Majestic fireplaces UVS33RN Operating Instructions Manual

Vent-free gas room heaters

Advertisement

PLEASE READ THIS MANUAL
BEFORE INSTALLING AND USING
HEATERS
IMPORTANT: Read all instructions
and warnings carefully before start-
ing installation. Failure to follow these
instructions may result in a possible fire
hazard and will void the warranty.
WARNING: If the information in this
manual is not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of life.
— Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
— What to Do If You Smell Gas
Do not try to light any appliance.
Do not touch any electrical switch;
do not use any phone in your build-
ing.
Immediately call your gas supplier
from a neighbor's phone. Follow the
gas supplier's instructions.
If you cannot reach your gas sup-
plier, call the fire department.
— Installation and service must be per-
formed by a qualified installer, ser-
vice agency or the gas supplier.
This is an unvented gas-fired heater.
It uses air (oxygen) from the room in
which it is installed. Provisions for ad-
equate combustion and ventilation air
must be provided.
Vent-Free Gas Room Heaters:
Models: UVS33RN, UVS33RP
UVS36RN, UVS36RP
Homeowner's Installation and
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Operating Instructions
GF454
UVC Cover
2/27/97
20002211 3/06 Rev. 15

Advertisement

Table of Contents
loading

Summary of Contents for Majestic fireplaces UVS33RN

  • Page 1 Vent-Free Gas Room Heaters: Models: UVS33RN, UVS33RP UVS36RN, UVS36RP PLEASE READ THIS MANUAL BEFORE INSTALLING AND USING HEATERS IMPORTANT: Read all instructions and warnings carefully before start- ing installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty.
  • Page 2: Table Of Contents

    UVS33/36 Vent-Free Heaters Table of Contents PLEASE READ THE INSTALLATION & OPERATING INSTRUCTIONS BEFORE USING APPLIANCE. Thank you and congratulations on your purchase of a Majestic fireplace. IMPORTANT: Read all instructions and warnings carefully before starting installation. Failure to follow these instructions may result in a possible fire hazard and will void the warranty.
  • Page 3: Installation & Operating Instructions

    UVS33/36 Vent-Free Heaters Installation & Operating Instructions annually. More frequent cleaning may be required due to This gas room heater should be installed by a qualified installer excess lint and dust from carpeting, bedding material, etc. in accordance with local building codes and with current Na- 6.
  • Page 4: Fireplace Dimensions

    UVS33/36 Vent-Free Heaters Fireplace Dimensions 33" 22����" Rough Opening Depth 23" 12" 33���" 33" Finished Wall Rough Opening Width 46” Thickness Rough Opening Height Gas Line Access - 2" Dia. Electrical Cable 28" Outside Knockout - 1" Dia. 28���" 16���" 29"...
  • Page 5: Safety Devices

    UVS33/36 Vent-Free Heaters Safety Devices Burner with Pilot Shield Tiles Hex Nut Orifice Adequate combustion and ventilation air must be pro- vided. The flow of combustion and ventilation air MUST Pilot NOT be obstructed. Shutter Provide adequate clearances around the air opening into the combustion chamber;...
  • Page 6: Mantels

    UVS33/36 Vent-Free Heaters Mantels Depending on the width of the mantel, it may be in- stalled higher or lower from the combustion chamber opening. This also applies to the distance between the mantel leg (if installed) and the fireplace. Refer to Fig- ures 5a and 5b for correct mounting heights and widths for combustible mantels and mantel legs.
  • Page 7: Framing

    UVS33/36 Vent-Free Heaters 3. Frame in heater with a header across the top. It is Insulation important to allow for finished face when setting the depth of the frame. Insulation meth- 4. Attach heater to frame using adjustable frame drywall ods shown are strips (located behind access door for shipping).
  • Page 8: Gas Inlet And Manifold Pressures

    UVS33/36 Vent-Free Heaters Gas Line Connection UVS33 / UVS36 Certified To If gas piping from the source to the heater location has not been accomplished, install the required pipe. Con- ANSI Z 21.11.2a-2003 sult local codes to assure proper pipe size. Unvented Room Heaters The gas pipeline can be brought in through the right or left side of the heater, as well as the bottom.
  • Page 9: Hard (Direct) Wire Hook-Up

    UVS33/36 Vent-Free Heaters NOTE: 110/120 electric power is required to operate EB1 (Receptacle) Hook-Up: blower (fan). 1. Remove 2" knockout. Slide the electrical box back Be sure to leave sufficient excess wire in case minor plate into the back and bottom lances (clips) while adjustments are required.
  • Page 10: Alternate Switch Location

    UVS33/36 Vent-Free Heaters Finishing Thermopile CAUTION: All joints between the finished wall and the heater surround (top and sides) may be sealed only with noncombustible material. Only noncombustible material can be applied as facing to the heater surround (the black painted face).
  • Page 11: Operating Instructions

    UVS33/36 Vent-Free Heaters Operating Instructions 6. Lift off the window frame as shown in Figure 15. Top Louvre (Grille) Removal 7. To reinstall window frame follow the above procedure To remove the top in reverse. (Fig. 16) louvre (grille) as- sembly, lift louvre up and then out.
  • Page 12: Ember Material Placement

    UVS33/36 Vent-Free Heaters Log Installation UVS36 1. Remove window frame. (See "Window Top Right Log Frame" section) (BE10) Rear Log 2. Remove logs from packaging. Top Left Log (BE8) (BE9) As with all plastic - these are not toys and should be kept away from children and infants.
  • Page 13: Flame Characteristics

    UVS33/36 Vent-Free Heaters Turn counterclockwise Turn clockwise to increase to lower flame height flame height HV102 Fig. 18 Flame adjustment on gas valve. LG118 Flame Characteristics 20,000 BTU's It is important to periodically perform a visual check of LG118 the pilot and burner flames. Compare them to Figures UVS33 log flames 12/20/99 djt 19 or 20.
  • Page 14: Lighting And Operating Instructions

    UVS33/36 Vent-Free Heaters Lighting and Operating Instructions FOR YOUR SAFETY READ BEFORE LIGHTING WARNING:If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This heater has a pilot which must be lit manu- •...
  • Page 15: Troubleshooting

    UVS33/36 Vent-Free Heaters Troubleshooting Honeywell START CHECK • Supply line hooked up • Gas Supply On • Shutoff valve open • Lockout has engaged. Wait 60 seconds and try again • For spark at electrode while Pilot Lights with depressing Piezo Piezo Ignitor 1/8"...
  • Page 16: Maintenance

    UVS33/36 Vent-Free Heaters Maintenance Burner and Burner Compartment To obtain proper operation, it is imperative that the pilot It is important to keep the burner and the burner and burner's flame characteristics are steady, not lifting compartment clean. At least once per year the logs and or floating.
  • Page 17 UVS33/36 Vent-Free Heaters 5a-f 13a/b 18a/b 2211 CFM Corporation reserves the right to make changes in design, materials, specifications, prices and discontinue colors and products at any time, without notice. 2211 UVS33/36 Vent Free Gas Room Heater uvs33 parts 12/20/99 djt Ref.
  • Page 18: Replacement Parts

    UVS33/36 Vent-Free Heaters UVS33/36 Vent Free Gas Room Heater (continued) Ref. Description UVS33 UVS36 Orifice Main Burner - LP (10,000) #62 20002250 See Rating Plate Fan w/Bracket (FK24) 54103 54103 Electrical Cord (6ft.) 51865 51865 Speed control Knob 51882 51882 speed Control 51738 51738...
  • Page 19: Optional Accessories

    UVS33/36 Vent-Free Heaters Optional Accessories 3. Locate the fan speed control unit. This can be fitted Fan Kits behind the lower louvre assembly or located FK12 Fan Kit remotely in a conveniently located wall mounted electrical box. Remote location of the This auxiliary fan system increases the efficiency of the speed control will require suitable extension of the circulation of the heating air.
  • Page 20: Decorative Frame Trims

    UVS33/36 Vent-Free Heaters Decorative Frame Trims A selection of decorative frame trim kits are available for mounting around the outside of the appliance to en- hance its visual effect on the room. Installation instruc- tions for each decorative frame trim are included with the frame trim kit.
  • Page 21: Decorative Bay Window

    UVS33/36 Vent-Free Heaters Decorative Bay Window Louvre Assem- bly Top Available for the UVS36 only. When fitting the Bay Window Kit, the original front frame/glass assembly MUST Window remain in place. The Bay Window Kit is fit- Frame ted over the existing front glass. Ceramic Ceramic Refractory...
  • Page 22 UVS33/36 Vent-Free Heaters 20002211...
  • Page 23: Warranty

    LIMITED LIFETIME WARRANTY UVS33/36 Vent-Free Heaters PRODUCT COVERED BY THIS WARRANTY All Vermont Castings gas stoves, gas inserts, and gas fireplaces, and all Majestic or Northern Flame brand gas fireplaces equipped with an Insta-Flame Ceramic Burner, or standard steel tube burner. BASIC WARRANTY •...
  • Page 24 CFM Corporation 2695 Meadowvale Blvd. • Mississauga, Ontario, Canada L5N 8A3 800-668-5323 • www.cfmcorp.com CFM Corporation ©...
