QUICK START
Welcome to your new Smart TV!
The following instructions cover assembling, connecting, and setting up your new TV. Make
GUIDE
sure you have the accessories listed below.
Included in this box
Remote Control
Stand Parts and Cables
BN68-05028A-00
Cable manager
Stand Mount
Insert the
Power on and
Attach the TV to
Connect video
batteries into the
start the initial
the Stand
devices
remote control
setup
Step
Step
Step
Step
1
2
3
4
IR extender
Power cord
Remote Control
x 2
Warning: Screens can be damaged
Batteries (AAA x 2)
Wall mount adapter
(46 inch and above models)
from direct pressure when handled
incorrectly. We recommend lifting the
Also included:
TV by the edges, as shown.
User Manual, Regulatory Guide
Step 1
Attach the TV to the Stand
4
Lay the TV on a soft surface, screen side down.
Insert 4 screws and secure the stand to the
1
Use the packing material to protect the screen.
mount.
x4 (M4 X L12)
REQUIRED TOOLS: a Phillips head screwdriver and a soft, flat surface larger than the TV
5
Holding the stand parallel to the screen, slide
(such as the box).
the stand into the notches on the back of the
TV.
2
Put a base and screws off to assemble the stand
out of the box.
Screws
32 inch models: 7 pieces
1
2
3
40 inch and above models: 8 pieces
Base
Screws
6
Fit the stand and mount together, making sure
Insert 4 screws and secure the stand to the TV.
3
the notch on the mount aligns with the stand.
x3 (M4 X L12) 32"
x4 (M4 X L12) 39" ~ 55"
