- Page 1 f r e e z e r INSTRUCTION BOOK EU 6233 I 2222 145-86...
-
Page 2: Important Safety Information
¥ Do not place carbonated or fizzy drinks in the freezer. ¥ Do not remove items from the freezer if your hands are damp/wet, as this could cause skin abrasions or frost/freezer burns. ¥ Ice lollies can cause Ôfrost/freezer burnsÕ if con- sumed straight from the freezer. -
Page 3: Table Of Contents
CONTENTS Instructions for the User Important Safety Information Description of the Appliance Operation Before using Starting your appliance Temperature control Freezing fresh food Frozen food storage Thawing Making ice cubes Hints and Tips Defrosting Maintenance and Cleaning Internal cleaning When the appliance is not in use Something Not Working Service and Spare Parts Customer Care... -
Page 4: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE A- Freezer controls B - Compartment for frozen food storage C - Compartments for freezing fresh foods 10 - 10 - 10 - 10 - 3 - 4... -
Page 5: Operation
In any 24 hour period you can freeze up to 16 kg of fresh food. When you first start the freezer or after a period of non-use, press the fast-freeze switch (A) 2-3 hours before you want to freeze your food (the yellow light (B) illuminates). -
Page 6: Thawing
Òfrost/freezer burnsÓ. In the event of a power cut the food in the freezer will not be affected if the power cut is short and the freezer is full. Do not open the door . Should the food begin to thaw, it must be consumed quickly and must not be re-frozen. -
Page 7: Hints And Tips
¥ Do not store food uncovered. ¥ Ensure that food placed in the freezer is dated and labelled and used in date order to ensure that food is consumed at its best. ¥ Lean food keeps better and longer than fatty food, salt reduces the storage time. -
Page 8: Defrosting
ÇOFFÈ position ( ) or disconnect the appliance from the mains. Remove any food from inside the freezer , wrap it in several sheets of newspaper and store in a cool/dry place. Leave the door open and insert the ice scraper under the channel in the centre of the lower part of the appliance;... -
Page 9: Maintenance And Cleaning
MAINTENANCE AND CLEANING Before any maintenance or cleaning work is carried out, DISCONNECT the appliance from the ELECTRICITY supply. Internal cleaning Clean the inside and accessories with warm water and bicarbonate of soda (5ml to 0.5 litre of water). Rinse and dry thoroughly. NEVER USE DETERGENTS, ABRASIVE POWDERS, HIGHLY PERFUMED CLEANING PRODUCTS OR WAX... -
Page 10: Something Not Working
Check there is not a power cut by checking the household lights. Check the fuse has not blown. Check the thermostat control knob in the freezer is turned to the correct setting relative to ambient conditions. Check the ambient temperature is within the applianceÕs operating limits of 10¡C to 32¡C. -
Page 11: Service And Spare Parts
The model and serial number of the appliance (found on the rating plate) The purchase date CUSTOMER CARE DEPARTMENT For general enquiries concerning your Electrolux appliance or for further information on Electrolux products, please contact our Customer Care Department by letter or telephone as follows:- Customer Care Department... -
Page 14: Guarantee Conditions
Standard guarantee conditions We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate. -
Page 15: Technical Specifications
TECHNICAL SPECIFICATIONS POWER SUPPLY VOLTAGE AND FREQUENCY TOTAL POWER ABSORBED AVERAGE DAILY UNITS ELECTRICITY * GROSS CAPACITY NET CAPACITY STAR RATING This figure is based on standard test results in accordance with European Standard EN 153. Actual consumption will depend on how the appliance is used and where it is located. 220-240 V / 50 Hz 100 W 0.70 kWh... -
Page 16: Installation Instructions
INSTALLATION Warning IF YOU ARE DISCARDING AN OLD APPLIANCE THAT HAS A LOCK OR CATCH ON THE DOOR, YOU MUST ENSURE THAT IT IS MADE UNUSABLE TO PREVENT YOUNG CHILDREN BEING TRAPPED INSIDE. Depending upon the position which you choose for your appliance, you may wish to reverse the way in which the door opens. -
Page 17: Electrical Connection
The cover/carrier is indicated by the coloured insert at the base of the plug. A replacement cover/carrier must be obtained from your local Electrolux Service Force Centre. This appliance complies with the E.E.C. Directive No. 87/308 of 2.6.87 relative to radio interference suppression. -
Page 18: Building In
Instructions for totally built-in appliances Door reversal Recess dimensions Height 880 mm Depth 550 mm Width 560 mm The applianceÕs door has been locked in position for transport by means of pins on both sides. According to the door opening direction, remove relevant pins at the top and at the bottom. - Page 19 Press in the joint covers between the appliance and the kitchen unit. D724 Apply covers (B) on joint cover lugs and into hinge holes. D726 Separate parts A, B, C, D as shown in the figure PR266 Place guide (A) on the inside part of the furniture door, upper and lower position as shown in the figure and mark the position of external holes.
- Page 20 Fix cover (C) on guide (A) until it clips into place. Open the appliance door and the furniture door at 90¡. Insert the small square (B) into guide (A). Put together the appliance door and the furniture door and mark the holes as indicated in the figure. Remove the squares and drill holes with ¿...
- Page 24 © Electrolux Household Appliances Limited 2001...
