1.3 Motherboard Layout

1
1
PS2 PS2_USB_PWR1
Mouse
PS2
Keyboard
COM1
USB 2.0
T: USB2
B: USB3
USB 2.0
Top:
T: USB0
RJ-45
B: USB1
31
USB 2.0
T: USB4 USB4_5
B: USB5
30
29
28
27
26
JL1
JR1
25
Audio
CODEC
24
2MB
BIOS
23
GAME1
1 PS2_USB_PWR1 Jumper
2 CPU Fan Connector (CPU_FAN1)
3 CPU Heatsink Retention Module
4 CPU Socket
5 North Bridge Controller
6 2 x 184-pin DDR DIMM Slots
(Dual Channel A: DDR1, DDR3; Blue)
7 ATX 12V Connector (ATX12V1)
8 Secondary IDE Connector (IDE2, Black)
9 Primary IDE Connector (IDE1, Blue)
10 2 x 184-pin DDR DIMM Slots
(Dual Channel B: DDR2, DDR4; Black)
11 AGP Slot (1.5V_AGP1)
12 Secondary Serial ATA Connector (SATA2)
13 Primary Serial ATA Connector (SATA1)
14 South Bridge Controller
15 Clear CMOS Jumper (CLRCMOS1)
2 3
21.8cm (8.6 in)
CPU_FAN1
CD1
AUX1
AUDIO1
1.5V_AGP1
LAN
PHY
PCI 1
PCI 2
USB2.0 FSB800
DDR400
PCI 3
5.1 CH
PCI 4
ATA133
PCI 5
P4V88+
IR1
1
22 21
4 5 6
AGP 8X
VIA
VT8237
CMOS
Battery
CLRCMOS1
FLOPPY1
SATA
CHA_FAN1
USB67
SPEAKER1
1
1
20 18
19
16 Floppy Connector (FLOPPY1)
17 System Panel Header (PANEL1)
18 Chassis Speaker Header (SPEAKER 1)
19 Chassis Fan Connector (CHA_FAN1)
20 USB 2.0 Header (USB67, Blue)
21 Infrared Module Header (IR1)
22 Game Connector (GAME1)
23 5 x PCI Slots (PCI1- 5)
24 Flash Memory
25 JL1 Jumper
26 JR1 Jumper
27 Front Panel Audio Header (AUDIO1)
28 Internal Audio Connector: AUX1 (White)
29 Internal Audio Connector: CD1 (Black)
30 Shared USB 2.0 Header (USB4_5, Blue)
31 ATX Power Connector (ATXPWR1)
7
IDE2
8
9
IDE1
10
11
SATA2
12
13
SATA1
14
15
16
PANEL 1
PLED PWRBTN
1
HDLED RESET
17
