Indica-
Description
tion
A
Window title. Construction of active module - Configuration name
B
Menu
C
Module navigation buttons
D
Configuration preview pane
E
Log window. Can be hidden by the log information button on top of the configuration preview
pane.
F
Settings pane. Content changes with the selected module button and selected
projector/device.
G
Manage buttons for configurations and snapshots
Tool tip
Some items and or icons show a tool tip when moving the cursor over that item or icon. This tool tip helps
to identify the buttons or items.
Scroll bars
If there is more information available than displayed in a pane, vertical and horizontal scroll bars will be
added to that specific pane. These scroll bars let you move up and down and left and right through the
information in the pane. Vertical scroll bars are the bars on the right side of the pane. Horizontal scroll
bars are the bars at the bottom of the pane.
To use scroll bars, place the cursor on the scroll box, click and hold down the mouse button. Move the
scroll box the entire span of the scroll bar. Notice how you can move and up down in the information in
the pane.
You can also click anywhere above or below (left or right) the scroll box in the empty space. Click once
with the mouse and the scroll bar will make larger leaps in the information.
Split bar
The split bar divides the different panes. The position of the split bar is adjustable.
Image 2-4
Split bar
To adjust the position, place the cursor over the split bar separating the panes, so that the two-headed
arrow cursor appears. Click on the two-headed arrow and drag it until the panes are the desired size.
2.4
Workspace Explorer
Workspace explorer
Window to manage the available configurations in the current workspace.
How to display
Click on the workspace explorer icon (
on the menu, click on View → Workspace explorer or
R59770449 DC TOOLSET 15/12/2009
) on the left top corner or
2. Menus
9
