CAUTION
Processor Switch Settings
The following table shows the settings for each of the Intel CPUs. To set the switches correctly, observe the
markings on the replacement CPU chip. Each CPU chip will have a speed marking ("180 MHz" or "200
MHz"), and a voltage marking ( "SL255" or "SL22V"). Use the table below to look up the appropriate switch
settings for each of these CPUs.
Voltage
CPU Speed Marking
180 MHz SL22V
200 MHz SL22V
200 MHz SL255

Exploded Views

1
16
15
Position 10 on the system board DIP switch package is to be changed only by a
Hewlett-Packard-authorized service provider. Setting this switch incorrectly could
result in damage to the processor chip, system board, or other components.
Damage due to incorrect switch settings is not covered by the HP warranty.
Switch 1 Switch 2
Closed
Open
Open
3
6
Switch 3
Open Open
Open Open
Open Open
8
7
13
Switch 4 Switch 5
Closed Open
Closed Open
Closed Open
9
10
11
12
Switch 10
Open
Open
Closed
45
