Configuring the application

Configuring the application
This guide assumes that the Lexmark Accessibility Solution is already present on at least one multi-function printer
(MFP) on the network. Administrators should use this guide to set up the browser‑based portion of the application.

Setting up user access

Creating a browser shortcut to the Lexmark Accessibility Solution

1
Open the user's default Web browser.
2
From the Web browser, paste the following URL into the address field:
http://127.0.0.1/cgi‑bin/direct/printer/prtapp/apps/LexmarkAccessibilitySolut
ion
3
Replace the IP address in the above URL with the IP address or DNS name of an MFP running the Lexmark Accessibility
Solution.
4
Press Enter.
The home page of the Lexmark Accessibility Solution will open.
5
From the home page of the Lexmark Accessibility Solution, create a bookmark or favorite—depending on the user's
Web browser—and then give it a descriptive name (such as Lexmark X651, or Bob's Printer). That way,
the user can easily navigate back to the MFP running the solution later.
Notes:
• Repeat these steps as necessary for any other MFPs running the Lexmark Accessibility Solution.
•
The Lexmark Accessibility Solution is not designed to be launched from within the Application section of the
Embedded Web Server for the MFP.

Creating a desktop shortcut to the Lexmark Accessibility Solution in Windows

1
Save the LAS‑Win‑Utility.exe file to the C:\Lexmark directory on the user's computer. Create that directory if it does
not already exist.
2
Right-click on an unused area of the Windows Desktop, and then select New > Shortcut.
3
From the Create Shortcut dialog, click Browse.
4
From the Browse for Folder dialog, click Desktop, and then click OK.
5
From the Create Shortcut dialog, click Next.
6
Type a descriptive name for the shortcut, such as Lexmark X651, or Bob's Printer, and then click Finish.
7
Right-click the new shortcut and select Properties from the menu.
