Altigen Quantum Boards Universal Quick Install Manual

Universal Quick Install Guide
Quantum and Triton Boards
Use this guide to install Quantum boards and Triton class telephony boards,
including Triton VoIP, Triton Analog Extension, Triton Analog Trunk (LS and LS/
GS), Triton Resource, Triton T1/PRI, and Triton T1/E1 PRI, which are all different
boards with common installation procedures.
MVIP Connector
MVIP BUS Termination Switch
Board Silhouette

Minimum System Requirements

•
IBM/PC AT compatible system with adequate number of full-size ISA and PCI
slots
•
Windows NT Server 4.0 with Service Pack 6A or Windows 2000 Server
Recommended AltiServ System Configurations*
Number of CPU Memory
Quantum and/
or Triton
Boards per
System
333 MHz 128 MB
1–3
700 MHz 256 MB
4–6
850+ MHz 512 MB
7–16+
*Individual requirements may vary depending on particular applications. Please contact AltiGen Sales Engineering
or Technical Support for assistance in selecting the most appropriate system configuration for your installation.
Individual Board Power
Board
Quantum
Triton Analog Extension
Triton Analog Trunk LS/GS
Triton Analog Trunk LS
Triton T1/PRI
Triton T1/E1 PRI
Triton VoIP
Triton Resource
Power Cable
Power Supply Hard Disk 5V Requirement
Controller
Single 300W IDE/SCSI
Single 400W or IDE ATA-100/
Dual 400W load SCSI
sharing
recommended
Dual 400W load IDE ATA-100/
sharing required SCSI
5V 12V
1.6A 1.4A
1.6A 1A
1.6A 0.25A
1.6A 0
1.6A 0
1.6A 0
1.6A 0
1.6A 0
12V
Requirement
15A 6A or better
20A 16A
40A 20A
Slot Type
ISA
PCI
PCI
PCI
PCI
PCI
PCI
PCI
