- Page 1 BT2750 USER AND INSTALLATION INSTRUCTIONS...
- Page 2 COOKING THEATRES USER AND INSTALLATION INSTRUCTIONS...
- Page 3 For future reference please record the following information which can be found on the Rating Plate and the date of purchase which can be found in the invoice: Model Number ……………………. Serial Number ……………………. Date of Purchase …………………….
-
Page 4: Table Of Contents
CONTENTS General Information page 4 Warning and Safety Instructions page 5 Instructions for Use pages 6-11 Instructions for Installation pages 12-15 Technical Data pages 16-17 Conditions of Guarantee back cover... -
Page 5: General Information
EMC – 89/336 Gas products – 90/396 Safety Standards – EN 60 335-1, EN 60 335-2-6, EN 30-1-1. As Baumatic have a policy of continued product improvement, the right is reserved to adjust and make any modifications deemed necessary without notification. - Page 6 For gas installations, CORGI registration is strictly required. For electrical installations, NICEIC registration is recommended. Baumatic Ltd declines any responsibility for injury or damage to persons or property as a result of improper use or installation of this appliance. Heat, steam and moisture will be created during use, take care to avoid injury and ensure that the room is adequately ventilated.
-
Page 7: Instructions For Use
USER INSTRUCTIONS INSTRUCTIONS FOR USE These User Instruction should be retained for future reference and for use by a person who is perhaps unfamiliar with the appliance The following models are covered by these instructions: BT2450 BT2750 BT2790 USING THE GAS HOB The symbols on the Control Panel Fascia show which Burner the Control Knob operates. - Page 8 USER INSTRUCTIONS USING THE MAIN ELECTRIC OVEN The oven temperature is controlled by the combined thermostat switch between OFF and 250+°C, depending on the temperature required. The Thermostat Pilot Light switches ON and OFF to indicate temperature control. The mode of cooking desired is selected using the Multifunction Control knob. The functions that can be selected are as follows (these apply to the single oven in model BT2450 and the main oven in models BT2750 and BT2790): OVEN LIGHT...
- Page 9 USER INSTRUCTIONS WARNING • Do not use the oven base as a shelf, only use the wire shelves in any of the positions provided. • Do not use aluminium foil to cover the grill pan, or heat items wrapped in aluminium foil under the grill –...
-
Page 10: Using The Minute Minder
USER INSTRUCTIONS USING THE ANALOGUE CLOCK/PROGRAMMABLE TIMER (BT2450 in Green and Black, BT2750, BT2790) The clock will only operate when the appliance is connected to the electricity supply. 1. TIME OF DAY: Push in and turn the setting knob anti-clockwise. If the ‘Start Time’... -
Page 11: Cooking Guidelines
USER INSTRUCTIONS COOKING GUIDELINES Please refer to the information on food packaging for guidance on cooking temperatures and times. Once familiar with the performance of your appliance, the temperatures and times can be varied to suit personal preferences. Make sure that frozen foods are thoroughly thawed before cooking, unless instructed otherwise. -
Page 12: Removing The Oven Door
USER INSTRUCTIONS REMOVING THE OVEN DOOR To facilitate cleaning the oven, the doors can be removed as follows (see Fig. 3): 1. With the door in the fully open position, swivel the catch on the lower hinge arms and clip them over the hook on each upper hinge arm. -
Page 13: Instructions For Installation
85°C, otherwise a 20mm air gap must be left on either side of the appliance. PRE-COMMISSIONING THE APPLIANCE When unpacked, check that the following parts are included with the appliance: • Baumatic Ltd Instruction and Installation Book. • 3 cast iron pan supports for hob. •... -
Page 14: Gas Connection
INSTALLATION INSTRUCTIONS ADJUSTABLE-LEG AND KICK-PLATE ASSEMBLY To complete the assembly and before fitting the accessories, proceed as follows: 1) Open the warming compartment door and tilt the appliance sufficiently to assemble two legs. 2) Repeat the exercise for the remaining two legs ensuring all four are tightly assembled. 3) Check that the appliance is level and at the correct height. -
Page 15: Electrical Connection
INSTALLATION INSTRUCTIONS ELECTRICAL CONNECTION This appliance must be installed by a competent person (such as one holding NICEIC Registration) and in accordance with the latest edition of the IEE Wiring Regulations. Before connecting the appliance, make sure the supply voltage marked on the Rating Plate corresponds with the mains supply voltage. -
Page 16: Replacing The Oven Light Bulb
During the guarantee period, in case of need all service interventions should be referred back to the Baumatic Ltd Service department. Please note that intervention or repair by any unauthorised personnel will invalidate such guarantee. -
Page 17: Technical Data
TECHNICAL DATA Dimensions: Model BT2450, BT2750 BT2790 Height 922 to 982mm 922 to 982mm Width 898mm 1000mm Depth 600mm (excl. door handles) 600mm (excl. door handles) Electrical Details: Rated Voltage: 230V ac 50Hz Rated Input: BT2750, BT2790 – 30A (Double Pole Isolator with 3mm contact gap) BT2450 –... - Page 18 Gas Hob Jet sizes: (Natural/LPG) Model Type of burner Large Medium Small Fish BT2450 1.1/0.75 0.95/0.6 0.7/0.5 1.5/1.0 1.3/0.88 BT2750 1.1/0.75 0.95/0.6 0.7/0.5 1.5/1.0 1.3/0.88 BT2790 1.1/0.75 0.95/0.6 0.7/0.5 1.5/1.0 1.3/0.88 Hob Primary Air gap mm: (Natural/LPG) Type of burner Model Large Medium...
-
Page 19: Conditions Of Guarantee
The conditions of the guarantee which applies to your Baumatic appliance are as follows: All ‘Work’ in relation to the Guarantee must be carried out by Baumatic Ltd or an approved service agent of Baumatic Ltd. Any claims made under the terms of the guarantee must be supported by the original invoice / bill of sale issued at the time of purchase.
