D. Super Freeze button: Activates/de-
activates the Super Freeze function for
large quantities for fresh food and
switches off the beeping alarm.

Installation

Wait at least 2 hours before
connecting the freezer to the power
supply to ensure the refrigerant circuit
is fully efficient.
Install the freezer in a dry, well
ventilated room. Avoid locations near a
source of heat or in direct sunlight.
The room
correspond to the climatic classification
for which the freezer was designed, see
chapter "Technical data".
Place the freezer horizontally on a firm
surface, resting on all four feet.
For optimum operation and in order to
avoid damage when the lid is opened,
leave a space of at least 5 cm from the
rear wall and 5 cm at the sides.
Before connecting the freezer to the
power supply, ensure that the voltage
corresponds to that indicated in
chapter "Technical
"Voltage".
Danger!
Ensure that the freezer is not resting
on the power supply cable.
Do not remove the power supply cable
by pulling on its lead, particularly when
the freezer is being pulled out of its
niche.
The power supply cable may only be
replaced by a qualified electrician.
Ensure that the power plug is not
squashed or damaged by the back of
the freezer.
There must be adequate ventilation
around the appliance.
Any electrical work required to install
this appliance should be carried out
by a competent electrician.
temperature should
data" under

Electrical connection

The appliance is supplied with a 13amp
plug fitted. In the event of having to
change the fuse in the plug supplied, a
13amp ASTA approved (BS1362) fuse
must be used. Should the plug need to
be replaced for any reason. The wires in
the power supply cable are coloured in
accordance with the following code:
Green and Yellow - Earth: must be
connected to the terminal marked with
the letter "E" or by the earth symbol or
coloured green and yellow.
Blue - Neutral: must be connected to
the terminal "N" or coloured black.
Brown - Live: must be connected to
the terminal marked "L" or coloured
red.
Upon completion there must be no cut,
or stray strands of wire present and the
cord clamp must be secure over the
outer sheath.
Warning! This appliance must be
earthed.

First use

Before first use, the freezer should be
cleaned inside, see chapter "Care and
cleaning".
Plug in the appliance.
The green light will come on.
The red light will also switch on and
the alarm will beep, to indicate that the
temperature inside the freezer is not
yet cold enough for food storage.
