- Page 1 D i s h w a s h e r Model ESL 4115 Instruction book 03/05...
-
Page 2: Table Of Contents
Hints for test centres Width Height Max depth Max depth with open door Information on the electrical connection is given on the rating plate on the inner edge of the dishwasher’s door. Minimum Maximum 44.6 cm 81.8 - 87.8 cm 55.5 cm 114 cm 50 kPa (0.5 bar) -
Page 3: Safety Instructions
Cardboard packaging is manufactured from recycled paper and should be deposited in the waste paper collection for recycling. As and when you cease to use your dishwasher and withdraw it from service, your should render it unserviceable before having it disposed of. -
Page 4: Description Of The Appliance
Description of the appliance Upper basket stop Water hardness dial Salt container Detergent dispenser Control panel Rating plate Rinse aid dispenser Filters Lower spray arm 10. Upper spray arm 11. Upper basket IN155... -
Page 5: The Control Panel
- malfunction of the machine. Deactivation/activation of the audible signals Factory setting: audible signals activated. 1. With the dishwasher switched off, press the On/Off button. The end of cycle indicator light flashes (setting mode). In case salt and/or rinse aid refilling is necessary the corresponding indicator lights illuminate. -
Page 6: Prior To Using For The First Time
5. Fill the rinse aid dispenser The water softener The dishwasher is equipped with a water softener designed to remove minerals and salts from the water supply, which would have a detrimental or adverse effect on the operation of the appliance. -
Page 7: Filling With Dishwasher Salt
Only use salt specifically designed for use in dishwashers. All other types of salt not specifically designed for use in a dishwasher, especially table salt, will damage the water softener. Only fill with salt just before starting one of the complete washing programmes. -
Page 8: In Daily Use
In daily use Check if it’s necessary to refill with dishwasher salt or rinse Load cutlery and dishes into the dishwasher. Fill with dishwasher detergent . Select a wash programme suitable for the cutlery and dishes. Start the wash programme. -
Page 9: The Upper Basket
The upper basket The upper basket is designed for plates (dessert plates, saucers, dinner plates of up to 24 cm in diameter), salad bowls, cups and glasses. Arrange items on and underneath the cup racks so that water can reach all surfaces. -
Page 10: Different Kinds Of Detergent
65°C programmes. Combi detergents If you are using dishwasher detergent that includes the rinse aid function, this must be placed in the detergent compartment. In this case the rinse aid dispenser must be empty, in order to avoid a double dosage. -
Page 11: Washing Programmes
Washing programmes Programme Degree of soil type of load Intensive 70°C Heavy soil. Crockery, cutlery, pots and pans Normal 65°C Normal soil. Crockery and cutlery Fresh soil. Quick 65°C Crockery and cutlery Normal soil. Bio 50°C Crockery and cutlery Any. Rinse and Hold Partial load (to be completed later in the... -
Page 12: Starting A Washing Programme
The dishwasher will automatically stop. An audible signal informs you of the end of the washing programme. Open the dishwasher’s door, leave it ajar and wait a few minutes before removing the dishes; in this way they will be cooler and the drying will be improved. -
Page 13: Maintenance And Cleaning
Dirty filters will degrade the washing result. 1. Open the door, remove the lower basket. 2. The dishwasher filter system comprises a coarse filter (A), a microfilter (B) and a flat filter (C). Unlock the filter system using the handle on the microfilter, and remove. -
Page 14: Something Not Working
Once the checks have been carried out, press the programme selection/cancel button and close the dishwasher’s door. The programme will continue from the point at which it was interrupted. If the fault code reappears contact your local Service Force Centre. -
Page 15: The Wash Results Are Not Satisfactory
(PNC) and serial number (S.N.). This information can be found on the rating plate located on the side of the dishwasher door (see picture). So that you always have these numbers at hand, we recommend you to make a note of them here: Mod. -
Page 16: Service And Spare Parts
Tel: + 353 (0)1 4090751 Email: service.eid@electrolux.ie Customer Care Department For general enquiries concerning your Electrolux appliance or for further information on Electrolux products, please contact our Customer Care Department by letter or telephone at the address below or visit our website at: www.electrolux.co.uk... -
Page 17: Guarantee Conditions
Guarantee Conditions Standard Guarantee Conditions We, Electrolux, undertake that if within 12 months of the date of purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same... -
Page 18: Installation Instructions
Remove all packaging before positioning the machine. If possible, position the machine next to a water tap and a drain. Building-in This dishwasher is designed to be fitted under a kitchen counter or worksurface. Attention! Carefully follow the instructions on the enclosed template for building in the dishwasher and fitting the furniture panel. -
Page 19: Water Outlet Hose Connection
A replacement cover/carrier must be obtained from your local Service Force Centre. To isolate the dishwasher from mains, remove the mains plug. Important! The plug must still be accessible after the appliance has been installed. -
Page 20: Hints For Test Centres
Hints for test centres Testing in accordance with EN 60704 must be carried out with appliance fully loaded and using the test programme (see "Washing programmes" chart). Test in accordance with EN 50242 must be carried out when the salt dispenser and rinse aid container have been filled with salt and rinse aid respectively and using the test programme (see "Washing programmes"... - Page 24 The Electrolux Group. The World’s No.1 choice. The Electrolux Group is the world’s largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx. 14 billion USD in more than 150 countries around the world.
