Chapter 4

Logical Drives, RAID Levels, and Array Spanning
On Worksheet B, logical drives are numbered LD0 through LD7. For each
logical drive you plan to create, record the following information:
Array number to which the logical drive is assigned
Whether the logical drive spans up to four sequentially-numbered arrays
RAID level
For each logical drive, you also need to define the logical drive size (capacity),
stripe size, write policy, read policy, and cache policy as defined in the sections
that follow.
40
Figure 4-4. Sample Worksheet B
Planning
