Replacing the mouse

To replace the mouse:
1. Remove any media (diskettes, CDs, or memory cards) from the drives,
shut down your operating system, and turn off all attached devices and the
computer.
2. Unplug all power cords from electrical outlets.
3. Locate the connector for the mouse. Refer to "Locating connectors on the
front of the computer" and "Locating connectors on the rear of the computer".
Note: Your mouse might be connected to the standard mouse connector
at the rear of the computer or to a USB connector
of the computer.
4. Disconnect the failing mouse cable from the computer.
5. Connect the new mouse cable to the connector.
6. Refer to the "Completing the installation."
