Kyocera TASKalfa 820 Operation Manual

Printing system (w) operation guide (setup edition)
Hide thumbs Also See for TASKalfa 820:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Driver Manual, Operating Manual
Printing System (W)
Operation Guide
Set up Edition

Advertisement

Table of Contents
loading

Related Manuals for Kyocera TASKalfa 820

Summary of Contents for Kyocera TASKalfa 820

  • Page 1 Printing System (W) Operation Guide Set up Edition...

  • Page 3: Trademark Information

    Trademark Information • KPDL is a trademark of Kyocera Corporation. • Ethernet is a registered trademark of Xerox Corporation. • Novell and NetWare are registered trademarks of Novell, Inc. • Centronics is a trademark of Centronics Data Computer Corporation. •...

  • Page 4: Getting Connected

    Getting connected For local connection of this machine (direct connection between a computer and the printer through a parallel/USB cable) Page 4 Connect the computer and the printer through a parallel cable or a USB cable. Install the printer driver in the computer. (Refer to the On-Line Manual.) For network connection of this machine (connection of the printer through a network) <Example connection>...

  • Page 5: Table Of Contents

    Contents Preparations ....................... 1 Names of parts ..........................1 Main body ..........................1 Operation panel ........................2 Accessories ..........................3 Items to be prepared by user .......................3 Set-up ......................... 4 Connecting the printer cable ......................4 Connecting the network cable .....................5 Setting the network (TCP/IP) .......................6 Installing the software ........................10 Canceling printing ...................

  • Page 7: Preparations

    Preparations Names of parts Main body Memory card (CompactFlash) slot — Insert an optional memory card (CompactFlash) here. You can write optional fonts, macros, and forms into the memory card. For details, refer to The Functions Edition of the Operation Guide. USB interface connector —...

  • Page 8: Operation Panel

    Preparations Operation panel Mixed Size originals Ready to print. Printer Cancel Menu [Printer] key (indicator) — Press this key to light up when selecting the printer mode. Status indicator — Lights up or blinks to show the status of this machine. Lighting green: This machine is receiving data.

  • Page 9: Accessories

    Preparations Accessories • CD-ROM (Product Library) • Operation Guide Items to be prepared by user • For parallel connection of the printer: Parallel cable (based on IEEE1284, shorter than 1.5 m) • For USB connection of the printer: USB2.0 compatible cable (based on High-Speed USB, shorter than 5.0 m) •...

  • Page 10: Set-Up

    Set-up Connecting the printer cable When using this machine as a local printer, use a parallel cable or a USB cable as a printer cable to connect this machine to a computer. IMPORTANT:ALWAYS turn the main power switch of the machine OFF BEFORE connecting the printer cable.

  • Page 11: Connecting The Network Cable

    Set-up Turn the main power switch of this machine ON ( | ). For details on setting of each interface, refer to the Functions Edition. Connecting the network cable When using this machine as a network printer, use a network cable (10Base-T or 100Base-TX) to connect this machine to a network.

  • Page 12: Setting The Network (Tcp/Ip)

    Set-up Setting the network (TCP/IP) When using this machine as a network printer, you must set the IP address of this machine. NOTE: • The IP address that should be registered here will differ depending upon your environment. Check with your network administrator BEFORE performing this setting. •...
  • Page 13 Set-up Press [] or [] to select TCP/IP and Interface press [Change #]. Setting Item Value NetWare TCP/IP Ethertalk Network Status Page Change # Parallel Network Printer menu Press [On] located under TCP/IP. TCP/IP Back TCP/IP Setting Item Value DHCP BOOTP IP Address 0.
  • Page 14 Set-up Press [] or [] to select IP Address Back Close and press [Change #]. Setting Item Value DHCP BOOTP IP Address 0. 0. 0. 0 Subnet Mask 0. 0. 0. 0 Change # Gateway 0. 0. 0. 0 Interface - Network Use the numeric keys on the keypad to IP Address...

  • Page 15: Printer Mode

    Set-up Press [] or [] to select Gateway and Back Close press [Change #]. Setting Item Value DHCP BOOTP IP Address 10. 141. 110. 204 Subnet Mask 255. 255. 255. 0 Change # Gateway 0. 0. 0. 0 Interface - Network Set the address using the same Gateway Back...

  • Page 16: Installing The Software

    Canceling printing Installing the software Install the software such as printer driver according to your computer system. For the method of installation, refer to the Printer Driver User Guide. Canceling printing To cancel printing and clear the data, perform the following procedure. Press [Cancel].
  • Page 17 Canceling printing Printing is canceled. Canceling data. Off line Orig. Page Cancel User name: user1 Job name:...
  • Page 18 Canceling printing...
  • Page 20 First edition 2008. 11 Printed in Japan 303M156010...

This manual is also suitable for:

Taskalfa 620Printing system (w)
