SETUP

You can flexibly customize the unit to suit your own preferences and
usage. From the SETUP menu, Sound Customizing, Visual
Customizing, etc., can be modified.
CDE-9874 Series
Rotary encoder (AUDIO)
/ /ENT
SOURCE/
/SOUND FUNC./SETUP
CDE-9872 Series
/ /ENT
FUNC./SETUP
/AUDIO
Use steps 1 to 4 to select one of the SETUP modes to
modify. See the applicable section below for details
about the selected SETUP item.
1
Press and hold FUNC./SETUP for at least
2 seconds to activate the SETUP mode.
2
Turn the Rotary encoder (CDE-9874 Series only) or
press and (CDE-9872 Series only) to select the
desired SETUP menu, and then press
(e.g. Select SUBWOOFER)
1
BT IN* FM-LEVEL
4
DIMMER* SUBWOOFER
PLAY MODE INT MUTE*
TEXT SCR POWER IC
7
AUX NAME* DEMO
1
* Displayed only when INT MUTE is set to OFF, and the mode is set to
other than BT AUDIO.
2
* Refer to "Receiving RDS Regional (Local) Stations" (page 8).
3
* Refer to "PI SEEK Setting" (page 9).
4
* CDE-9874RB only.
5
* Displayed only when SUBW is ON.
6
* Displayed only when BT IN is OFF.
7
* CDE-9874 Series only.
3
Turn the Rotary encoder (CDE-9874 Series only) or
press and (CDE-9872 Series only) to change
the setting.
(e.g. Select SUBW ON or SUBW OFF.)
/ /ENT.
2 3
REGIONAL* PI SEEK*
5
(SUBW SYS) *
6
SCROLLTYPE
AUX+ SETUP
BT IN
4
Press and hold FUNC./SETUP for at least 2
seconds to return to normal mode.
• Press /SOUND (CDE-9874 Series only) or
(CDE-9872 Series only) to return to the previous mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.

Bluetooth Setting

Setting the Bluetooth Connection (BT IN)

BT ADAPTER / BT OFF (Initial setting)
If an optional Bluetooth Box (KCE-300BT) is connected, you can place
a hands-free call by a Bluetooth-equipped mobile phone. Make this
setting when the Bluetooth Box (KCE-300BT) is connected and the
Bluetooth function is used. For details, refer to the Owner's Manual of
the optional Bluetooth Box (KCE-300BT).
Set ADAPTER when the Bluetooth Box (KCE-300BT) is connected.
• The PHONE button can be used only when the optional Bluetooth
Box (KCE-300BT) is connected.

Sound Customizing

Adjusting Source Signal Levels

FM-LV HI (Initial setting) / FM-LV LOW
If the difference in volume level between the CD player and FM radio is
too great, adjust the FM signal level.

Subwoofer On and Off

SUBW ON (Initial setting) / SUBW OFF
When the subwoofer is on, perform the steps below to adjust the
subwoofer output level.
1 In the normal mode, press Rotary encoder (AUDIO)
(CDE-9874 Series only) or
only) repeatedly to select the SUBW mode.
SUBW BASS TREBLE
DEFEAT VOLUME
2 Adjust the level by turning the Rotary encoder
(CDE-9874 Series only) or pressing
(CDE-9872 Series only).
1
* CDE-9872 Series only.

Setting the Subwoofer System

SUBW SYS 1 (Initial setting) / SUBW SYS 2
Select either SYS 1 or SYS 2 for the desired subwoofer effect.
SUBW SYS 1: Subwoofer level changes according to the main
volume setting.
SUBW SYS 2: Subwoofer level change is different from the main
volume setting. For example, even at low volume
settings, the subwoofer is still audible.

Visual Customizing

Dimmer Control (CDE-9874RB only)

DIM AUTO (Initial setting) / DIM MANUAL
Set the DIMMER control to AUTO to decrease the illumination
brightness of the unit with the head lights of the vehicle ON. This mode
is useful if you feel the unit's backlighting is too bright at night.
/AUDIO
/AUDIO (CDE-9872 Series
1
BAL FADER LOUD*
SUBW
and
17
-EN
