Table of Contents

SPLIT TYPE
ROOM AIR CONDITIONER

WALL MOUNTED

Models
Indoor unit
ASYA24LCC
CONTENTS
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . 1
DIMENSIONS . . . . . . . . . . . . . . . . . . . . . . . 2
CIRCUIT DIAGRAM . . . . . . . . . . . . . . . . . 4
ERROR CONTENTS . . . . . . . . . . . . . . . .
DISASSEMBLY ILLUSTRATION . . . . . . . 14
PARTS LIST . . . . . . . . . . . . . . . . . . . . . . . 20
STANDARD ACCESSORIES . . . . . . . . . .
type
Outdoor unit
AOYR24LCC
5
8
13
22

Advertisement

Table of Contents
loading

Related Manuals for Fujitsu AOYR24LCC

Summary of Contents for Fujitsu AOYR24LCC

  • Page 1: Table Of Contents

    Indoor unit Outdoor unit ASYA24LCC AOYR24LCC CONTENTS SPECIFICATIONS ....1 DIMENSIONS ..... . . 2 REFRIGERANT SYSTEM DIAGRAM .

  • Page 2: Specifications

    OUTDOOR UNIT H x W x D WEIGHT INDOOR UNIT Gross / Net OUTDOOR UNIT Gross / Net 2006.03.22 NOISE LEVEL ASYA24LCC AOYR24LCC INDOOR UNIT 7.10 kW 8.10 kW OUTDOOR UNIT 230 V REFRIGERANT CHARGE (R410A) 50Hz 9.7 A FULL CHARGE 9.8 A...
  • Page 3 OUTLINE AND DIMENSIONS Unit : mm INDOOR UNIT OUTDOOR UNIT 2006.06.26...

  • Page 4: Refrigerant System Diagram

    REFRIGERANT SYSTEM DIAGRAM Models : ASYA24LCC / AOYR24LCC Muffler Strainer Cooling Heating Refrigerant pipe diameter Liquid : 1/4" (6.35 mm) Gas : 5/8" (15.88 mm) 2006.02.28 Heat exchanger ( INDOOR ) 3-Way valve 4-Way valve Heat exchanger ( OUTDOOR )

  • Page 6: Indoor Pcb Circuit Diagram

    INDOOR PCB CIRCUIT DIAGRAM Model : ASYA24LCC REMOTE CONTROL UNIT AR-3TA TYPE LOUVER ( RIGHT / LEFT ) LOUVER ( UP / DOWN ) DIFFUSER FAN MOTOR 2006.03.22 CONTROL UNIT EZ-0051KHSE TERMINAL BOARD THERMAL FUSE 102 OUTDOOR UNIT SERIAL EARTH TERMINAL EARTH BLACK WHITE...
  • Page 7 Model : ASYA24LCC POWER SUPPLY CIRCUIT 5D - 11 I C26-14 I C26-10 K1-4 C13 0.01 0.7A - 5.0MH 250V C8 0.47 275V 470V C14 0.01 <TNR> 250V (97) I C2 (96) 470V 470V NJM7805 (76) <TNR> <TNR> T1-12 330/ 330/ <F>...
  • Page 8 Model : ASYA24LCC SLR-325 SLR-325 SLR-325 2006.02.28 INDICATOR PCB ASSY K05CY-0500HSE-D0 D201 D202 C201 D203 <F> I C201 R201 GP1UM261R <1/4W> + C202 CN201...

  • Page 9: Outdoor Pcb Circuit Diagram

    OUTDOOR PCB CIRCUIT DIAGRAM Model : AOYR24LCC UL1015 EMI FILTER AWG14 WHITE POWER SOURCE UL1015 UL1015 AWG14 AC220 - 240V AWG14 BLACK BLACK 50 / 60Hz UL1015 F200 AWG20 TLC 25A - 250V, B UL1015 AWG20 BLACK INDOOR UNIT UL1015...
  • Page 10 Model : AOYR24LCC <1/10W> <1/10W> 2006.02.28 CONTROLLER PCB ASSY K05CU-0500HUE-C1...
  • Page 11 Model : AOYR24LCC 2006.02.28...
  • Page 12 TR PCB ASSY ( I P M ) K05CZ-0500HUE-TR0 Model : AOYR24LCC 2006.02.28...
  • Page 13 Model : AOYR24LCC YELLOW WHITE R200 220K <2W> BLUE VIOLET 2006.02.28 CAPACITOR PCB ASSY K05DG-0500HUE-P0 SMOOTHING CIRCUIT C202 C200 C201 660/ 660/ 660/ 450V 450V 450V POWER_G YELLOW BLUE...

  • Page 14: Error Contents

    Error Serial signal error Indoor unit thermistor error Outdoor unit thermistor error Indoor unit control error Outdoor unit control error Indoor fan motor error Refrigerant cycle error Optional function error Model error 2006.02.28 Display Error Operation Timer LED 2 flash Serial signal (reverse) error, at operation start up 3 flash Serial signal (reverse) error, during oeration...

  • Page 15: Disassembly Illustration

    DISASSEMBLY ILLUSTRATION Model : ASYA24LCC 2006.02.28...
  • Page 18 Model : ASYA24LCC 2006.02.28...
  • Page 19 Model : AOYR24LCC 2006.03.22...
  • Page 20 Model : AOYR24LCC 2006.03.22...

  • Page 21: Parts List

    PARTS LIST INDOOR UNIT Ref No 2006.02.28 Descriprion ASYA24LCC Front Panel Total Assy 9315335012 Intake Grille Assy 9315336019 Air Filter 9315014016 Clamper Grille 9306755010 Receiver Window 9315010018 Crossflow Fan Assy 9315024015 Bearing C Assy 9306628017 Casing Assy 9315331014 R and L Louver 9311997016 Spacer B 9312441013...
  • Page 22 TR PCB Assy ACTPM Fuse Fuse Holder Pulse Motor Valve Assy JNT PIPE(3WV)AS PIPE(COND OLT)AS PIPE(COND ILT)AS Discharge Pipe Assy Chock Coil Parts No. Ord. Q'ty AOYR24LCC 9309230064 9314809019 9308884015 9309236028 9308885012 9308880017 9309237032 9900163013 9900056018 9315303011 9315302014 313728262708 9309909014...

  • Page 23: Standard Accessories

    STANDARD ACCESSORIES Wall hook bracket Remote control unit Remote control unit holder Battery (penlight) Cloth tape Tapping screw (big) Tapping screw (small) Air cleaning filter Air cleaning filter frame Drain pipe 2006.02.28 Name and Shape Part No. 9315023018 9315027139 9305642045 0600185534 9310519004 0700076046...
  • Page 24 0512G2974...
