American DJ
HALOGEN LAMP WARNING!
This fixture is fitted with halogen lamps
which are highly susceptible to damage if
improperly handled. Never touch lamp
with bare fingers as the oil from your
hands will shorten lamp life. Also, never
move fixture until lamp has had ample
time to cool. Remember, lamps are not
covered under warranty conditions.
C a u t i o n !
Always disconnect from main
power before replacing lamps or servicing unit.
Remember to always replace with same lamps
and fuses.
Model:
SPECIFICATIONS:
Lamp: 2 x ZB-64514 120V 300W,
Dimensions: 16" x 12" x 11"
Weight: 11 lbs.
Supply Voltage: 120V
Fuse: 7A
Working Position: Any Safe position
Duty Cycle: 10 min., on, 10
Colors: Multiple Colored Lens
Optional: ZB-ADJ300 120V 300W 150 hr.
Long Life lamp also available.
®
™
min. off
American DJ
User
Instructions
™
Tha nk y ou f o r pu rch a sin g th is
America n DJ® produ ct. For your
convenience this lighting effect has
been lamped and is ready to be used,
t h e re i s no a s se mbl y re q u i re d .
Pl eas e
i n s t ru ctions bef ore in stal lin g or
using your new unit.
Product Description:
Dual rotating disks on attached base
Operating Instructions:
Unit is ready to be hung or set on flat surface. Be
sure not to obstruct cooling vents and keep in a
well ventilated area. Fog best results, fog or spe-
cial effects smoke must be used in order to see
the beams of light.
Caution! Never open unit when in use. Always dis-
connect main power before serving or replacing
lamp. Remember always replace same lamp and
fuses.
Lamp replacement: Remove thumb screws on
side of each disk and disconnect socket from rear
of lamp. Remove and replace lamps..
For service, contact your American DJ® dealer.
®
LOS ANGELES, CA. 90058
rea d
t he
fo ll ow in g
