  • Page 1 Universal Wireless Subwoofer Kit User Guide RF-WSW312...

  • Page 2: Table Of Contents

    Universal Wireless Subwoofer Kit. Read this user guide carefully before installing your system, then keep it near your system for quick reference. Your RF-WSW312 Universal Wireless Subwoofer Kit uses a wireless communication system to transmit high fidelity audio to a subwoofer, providing superior level audio quality and resistance to interference.

  • Page 3: Safety Information

    RF-WSW312 Safety information CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

  • Page 4: Additional Safety Information

    7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9) Do not defeat the safety purpose of the polarized or grounding-type plug.

  • Page 5: Features

    • Transmits high quality audio over a radio frequency communication link • Compact size • Hidden antennas Package contents Examine the contents of the box for your RF-WSW312 Universal Wireless Subwoofer Kit. The box should contain: • Wireless Sender • Wireless Receiver • AC power adapters (2) •...
  • Page 6 Wireless Sender The Wireless Sender transmits audio signals to the Wireless Receiver. Back view CONNECT DC IN 5V Bottom view Top view Feature Subwoofer In RCA jack Line In RCA jack Connect (pairing) button DC IN jack Power indicator LED Hanging holes for wall mounting the Sender...

  • Page 7: Wireless Receiver

    RF-WSW312 Wireless Receiver The Wireless Receiver unit receives audio signals from the Wireless Sender. Back view CONNECT DC IN 5V Bottom view Top view Feature Subwoofer Out RCA jack Connect (pairing) button DC IN jack Power indicator LED Hanging holes for wall mounting the Receiver...

  • Page 8: Setting Up Your Subwoofer Kit

    Setting up your subwoofer kit Left speaker Right speaker Center speaker Wireless Sender Amplifier Subwoofer Wireless CONNECT DC IN 5V Receiver Rear Right speaker Rear Left speaker...
  • Page 9 RF-WSW312 Connecting the Wireless Sender Option 1: Home theater receiver with a Sub Out jack Most home theater receivers have a subwoofer output jack. For that type of receiver, use this option. • Connect the Subwoofer RCA cable (provided) to the Subwoofer Out RCA jack on your home theater receiver and to the Wireless Sender’s SUB IN RCA jack.

  • Page 10: Audio Source With Line Out Jacks

    Option 2: Audio source with L/R Line Out jacks If your audio receiver does not have a subwoofer output jack, use this option. • Connect an RCA stereo audio cable (not included) to the stereo output jack of your audio receiver and to the Wireless Sender’s Line In RCA jacks.
  • Page 11 RF-WSW312 To connect the Wireless Sender to an AC power outlet • Plug the AC power adapter into a power outlet, then plug it into the DC IN jack on the Wireless Sender. Note: The AC power adapter can be connected to the SWITCHED AC outlet of your home theater receiver.
  • Page 12 Connecting the Wireless Receiver To connect the subwoofer to the Wireless Receiver: • Connect the Subwoofer RCA cable (provided) to the Wireless Receiver SUB OUT RCA jack and to the subwoofer input RCA jack. Subwoofer CONNECT DC IN 5V Wireless receiver back panel To connect the Wireless Receiver to an AC power outlet •...

  • Page 13: Using Your Subwoofer Kit

    RF-WSW312 Placing the Wireless Sender and Wireless Receiver The Wireless Sender and Wireless Receiver must be separated by at least 12 inches and be within 45 feet of each other to function properly. Wall mounting the Wireless Sender and Wireless...

  • Page 14: To Listen To Subwoofer Audio

    1 Wireless Sender - Press and hold the pairing button for more than two seconds, then release it. The Wireless Sender enters pairing mode. 2 Wireless Receiver - Press and hold the pairing button for more than two seconds, then release it. The Wireless Receiver enters pairing mode.

  • Page 15: Troubleshooting

    RF-WSW312 Troubleshooting Please read this User Guide carefully before using your universal wireless subwoofer kit. Check this list for a possible troubleshooting solution before calling for service. Problem Solution No sound • Make sure that the AC adapters are connected to the Wireless Sender and the Wireless Receiver.

  • Page 16: Legal Notices

    Wireless Receiver Audio Input: Wireless • 16-bit, 48 KHz, uncompressed Audio Output • Output Level: 2V RMS • Total Harmonic Distortion: ≤ 0.5% • Signal to Noise: 90dB Power Supply • 5V Legal notices FCC Part 15 This device complies with Part 15 of the FCC Rules. Operation of this product is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference...
  • Page 17 Copyright © 2012 Rocketfish. Rocketfish and the Rocketfish logo are trademarks of Best Buy Enterprise Services, Inc. Other brands and product names are trademarks or registered trademarks of their respective holders.

  • Page 19: One-Year Limited Warranty

    One-Year Limited Warranty Rocketfish Products (“Rocketfish”) warrants to you, the original purchaser of this new RF-WSW312 (“Product”), that the Product shall be free of defects in the original manufacture of the material or workmanship for one (1) year from the purchase of the Product (“Warranty Period”).
  • Page 20 • Damage due to incorrect operation or maintenance • Connection to an incorrect voltage supply • Attempted repair by anyone other than a facility authorized by Rocketfish to service the Product • Products sold as is or with all faults •...
  • Page 21 7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645 © 2012 Best Buy Enterprise Services, Inc. All rights reserved. ROCKETFISH is a trademark of Best Buy Enterprise Services, Inc. Registered in some countries. All other products and brand names are trademarks of...
  • Page 22 Distributed by Best Buy Purchasing, LLC 7601 Penn Avenue South, Richfield, MN 55423-3645 USA © 2012 BBY Solutions, Inc. All rights reserved. ROCKETFISH is a trademark of BBY Solutions, Inc. All other products and brand names are trademarks of their respective owners. 12-1005...
