4. Configurator
Projector's identification
The default display name is Barco followed by the projector type.
This name can be changed to any other name. Click in the name field, select the current name and enter
a new name (b).
Next to the display name, the device type is indicate with the name and a device icon.
Projector status
Indicates the communication status of the projector (c).
•
enabled: communication with projector possible
•
disabled: no communication with projector possible
4.5.3
Set up a Ethernet connection
Possibilities
To establish a Ethernet connection, the following ways are possible:
•
Enter an IP address
•
Enter a host name
•
Scan the net work for the connected projectors
Via entering an IP address
The IP address known :
1. Select the Connection properties tab (a). (image 4-6)
The right pane changes to the connection setup page.
2. Click on the radio button in front of IP address (b).
3. Enter the IP address (c).
Note: An address contains 4 octets with a maximum value of 255.
4. Click OK to make the connection.
Image 4-6
Make connection via entering IP address
Via entering a host name
1. Select the Connection properties tab (a). (image 4-7)
The right pane changes to the connection setup page.
2. Click on the radio button in front of Host name (b).
3. Click in the input field and enter the host name (c).
30
R59770449 DC TOOLSET 15/12/2009
