RocketFish RF-WSW312 User Manual

Universal wireless subwoofer
Hide thumbs Also See for RF-WSW312:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
UNIVERSAL WIRELESS
SUBWOOFER KIT
RF-WSW312
USER GUIDE
Before using your new product, please read these instructions to prevent any damage.

Advertisement

Table of Contents
loading

Related Manuals for RocketFish RF-WSW312

Summary of Contents for RocketFish RF-WSW312

  • Page 1 UNIVERSAL WIRELESS SUBWOOFER KIT RF-WSW312 USER GUIDE Before using your new product, please read these instructions to prevent any damage.

  • Page 2: Table Of Contents

    Wireless Subwoofer Kit. Read this user guide carefully before installing your system, then keep it near your system for quick reference. Your RF-WSW312 Universal Wireless Subwoofer Kit uses a wireless communication system to transmit high fidelity audio to a subwoofer, providing superior level audio quality and resistance to interference.

  • Page 3: Safety Information

    RF-WSW312 Safety information CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
  • Page 4 6) Clean only with dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. 8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.

  • Page 5: Features

    • Transmits high quality audio over a radio frequency communication link • Compact size • Hidden antennas Package contents Examine the contents of the box for your RF-WSW312 Universal Wireless Subwoofer Kit. The box should contain: • Wireless Sender • Wireless Receiver • AC power adapters (2) •...
  • Page 6 Wireless Sender The Wireless Sender transmits audio signals to the Wireless Receiver. Back view CONNECT DC IN 5V Bottom view Top view Feature Subwoofer In RCA jack Line In RCA jack Connect (pairing) button DC IN jack Power indicator LED Hanging holes for wall mounting the Sender...
  • Page 7 RF-WSW312 Wireless Receiver The Wireless Receiver unit receives audio signals from the Wireless Sender. Back view CONNECT DC IN 5V Top view Bottom view Feature Subwoofer Out RCA jack Connect (pairing) button DC IN jack Power indicator LED Hanging holes for wall mounting the Receiver...

  • Page 8: Setting Up Your Subwoofer Kit

    Setting up your subwoofer kit Left speaker Right speaker Center speaker Wireless Sender Amplifier Subwoofer Wireless CONNECT DC IN 5V Receiver Rear Right speaker Rear Left speaker...
  • Page 9 RF-WSW312 Connecting the Wireless Sender Option 1: Home theater receiver with a Sub Out jack Most home theater receivers have a subwoofer output jack. For that type of receiver, use this option. • Connect the Subwoofer RCA cable (provided) to the Subwoofer Out RCA jack on your home theater receiver and to the Wireless Sender’s SUB IN RCA jack.
  • Page 10 • Connect an RCA stereo audio cable (not included) to the stereo output jack of your audio receiver and to the Wireless Sender’s Line In RCA jacks. CONNECT DC IN 5V Wireless Sender back panel...
  • Page 11 RF-WSW312 To connect the Wireless Sender to an AC power outlet • Plug the AC power adapter into a power outlet, then plug it into the DC IN jack on the Wireless Sender. Note: The AC power adapter can be connected to the SWITCHED AC outlet of your home theater receiver.
  • Page 12 To connect the Wireless Receiver to an AC power outlet • Plug the AC power adapter into a power outlet, then plug it into the DC IN jack on the Wireless Receiver. CONNECT DC IN 5V Caution: To avoid risk of fire, and to prevent damage, only use the AC adapter supplied with your universal wireless subwoofer kit.

  • Page 13: Using Your Subwoofer Kit

    RF-WSW312 Using your subwoofer kit Pairing the Wireless Sender and Wireless Receiver: Note: The Wireless Sender and Wireless Receiver are pre-paired at the factory. • Auto pairing • When the Wireless Sender and Wireless Receiver are plugged in, the system enters automatic pairing mode, and the LED indicator turns solid blue.

  • Page 14: Troubleshooting

    Troubleshooting Please read this User Guide carefully before using your universal wireless subwoofer kit. Check this list for a possible troubleshooting solution before calling for service. Problem Solution No sound • Make sure that the AC adapters are connected to the Wireless Sender and the Wireless Receiver.

  • Page 15: Specifications

    RF-WSW312 Specifications Wireless Sender Audio Input • Maximum audio input signal: 2 V RMS Audio Output: Wireless • 16-bit, 48 KHz uncompressed Supply voltage • 5V Wireless Receiver Audio Input: Wireless • 16-bit, 48 KHz, uncompressed Audio Output • Output Level: 2V RMS •...

  • Page 16: Fcc Warning

    Copyright Rocketfish is a trademark of Best Buy and its affiliated companies. Registered in some countries. Distributed by Best Buy Purchasing, 7601 Penn Ave South, Richfield, MN 55423 U.S.A ©...

  • Page 17: One-Year Limited Warranty-Rocketfish

    Products and parts replaced under this warranty become the property of Rocketfish and are not returned to you. If service of Products or parts are required after the Warranty Period expires, you must pay all labor and parts charges.
  • Page 18 Damage due to incorrect operation or maintenance • Connection to an incorrect voltage or power supply • Attempted repair by any person not authorized by Rocketfish to service the Product • Products sold “as is” or “with all faults” •...
  • Page 19 7601 Penn Avenue South, Richfield, Minnesota, U.S.A. 55423-3645 © 2016 BBY Solutions, Inc. All rights reserved. ROCKETFISH is a trademark of BBYSolutions, Inc. Registered in some countries. All other products and brand names are trademarks of their respective owners. Made in China...
  • Page 20 (800) 620-2790 ROCKETFISH is a trademark of Best Buy and its affiliated companies. Registered in some countries. Distributed by Best Buy Purchasing, LLC 7601 Penn Avenue South, Richfield, MN 55423-3645 USA © 2016 Best Buy. All rights reserved. Made in China...
