- Page 1 ..................... EWG 127410 W EN WASHING MACHINE USER MANUAL...
-
Page 2: Table Of Contents
2 electrolux Electrolux. Thinking of you. Share more of our thinking at www.electrolux.com CONTENTS Safety information Care and cleaning Product description What to do if... Control panel Technical data First use Consumption values Personalisation Installation Daily use Electrical connection Helpful hints and tips... -
Page 3: Installation & Use
3 INSTALLATION ing fluids are used, care should be taken to ensure that the fluid is removed from • This appliance is heavy. Care should be the garment before placing in the ma- taken when moving it. chine. • When unpacking the appliance, check •... -
Page 4: Product Description
4 electrolux PRODUCT DESCRIPTION Your new appliance meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. Its new washing system allows to- tal use of detergent and reduces water consumption so saving energy. -
Page 5: Control Panel
5 CONTROL PANEL Below is a picture of the control panel. It shows the programme selector dial as well as the buttons, pilot light and the display. These are presented by relevant numbers on the following pages. Programme selector dial... -
Page 6: First Use
6 electrolux EXTRA RINSE DOOR LOCKED PILOT LIGHT This appliance is designed to save energy. The pilot light 9 illuminates when the pro- If it necessary to rinse the laundry using an gramme starts and indicates if the door can... -
Page 7: Daily Use
7 DAILY USE Load the laundry Open the door by carefully pulling the door handle outwards. Place the laundry in the drum, one item at a time, shaking them out as much as possible. Close the door. Make sure that no laundry stays between the seal and the door. - Page 8 8 electrolux SELECT THE TEMPERATURE BY 2. Select the delay start by pressing the PRESSING BUTTON 2 button 6. 3. Press button 8: By selecting a programme, the appliance – the machine starts its hourly count- proposes automatically a default tempera- down.
- Page 9 9 need to open it, set first the machine to Soil Level Icon Type of fabric PAUSE by pressing the button 8. Daily For daily soiled After a few minutes the pilot light 9 goes items out and it is possible to open the door.
-
Page 10: Helpful Hints And Tips
10 electrolux Stand by : once the programme has finish- the display is reduced. By pressing any but- ed after a few minutes the energy saving ton the appliance will come out of the ener- system will be enabled. The brightness of gy saving status. -
Page 11: Washing Programmes
11 Your appliance incorporates a recirculation • you are washing a small load system which allows an optimal use of the • the laundry is lightly soiled concentrated detergent. • large amounts of foam form during wash- Follow the product manufacturer’s recom- ing. - Page 12 12 electrolux Programme - Maximum and Minimum Tempera- Detergent Com- ture - Cycle Description - Maximum Spin Speed - Options partment Maximum Fabrics Load - Type of Laundry Delicates SPIN REDUCTION 40° - Cold NIGHT CYCLE Main wash - Rinses...
-
Page 13: Care And Cleaning
13 Programme - Maximum and Minimum Tempera- Detergent Com- ture - Cycle Description - Maximum Spin Speed - Options partment Maximum Fabrics Load - Type of Laundry Wool SPIN REDUCTION 40° - Cold NIGHT CYCLE Main wash - Rinses... - Page 14 14 electrolux open after a wash will also help to preserve the door seal. MAINTENANCE WASH With the use of low temperature washes it is possible to get a build up of residues in- side the drum. We recommend that a maintenance wash be performed on a regular basis.
- Page 15 15 DRAIN PUMP 5. When no more water comes out, un- screw the pump cover (A) by turning it The pump should be inspected regularly anti-clockwise and remove the filter. and particularly if: Use pliers, if necessary. Always keep a •...
- Page 16 16 electrolux 8. Replace the filter into the pump by in- 6. Clean the filter in the valve with a stiff serting it correctly into the special brush or with the piece of cloth. guides. Screw the pump cover firmly by turning it clockwise.
-
Page 17: What To Do If
17 Important! Every time you drain the water and then run the drain programme. This will through the emergency emptying hose you activate the ECO Valve device avoiding must pour 2 litres of water into the main that part of the detergent remains unused wash compartment of the detergent drawer at next washing. - Page 18 18 electrolux Problem Possible cause/Solution The drain hose is squashed or kinked. • Check the drain hose connection. The drain filter is clogged. • Clean the drain filter. An option or a programme that ends with the water still in the tub or a that eliminates all the The machine does not empty and/or does spinning phases has been selected.
-
Page 19: Technical Data
19 Problem Possible cause/Solution The transit bolts and packing have not been re- moved. • Check the correct installation of the appli- ance. The support feet have not been adjusted The machine vibrates or is noisy: • Check the correct levelling of the appliance. -
Page 20: Consumption Values
20 electrolux Spin Speed Maximum 1200 rpm 1) Connect the water inlet hose to a water tap with a 3/4'' thread. CONSUMPTION VALUES The data of this table are approximate. Different causes can change the data: the quantity and type of laundry, the water and ambient temperature. - Page 21 21 2. Remove the power supply cable and 5. Fill the smaller upper hole and the two the draining hose from the hose holders large ones with the corresponding plas- on the rear of the appliance. tic plug caps supplied in the bag con- taining the instruction booklet.
- Page 22 22 electrolux 4. Connect the hose to a tap with a 3/4” thread. Always use the hose supplied with the appliance. RAISING THE APPLIANCE Suspended wooden floors are particularly susceptible to vibration. To help prevent vibration we recommend you place a waterproof wood panel, at least...
- Page 23 23 Warning! Installation should 1. Into a drainage standpipe comply with local water authority Firstly form a hook in the end of the drain and building regulations’ hose using the “U” piece” supplied. requirements. The appliance must be connected to a cold water supply.
- Page 24 24 electrolux 3 pin The drain hose may be extended to a maxi- mum of 4 metres. An additional drain hose and joining piece is available from your local Service Force Centre. The joining piece must have an internal diameter of 18 mm.
- Page 25 25 that has not been used for some time, run off a reasonable amount of water to flush out any debris that may have collected in the pipes. IN THE INTEREST OF THE ENVIRONMENT The appliance should be connected to the...
-
Page 26: Electrical Connection
26 electrolux SHOWER SINK TOILET BATH BIDET WASHING MACHINE DISHWASHER RAINWATER ‘RUN-OFF’ FOUL DRAIN SURFACE WATER FOUL SEWERS DRAINS & SEWERS SEWAGE TREATMENT UNTREATED WORKS DISCHARGE TREATED DISCHRGE RIVER RIVER ELECTRICAL CONNECTION Information on the electrical connection is Warning! The appliance is supplied given on the rating plate on the inner edge with a 13amp plug fitted. -
Page 27: Environment Concerns
27 Should the appliance power supply The power supply cable must be cable need to be replaced, this easily accessible after installing the MUST be carried out by a Service machine. Centre. ENVIRONMENT CONCERNS >PP<=polypropylene The symbol on the product or on its... - Page 28 28 electrolux Fig. 2 Fig. 4 c) Mounting the door Fix the hinges to the appliance by means of the M5x15 screws. The hinges can be ad- a) Door justed to compensate for possible uneven The dimensions of the door should be: thickness of the door.
- Page 29 29 Fig. 6 5 mm Hardwood strip Additional pieces of timber should run from front to back Front view Drill four fixing holes (see Fig. 9). If the door has to be opened from left to right, invert the position of the plates E, the magnet D and the plate C.
- Page 30 30 electrolux With the appliance installed adjust all four A strip of beading approximately 605 mm feet ensuring the machine is stable, and a W, x 5 mm H, x 25 mm D must be screwed clearance of approximately 5 mm is left be-...
- Page 31 31...
