PATENT N
OS
CAN 2,105,426
USA 5,614,883 – 5,617,819 – 5,673,017 – 6,087,996
AND OTHER PATENTS PENDING
Printed in Canada
All rights reserved © Astroflex 2005
U S E R M A N U A L
Models 903U & 701U
(FRANÇAIS AU VERSO)
®
REMOTE CONTROL
ENGINE STARTER
C
S
P
ONSULT
AFETY
RECAUTION SECTION
BEFORE USING THIS PRODUCT
S
OME FEATURES MAY REQUIRE
ADDITIONAL MATERIAL
July 2005
For all gas- and diesel-
powered vehicles
.
(N
).
OT INCLUDED
Manufactured in Canada by:
193-127-318-00
Advertisement
Table of Contents
Related Manuals for AstroStart 701U
Summary of Contents for AstroStart 701U
-
Page 1: Remote Control
® REMOTE CONTROL ENGINE STARTER U S E R M A N U A L Models 903U & 701U For all gas- and diesel- powered vehicles (FRANÇAIS AU VERSO) ONSULT AFETY RECAUTION SECTION BEFORE USING THIS PRODUCT OME FEATURES MAY REQUIRE ADDITIONAL MATERIAL OT INCLUDED PATENT N... -
Page 2: Government Regulations
GOVERNMENT REGULATIONS This device complies with the requirements of Industry Canada (IC) - Management of Radio Frequencies, as specified in document CNR-210. Its use is authorized only on a no-interference, no-protection basis; in other words, this device must not be used if it is determined that it causes harmful interference to services authorized by IC. -
Page 3: Table Of Contents
THANK YOU FOR CHOOSING AN ASTROSTART REMOTE CAR STARTER! Like you, Astroflex is concerned with the environment. This is why we are suggesting that you use the two-minute runtime when you remote-start your vehicle to warm up engine fluids. Ask your dealer. -
Page 4: Safety Precautions
Make sure you comply with all local regulations, which may prohibit leaving your engine running when vehicle is unattended in a public place. • To ensure continued safe operation of your remote starter, ask your AstroStart dealer to periodically check and/or tune the remote starting system. •... -
Page 5: Safety Sequence For Manual Transmission Vehicles
SAFETY SEQUENCE FOR MANUAL TRANSMISSION VEHICLES Your remote starter was designed to force you to perform a series of actions that will ensure that the gearshift lever is in neutral position when you exit the vehicle. This series of actions is called a "Safety sequence" and is aimed at preventing any remote start in situations where remote starting the engine would not be safe. -
Page 6: The Remote Control
THE REMOTE CONTROL Your remote control works off two small 3 volts lithium batteries ( CR2016). See your dealer for replacement batteries or additional remote controls. The range of your remote control can be affected by a weak battery, interference from nearby metal structures, hydro poles, or crowded parking lots. -
Page 7: Start Commands
CONFIRMATION In all cases, your remote starter will confirm that a command has been received properly by flashing parking lights. The horn provides certain confirmations when connected to system (requires optional wiring and material). In this manual, confirmation signals are written in an abbreviated form; for example: (lights: 2) means that parking lights will flash twice. Confirmations are explained in more detail under each command. - Page 8 CONTINUOUS MODE The “Continuous Mode“ function allows to remove the key from the ignition while leaving the engine running. This convenient feature allows you to leave the vehicle for short periods of time while the climate controls remain on. To access Continuous Mode, send start command UTOMATIC (Model 701U - Model 903U...
-
Page 9: Lock/Unlock Commands (903U Only)
LOW TEMPERATURE MODE (Model 903U only) In Low Temperature (Sentinel) mode, system starts your engine Low temperature level is set to automatically when temperature falls below a preset level -5°C (23°F) -20°C (-7°F) (programmable during installation). See table. Factory default setting is shaded. -
Page 10: Antitheft (Circuit Disabler)
UNLOCK Press the button. Doors are unlocked and parking light flashes twice to confirm command has been received. The “Unlock“ function can be programmed and connected in such a way that the first Unlock command only unlocks the driver's door, while a following Unlock command unlocks the other door(s). Dome light will turn on for 30 seconds every time (optional connection during installation): •... -
Page 11: Code Learning Of Additional Transmitter(S)
PANIC (903U only) Panic mode is used to attract attention if you are in difficulties. This command will not be executed if engine is kept running by ignition key. Use the stop command to abort panic mode or depress brake pedal. Press and hold, for at least 4 seconds, any of the 2) buttons. -
Page 12: Gearshift Check Applicable To Automatic Transmission Vehicles
GEARSHIFT CHECK APPLICABLE TO AUTOMATIC TRANSMISSION VEHICLES If key must be in ignition for gearshift to be moved out of P, your vehicle is safe as long as keys are kept away from children. If, on the other hand, gearshift can be put in gear without the key being in the ignition, proceed with this simple check. •...
