Warranty information contained in this User Guide will describe your limited coverage from ViewSonic Corporation, which is also found on our web site at http:// www.viewsonic.com in English, or in specific languages using the Regional selection box in the upper right corner of our website.
Compliance Information NOTE: This section addresses all connected requirements and statements regarding regulations. Confirmed corresponding applications shall refer to nameplate labels and relevant markings on unit. FCC Compliance Statement This device complies with part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Declaration of RoHS Compliance This product has been designed and manufactured in compliance with Directive 2011/65/EU of the European Parliament and the Council on restriction of the use of certain hazardous substances in electrical and electronic equipment (RoHS Directive) and is deemed to comply with the maximum concentration values issued by the European Technical Adaptation Committee (TAC) as shown below: Proposed Maximum Substance...
16. If smoke, an abnormal noise, or a strange odor is present, immediately switch the Zero Client Monitor off and call your dealer or ViewSonic. It is dangerous to continue using the Zero Client Monitor. 17. Do not attempt to circumvent the safety provisions of the polarized or grounding- type plug.
Page 5
20. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the equipment. When a cart is used, use caution when moving the cart/equipment combination to avoid injury from tipping over. 21. Unplug this equipment when it will be unused for long periods of time. 22.
Contents Compliance Information FCC Compliance Statement ...................i Industry Canada Statement ..................i Declaration of RoHS Compliance ................ii Cautions and Warnings ..................iii Copyright Information Product Registration ....................2 For Your Records ....................2 Getting Started Package Contents ....................3 Quick Installation ....................4 Additional Software Installation (Optional).............4 Wall Mounting (Optional) ..................5 Using the Zero Client Monitor Setting the Timing Mode..................8...
VESA is a registered trademark of the Video Electronics Standards Association. DPMS, DisplayPort, and DDC are trademarks of VESA. Disclaimer: ViewSonic Corporation shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product.
Product Registration To fulfill possible future product needs, and to receive additional product information as it becomes available, please visit your region section on ViewSonic’s website to register your product online. For Your Records Product Name: SD-Z225 ViewSonic Zero Client Monitor...
- INF/ICM files* - Registration information - Additional software (Optional) NOTE: The INF file ensures compatibility with Windows operating systems, and the ICM file (Image Color Matching) ensures accurate on-screen colors. ViewSonic recommends that you install both the INF and ICM files.
3. Turn ON Zero Client Monitor Additional Software Installation (Optional) 1. Load the ViewSonic CD on your CD/DVD drive. 2. Double click on the "Software" folder and choose an application, if desired. 3. Double click on the Setup.exe file and follow the onscreen instructions to...
Wall Mounting (Optional) NOTE: For use only with UL Listed Wall Mount Bracket. To obtain a wall-mounting kit or height adjustment base, contact ViewSonic ® your local dealer. Refer to the instructions that come with the base mounting kit. To...
Using the Zero Client Monitor Setting the Timing Mode Setting the timing mode is important for maximizing the quality of the screen image and minimizing eye strain. The timing mode consists of the resolution (example 1024 x 768) and refresh rate (or vertical frequency; example 60 Hz). After setting the timing mode, use the OSD (On-screen Display) controls to adjust the screen image.
Adjusting the Screen Image Use the buttons on the front control panel to display and adjust the OSD controls which display on the screen. Standby Power On/Off MENU/EXIT Displays the Main Menu or exits the control screen and saves adjustments. SOURCE/ENTER Displays the control screen for the highlighted control.
Information displays the timing mode (video signal input) coming from the graphics card in the computer, the LCD model number, the serial number, and the ViewSonic website URL. See your graphics card’s user guide ® for instructions on changing the resolution and refresh rate (vertical frequency).
Page 17
Manual of Zero Client, PCoIP firmware update and PCoIP Management Console Software: 1. Please visit ViewSonic website at www.viewsonic.com to download the user guide of Zero Client and PCoIP firmware updates. 2. The latest version of “PCoIP Management Console Software” can be downloaded free of charge from the Teradici web site.
Other Information Specifications Processor Teradici Tera2321 / Image Performance 50Mpps Random Access 512 MB Memory Type TFT (Thin Film Transistor), Active Matrix 1920 x 1080 LCD, 0.248 mm pixel pitch Display Size Metric: 55 cm Imperial: 21.5” (21.5” viewable) Color Filter RGB vertical stripe Glass Surface Anti-Glare...
Page 19
100 x 100 mm Net weight Physical 9.92 lbs (4.5 kg) (with Stand) Macintosh computers older than G3 require a ViewSonic Macintosh adapter. To order an adapter, contact ® ViewSonic. Do not set the graphics card in your computer to exceed these timing mode; doing so may result in permanent...
Zero Client Monitor screen or case. Some chemical cleaners have been reported to damage the screen and/or case of the Zero Client Monitor. • ViewSonic will not be liable for damage resulting from use of any ammonia or alcoholbased cleaners.
Loose or broken pins in the cable connector could cause an improper connection. • Connect the Zero Client Monitor to another computer. • If you have an older graphics card, contact ViewSonic for a non-DDC adapter. ®...
(Mexico) Renta y Datos, 29 SUR 721, COL. LA PAZ, 72160 PUEBLA, PUE. Tel: 01.222.891.55.77 CON 10 LINEAS Electroser, Av Reforma No. 403Gx39 y 41, 97000 Mérida, Yucatán. Tel: 01.999.925.19.16 Other places please refer to http://www.viewsonic.com/la/soporte/index.htm#Mexico Latin America www.viewsonic.com/la/ T= 0800-54565 soporte@viewsonic.com...
ViewSonic Zero Client products are warranted for (3) years from the first consumer purchase for parts and labor. User is responsible for the back up of any data before returning the unit for service. ViewSonic is not responsible for any data lost.
Page 24
Exclusion of damages: ViewSonic’s liability is limited to the cost of repair or replacement of the product. ViewSonic shall not be liable for: 1. Damage to other property caused by any defects in the product, damages based upon inconvenience, loss of use of the product, loss of time, loss of profits, loss of business opportunity, loss of goodwill, interference with business relationships, or other commercial loss, even if advised of the possibility of such damages.
