Electrolux EWG147540W User Manual

Fully integrated washing machine, with 7kg wash load. a+++ab energy rating and 1400rpm spin.
Hide thumbs Also See for EWG147540W:
Table of Contents

Advertisement

Quick Links

................................................ .............................................
EWG 147540 W
EN WASHING MACHINE
USER MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Electrolux EWG147540W

Summary of Contents for Electrolux EWG147540W

  • Page 1 ..................... EWG 147540 W EN WASHING MACHINE USER MANUAL...

  • Page 2: Table Of Contents

    2 electrolux Electrolux. Thinking of you. Share more of our thinking at www.electrolux.com CONTENTS Safety information Consumption values Safety instructions Care and cleaning Product description What to do if… Control panel Technical data First use Installation Personalisation Electrical connection Daily use...

  • Page 3: Safety Instructions

    3 • Do not change the specification of this appliance. • Obey the maximum load volume of 7 kg (refer to the “Pro- gramme chart” chapter). • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

  • Page 4: Product Description

    4 electrolux • The appliance is to be connected to the tact the Service to ensure which acces- water mains using the new supplied sories can be used. hose-sets. Old hose sets must not be CARE AND CLEANING reused. • Before you connect the appliance to new...

  • Page 5: Control Panel

    5 Drain pump Mains cable Front adjustable feet Water inlet valve Water drain hose Back adjustable feet DETERGENT DISPENSER DRAWER Compartment for detergent used for prewash and soak phase or for stain re- mover used during the stain action phase (if available).
  • Page 6 6 electrolux Programme selector dial machine will perform some additional rinses in some programmes. On cotton pro- TEMPERATURE button grammes the maximum spin speed is re- SPIN button duced automatically. EASY IRON button EXTRA RINSE EXTRA RINSE button This appliance is designed to save energy.
  • Page 7 7 DISPLAY 7.12 7.11 7.10 The display shows the following informa- with more water. When the programme has tion: finished, the display shows three blinking 7.1: Temperature value 0.00, the icon 7.10 is still visualized, the light of button 8 is off and the door is 7.2: Temperature icons...

  • Page 8: First Use

    8 electrolux If an option which is not compatible with 7.11: Washing programme phase icons the set wash programme is selected, the • Prewash message Err is displayed at the bottom • Wash of the display for a few seconds and the •...
  • Page 9 9 Open the door by carefully pulling the door handle outwards. Place the laundry in the drum, one item at a time, shaking them out as much as possible. Close the door. Make sure that no laundry stays between the seal and the door.
  • Page 10 10 electrolux REDUCE THE SPIN SPEED BY Cancelling the delayed start after having PRESSING BUTTON 3 pressed button 8: 1. Set the washing machine to PAUSE by By selecting a programme, the appliance pressing button 8. proposes automatically the maximum spin 2.
  • Page 11 11 by pressing the button 8 again. The wash- Washing cy- Soil Type of fabric ing water in the tub will be not emptied out. Level icon INTERRUPTING A PROGRAMME Quick Very slightly soiled Press the button 8 to interrupt a pro-...

  • Page 12: Helpful Hints And Tips

    12 electrolux 1. Turn the programme selector dial to door can be opened. Turn the programme selector dial to to switch the machine 2. Select the draining or spinning pro- off. gramme. Remove the laundry from the drum and 3. Reduce the spin speed if needed, by carefully check that the drum is empty.
  • Page 13 13 REMOVING STAINS The choice of detergent will depend on the type of fabric (delicates, woollens, cottons, Stubborn stains may not be removed by etc.), the colour, washing temperature and just water and detergent. It is therefore ad- degree of soiling.

  • Page 14: Washing Programmes

    14 electrolux WASHING PROGRAMMES Programme Maximum and Minimum Temperature Cycle Description Detergent Com- Options Maximum Spin Speed partment Maximum Fabrics Load Type of Laundry Cottons SPIN REDUCTION 90° - Cold RINSE HOLD Main wash - Rinses NO SPIN Maximum spin speed 1400 rpm...
  • Page 15 15 Programme Maximum and Minimum Temperature Cycle Description Detergent Com- Options Maximum Spin Speed partment Maximum Fabrics Load Type of Laundry Drain Draining of water Max. load 7 kg For emptying out the water of the last rinse in pro- grammes with the Rinse Hold or Night cycle option selected.

  • Page 16: Consumption Values

    16 electrolux Programme Maximum and Minimum Temperature Cycle Description Detergent Com- Options Maximum Spin Speed partment Maximum Fabrics Load Type of Laundry Cottons Eco + Prewash SPIN REDUCTION 90 °- 40° RINSE HOLD Prewash - Main wash - Rinses NO SPIN...

  • Page 17: Care And Cleaning

    17 Programmes Load Energy con- Water con- Approximate Remaining (kg) sumption sumption (li- programme moisture (kWh) tre) duration (mi- nutes) Standard cotton programmes Standard 60 °C 0.86 cotton Standard 60 °C 0.77 cotton Standard 40 °C 0.51 cotton 1) At the end of spin phase.
  • Page 18 18 electrolux 2. Run a washing cycle without any wash- ing to clean off any cleaning agent resi- dues. Programme: Short Cotton Programme at maximum temperature and add ap- prox. 1/4 measuring cup of detergent. DOOR SEAL Check from time to time the door seal and eliminate eventual possible objects that could be trapped in the fold.
  • Page 19 19 4. Release the emergency emptying hose 6. Remove foreign bodies and fluff from (B), place it in the container and re- the filter seat and from the pump impel- move its cap cover ler. Check carefully whether the pump im- peller rotates (it rotates jerkily).

  • Page 20: What To Do If

    20 electrolux Never remove the pump cover during a 1. Turn off the water tap. wash cycle, always wait until the appliance 2. Unscrew the inlet hose. has finished the cycle, and is empty. When 3. Place the end of the emergency empty-...
  • Page 21 21 Centre, please carry out the checks listed • : problem with the water supply. below. • : problem with the water draining. During machine operation it is possible that • : door open. the red pilot light of button 8 blinks, one of...
  • Page 22 22 electrolux Problem Possible cause/Solution Too much detergent or unsuitable detergent (creates too much foam) has been used. • Reduce the detergent quantity or use another one. Check whether there are any leaks from one of the inlet hose fit- tings.

  • Page 23: Technical Data

    23 If you are unable to identify or solve the problem, contact our service centre. Before telephoning, make a note of the model, se- Mod..rial number and purchase date of your ma- Prod. No..
  • Page 24 24 electrolux 3. Unscrew the three bolts. Any necessary adjustment can be made with a spanner. Accurate levelling prevents vibration, noise 4. Slide out the relevant plastic spacers. and displacement of the machine during operation. Caution! Never place cardboard, wood or similar materials under the machine to compensate for any unevenness in the floor.
  • Page 25 25 2. Connect the hose with the angled con- water tap off and refer to your Service Cen- nection to the machine. Do not place tre to replace the hose. the inlet hose downwards. Angle the hose to the left or right depending on the position of your water tap.
  • Page 26 26 electrolux Place the drain hose into your standpipe, an air break between the drain hose and which should have an internal diameter of standpipe. approximately 38 mm thus ensuring there is 38 mm (½”) standpipe diameter When discharging into a standpipe ensure than 90 cm (35.4'') and no less than 60 cm...
  • Page 27 27 Use the plastic “U - Piece” supplied. Loop 2. Onto a sink outlet spigot. If the outlet spigot has not been used be- fore, remove any blanking plug that may be in place. Important! Before connecting up the...

  • Page 28: Electrical Connection

    28 electrolux SHOWER SINK TOILET BATH BIDET WASHING MACHINE DISHWASHER RAINWATER ‘RUN-OFF’ FOUL DRAIN SURFACE WATER FOUL SEWERS DRAINS & SEWERS SEWAGE TREATMENT UNTREATED WORKS DISCHARGE TREATED DISCHRGE RIVER RIVER ELECTRICAL CONNECTION Information on the electrical connection is Warning! The appliance is supplied given on the rating plate on the inner edge with a 13amp plug fitted.

  • Page 29: Building In

    29 Should the appliance power supply The power supply cable must be cable need to be replaced, this easily accessible after installing the MUST be carried out by a Service machine. Centre. BUILDING IN OVERVIEW - thickness 16-22 mm...
  • Page 30 30 electrolux To align the door perfectly it is necessary to Fig. 7 loosen the screw, adjust the door and tight- en the screw A again (Fig. 5). Warning! Do not remove the screw B (Fig. 5). Fig. 5 Recommendations regarding the con-...

  • Page 31: Environment Concerns

    31 With the appliance installed adjust all four feet ensuring the machine is stable, and a clearance of approximately 5 mm is left be- tween the top of the machine and the un- derside of the worktop. A final check for stability should be carried...
  • Page 32 32 electrolux >PE<=polyethylene tergent, water and time (the environment >PS<=polystyrene is protected too!). >PP<=polypropylene • The machine works more economically if This means that they can be recycled by it is fully loaded. disposing of them properly in appropriate • With adequate pre-treatment, stains and collection containers.
  • Page 33 33...
  • Page 34 34 electrolux...
  • Page 35 35...
  • Page 36 132923531-A-092013...
