3. HARDWARE SETUP
2) CPU External Frequency Selection (DIP_SW Switches 5–8)
This option tells the clock generator what frequency to send to the CPU, DRAM,
and the PCI bus. This allows the selection of the CPU's External frequency (or
BUS Clock). The BUS Clock multiplied by the Frequency Multiple equals the
CPU's Internal frequency (the advertised CPU speed).
CUV4X-DLS
®
CUV4X-DLS CPU External
Frequency Selection
NOTE: Overclocking your processor is not recommended. It may result in a slower
speed.
WARNING! Frequencies other than the recommended CPU bus frequencies are
not guaranteed to be stable.
ASUS CUV4X-DLS User's Manual
ON ON
1 2 3 4 5 6 7 8 1 2 3 4
CPU 66MHz 68MHz
PCI 33MHz 34MHz
ON ON
1 2 3 4 5 6 7 8 1 2 3 4
CPU 80MHz 83MHz
PCI 40MHz 42MHz
ON ON
1 2 3 4 5 6 7 8 1 2 3 4
CPU 103MHz 105MHz
PCI 34MHz 35MHz
ON ON
1 2 3 4 5 6 7 8 1 2 3 4
CPU 112MHz 115MHz
PCI 37MHz 38MHz
ON ON
1 2 3 4 5 6 7 8 1 2 3 4
CPU 124MHz 133MHz
PCI 31MHz 33MHz
ON
1 2 3 4 5 6 7 8
CPU 150MHz
PCI 37MHz
ON
5 6 7 8 1 2 3 4 5 6 7 8
75MHz
37MHz
ON
5 6 7 8 1 2 3 4 5 6 7 8
100MHz
33MHz
ON
5 6 7 8 1 2 3 4 5 6 7 8
110MHz
36MHz
ON
5 6 7 8 1 2 3 4 5 6 7 8
120MHz
40MHz
ON
5 6 7 8 1 2 3 4 5 6 7 8
140MHz
35MHz
