDL
-
Page 1: Table Of Contents
SPLIT TYPE ROOM AIR CONDITIONER WALL MOUNTED TYPE Indoor unit Outdoor unit ASYB24LDC AOYS24LDC ASYB24LDC AOYS24LDL CONTENTS SPECIFICATIONS ..... 1 DIMENSIONS . -
Page 2: Specifications
SPECIFICATIONS NOISE LEVEL ASYB24LDC Cool 49 dB / Heat 48 dB HIGH INDOOR UNIT OUTDOOR UNIT AOYS24LD_ Cool 43 dB / Heat 42 dB INDOOR UNIT 7.10 kW Cool 38 dB / Heat 37 dB COOLING CAPACITY 8.10 kW QUIET Cool 33 dB / Heat 33 dB HEATING CAPACITY Cool 52 dB / Heat 54 dB... - Page 3 OUTLINE AND DIMENSIONS Unit : mm INDOOR UNIT OUTDOOR UNIT 2006.06.26...
-
Page 4: Refrigerant System Diagram
REFRIGERANT SYSTEM DIAGRAM Heat exchanger ( INDOOR ) 3-Way valve 2-Way valve Muffler 4-Way valve Strainer Expansion valve Heat exchanger Strainer ( OUTDOOR ) Strainer Cooling Heating Refrigerant pipe diameter Liquid : 1/4" (6.35 mm) Gas : 5/8" (15.88 mm) 2006.10.05... -
Page 5: Circuit Diagram
CIRCUIT DIAGRAM INDOOR UNIT CONTROLLER PCB ASSY BLUE OUTDOOR UNIT YELLOW WHITE TEST BLACK PIPE TEMP. THERMISTOR FAN MOTOR BLACK BLUE BLACK PINK STEP MOTOR OUTDOOR TEMP. ( DIFFUSER ) WHITE YELLOW BLUE THERMISTOR CN62 BLUE CN42 CN40 CN200 CN400 ORANGE 1 2 3 4 1 2 3 4 5 6 7 8 910... - Page 6 PCB Circuit Diagrams not available at time of publication...
-
Page 7: Error Contents
ERROR CONTENTS Display Error Error Operation Timer LED 2 flash Serial signal (reverse) error, at operation start up 3 flash Serial signal (reverse) error, during oeration Serial signal error Normal 4 flash Serial signal (forward) error, at operation start up 5 flash Serial signal (forward) error, during operation 8 flash... -
Page 8: Disassembly Illustration
DISASSEMBLY ILLUSTRATION INDOOR UNIT 2006.10.18... - Page 11 INDOOR UNIT 2006.10.13...
- Page 12 OUTDOOR UNIT 2006.10.26...
- Page 13 OUTDOOR UNIT 2006.10.13...
-
Page 14: Parts List
PARTS LIST INDOOR UNIT Descriprion Part No Front Panel 9314991042 Intake Grille Assy 9315336071 Air Filter 9315014016 Clamper Grille 9306755010 Receiver Window 9315010018 Air Cleaner Assy 9313148041 Crossflow Fan Assy 9315024015 Bearing C Assy 9306628017 Casing Assy 9315331014 R and L Louver 9311997016 Spacer B 9312441013... - Page 15 OUTDOOR UNIT Description Parts No. Top Panel Assy 9309230064 Cabinet Sub Assy 9314809019 Blow Grill 9308884015 Cabinet Right Assy 9309236028 Fan Ring 9308885012 Grip 9308880017 Switch Cover Assy 9309237032 4-Way Valve 9900163013 Condenser Assy B 9315303011 Condenser Assy 9315302014 Thermistor Spring A 313728262708 Propeller Fan 9309909014...
-
Page 16: Accessories
ACCESSORIES Name and Shape Part No. Wall hook bracket 9315023018 Remote control 9315027122 Remote control unit holder 9305642045 Battery (penlight) 0600185534 Cloth tape 9310519004 Tapping screw (big) 0700076046 Tapping screw (small) 0700019036 Air cleaning filter 9313275013 Drain pipe 9301102000 2006.10.13... - Page 17 0610G3163...
