- Page 1 Twin-tub Washing Machine User's manual This manual is for HWM110-0713S Please read this manual carefully before using. Retain it for future reference. 0030807886I...
-
Page 2: Table Of Contents
Contents Names of the parts Safety precautions Installation and adjustment Preparation before washing The musts in washing Usage of the detergent Washing sequence Disposal after washing Trouble-Shooting Answers to question Packing list Specification... -
Page 3: Names Of The Parts
Names of the parts Valve cover Notes: All illustrations in this Manual are given for reference only. Your products and accessories may show differences from these illustrations due to our continuous improvement. Meaning and description of the symbols Contents marked with that symbol are related Warning sign to the safety of the product and the personal safety of the users. -
Page 4: Safety Precautions
Safety precautions × ¢ Ò â Ê Â Ï î When the machine is normally Please insert the power cord into using, please put the power plug special receptacle with rated vol- at the location easily to be insert- tage.Be sure to use single-phase ed and extracted by hand. - Page 5 × ¢ Ò â Ê Â Ï î Safety precautions Do not decompose, repair or alter the Do not stretch hands into the working machine by yourself. machine. It is dangerous even if the rotation is slow. Take special care of the children.
-
Page 6: Installation And Adjustment
Installation and adjustment Please install and adjust the machine according to the requirement of the manual. It is very important to your security and correct operating the machine. Install the lint filter Put the underside of the lint filter into overflow filter then push the upside into overflow filter After installation,please refer that the lint filter installed to the right station,otherwise the lint... -
Page 7: How To Change The Direction Of The Drain Hoses
How to change the direction of the drain hoses Figure 1 indicates the ex factory installation position of the drain hose. Side sectional view Drain hose Fixing hook Extend the drain hose from the side of spin tub fixing hook installation hole Drain hose Pull outwards... -
Page 8: Install The Water Inlet Hose; Select The Water Level
Install the water inlet hose; Select the water level Insert the water inlet hose into the water-filling entrance on the control panel To dismantle the water inlet pipe, Water inlet hose just push the control handle as indicated in the Water level Water inlet figure and pull it out... -
Page 9: Preparation Before Washing
Ï ´ Ç ° × ¼ ± ¸ Preparation before washing Preparation before washing 1.Connect the water inlet hose. 2.Confirm that the washing machine is earthed reliably . Then insert the power plug into the receptacle. Do not connect the earth terminal to the gas pipe and tap water pipe. -
Page 10: The Musts In Washing
The musts in washing The capacity of washing and spinning of the machine refer to the largest weight of the standard laundries under dry condition that can be washed or spinned in one time. Laundries quantity in one washing cycle shall be lower than the rated capacity. -
Page 11: Washing Sequence
Ï ´ µ Ó Ë ³ Ð ò Ï ´ µ Ó Ë ³ Ð ò Ï ´ µ Ó Ë ³ Ð ò Washing sequence Wash timer Wash timer Spin timer Spin timer Wash selector Wash selector ( To set to below 2 minute, (to set to below 1 minute, (Strong current, first set to 5 minute then... - Page 12 Ï ´ µ Ó Ð ë Ö ª Midway spinning 1.Put the laundries into the spin tub evenly and smoothly. 2.Spin (1) Put the gland in properly. Please put in the gland properly even if the laundries quantity is small. Push Gland Push...
-
Page 13: Rinse With Water-Filling
Rinsing Rinse with water-filling 1.Put the laundries into the wash tub. Select suitable current according to the laundries. 2.Adjust the water level Set the water level with water level adjusting lever according to the laundries quantity. Then fill suitable water continuously. 3.Rinse Adjust the wash timer to 5-7 minutes to do rinsing. - Page 14 Spinning 1. Put the laundries into the spin tub evenly and smoothly. 2. Press the gland in the tub properly. Close the inner and outer cover of the spin tub. 3. Spin Select suitable spin time according to the laundries, and do spinning. During spinning, if there's abnormal sound, it is generally owing to slanting placement of the laundries.
-
Page 15: Disposal After Washing
Disposal after washing After using, please clean the lint and eyewinker of the lint filter and overflow filter in time. Otherwise it may influence your using the machine. Please first pull off the power plug from the receptacle before cleaning. Cleaning the lint filter The lint filter must be used during washing. -
Page 16: Cleaning The Overflow Filter
Ï ´ º ó ´ ¦ À í Cleaning the overflow filter 2. Take off the corrugation pipe. Water level Dismantle the upper part of the adjusting lever corrugation pipe inside overflow filter ( as indicated in Corrugation Figure 1). Pipe 3. -
Page 17: Protective Cover
Ï ´ º ó ´ ¦ À í protective cover Cleaning the 2.cleaning dirty under the protective cover take out the sundries using the plier or other wiry 3.install the protective cover after cleaning, install it as origin assure it reliable Disposal of the complete unit After washing, dismount the water inlet Wipe the complete unit with soft... -
Page 18: Trouble-Shooting Answers To Question
Trouble-shooting Answer to question If there's breakdown, please pull off the power plug before checking) The following phenomena are not breakdowns sometimes. Please confirm again before sending it to repair. If there are real breakdowns, please come to the special maintenance department or after-sale service department of our company. -
Page 19: Packing List
Packing list Quantity Name One piece User's manual One piece Water inlet hose One piece Lint filter One piece Gland One set Twin-tub washing machine Specification Water level Water quantity about (L) Maximum/58 Medium/49 Minimum/43 Injection pressure(MPa) 0.02~0.2 Rated voltage frequency 220V/127V 60Hz 8.0kg/6.0kg Rated washing / spinning capacity...
