American DJ
SUNRAY-150D
CAUTION! Read instructions before installing or plugging unit in.
SPECIFICATIONS:
Weight:
Size:
Lamp:
Fuse:
Supply Voltage:
Working Position:
Motor Speed:
Full Intensity:
Duty Cycle:
FEATURES:
The Sunray 150D™ features extremely bright focused beams of multi-colored light. This unit
is Ideal for large venues as a centerpiece. The Sunray 150D™ includes a mounting bracket
for mounting on ceilings. After plugging in, the unit will take five minute to warm-up to full
light output . Due to the warm up time time this unit is not deigned to be turn off and on
continuously, for best results and extended lamp life leave the fixture on for an extended
period of time. The unit will also rotate slowly at 6 r.p.m. creating a mirror ball type effect.
Caution: Never open unit when in use. Unplug unit and let cool before servicing. Always
remember to replace with the same type lamp and fuse.
For lamp replacement; Remove the screws on the upper half of the ball, remove the upper
cover, replace lamp & reassemble.
For service, contact your American DJ
ACH UNIT IS LAMPED AND TESTED BEFORE LEAVING THE FACTORY.
Affordable Quality Lighting Products from American DJ® Los Angeles, CA. 90058 USA
®
SUNRAY-150D
™
21 lbs.
10" x 10" x 14".
ZB-HTI/152
6 AMP
110-120V/60Hz.
Any Safe position.
6 rpm.
5 Minutes
None
Dealer.
®
User Instructions
™
HALOGEN LAMP WARNING!
This fixture is fitted with halogen
lamps which are highly suscepti-
ble to damage if impr o p e r l y
handled. Never touch lamp with
bare fingers as the oil from your
hands will shorten lamp life. Also,
never move fixture until lamp
has had ample time to cool.
R e m e m b e r, lamps are not cov-
ered under warranty conditions.
