HP Elite 7200 - Microtower PC Manual

Illustrated Parts & Service Map
HP Elite 7200 Series Microtower PC
©
2010 Hewlett-Packard Development Company, L.P. The information contained
herein is subject to change without notice. HP shall not be liable for technical or edito-
rial errors or omissions contained herein.
Document Number 640041-001.
Key Specifications
Processor Type Intel® Core™ i3, Intel Core i5, Intel Core i7
Maximum RAM 16 GB; PC-3-10600 (1333MHz) DDR3 SDRAM
Expansion Slots •
•
Integrated Graphics Integrated Intel HD graphics
Chipset Intel H57 Express
Drive Support •
•
I/O Interfaces Front: (3) USB ports, 1394, microphone, headphone
Rear: (6) USB ports, (1) RJ-45, (1) 1394, (1) audio in, (1)
audio out, (1) microphone, (1) surround center, (1) surround
right, (1) surround left, (1) optical out, (1) VGA, (1) DVI
Operating Systems •
•
•
•
•

Spare Parts

System Unit
1 Access panel
2 Power supply, 300W, PFC
3 Front bezel
4 Chassis
* Not shown
HP Elite 7200 MT Series
1st Edition January 2011.
1 PCI x16
3 PCI x1
External: (2) 5.25-inch and (1) 3.5-inch drive bays
Internal: (2) 3.5-inch drive bays
Windows® 7
Windows XP Professional (downgrade from Windows 7)
Windows Vista® Business
Novell SUSE Linux Enterprise Desktop 11
FreeDOS
Cables
1 SATA HDD cable, 6.5 inch (16.5 cm)
2 SATA ODD cable, 9.5 inch (24 cm)
3 IDE to SATA adapter
4 Front I/O assembly
5 Power switch/LED cable assembly
* DMS-59 to dual DVI adapter
*Not shown
Keyboards (not illustrated)
USB, low cost
USB, low cost, blue
Arabic
Belgian
BHCSY
Bulgarian
Czech
Danish
Finnish
French
French Arabic
German
Greek
Hebrew
Hungarian
* 630886 only for -DH1 (Nordic)
Mass Storage Devices (not illustrated)
DVD±RW and CD-RW drive with LightScribe
DVD-ROM drive
BD Writer SuperMulti DL Drive with LightScribe
1.5 TB, 7200-RPM SATA hard drive
1.5 TB, 5400-RPM SATA hard drive
1 TB SATA hard drive
750 GB SATA hard drive
640 GB SATA hard drive
500 GB SATA hard drive
320 GB SATA hard drive
320 GB, 7200-RPM SATA hard drive, 3.6 Gb
250 GB, 7200-RPM SATA hard drive
160 GB, 7200-RPM SATA hard drive
250-GB hard drive, external USB
586372-001
592502-001
640951-001
not spared
640041-001
630886-DH1 (Nordic)*
537924-xxx
-171 International
-181 Italian
-B41 Norwegian
-261 Polish
-221 Portuguese
-081 Romanian
-351 Russian
-051 Slovakian
-DE1 Spanish
-041 Swedish
-151 Swiss
-BB1 Turkish
-211 U.K.
448670-001
614498-001
not spared
448667-001
614496-001
463024-001
-L31
-061
-091
-241
-131
-271
-251
-231
-071
-101
-111
-141
-031
506462-001
506464-001
534891-001
613209-001
613203-001
585465-001
632938-001
632939-001
586720-001
586969-001
636298-001
586719-001
586718-001
586383-001
500019-001
page 1
