Contents: Sound Blaster Live! Value Sound Card User's Guide
Sound Blaster Live! Value Sound Card User's Guide
Safety Instructions
Introduction
Setup
Using the Sound Card
Software
Troubleshooting
Specifications
Internal Connectors
Regulatory
Information in this document is subject to change without notice.
© 1998-2000 Creative Technology Ltd. All rights reserved.
Trademarks used in this text: Sound Blaster and Blaster are registered trademarks, and the Sound Blaster Live! logo, the Sound Blaster PCI logo, EMU10K1, E-mu Environmental
Modeling, Environmental Audio, Creative Multi Speaker Surround, and DynaRAM are trademarks of Creative Technology Ltd. in the United States and/or other countries. E-Mu and
SoundFont are registered trademarks of E-mu Systems, Inc. Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Creative Technology Ltd. disclaims any
proprietary interest in trademarks and trade names other than its own.
This product is covered by one or more of the following U.S. patents:
4,506,579; 4,699,038; 4,987,600; 5,013,105; 5,072,645; 5,111,727; 5,144,676; 5,170,369; 5,248,845; 5,298,671; 5,303,309; 5,317,104; 5,342,990; 5,430,244; 5,524,074; 5,698,803;
5,698,807; 5,748,747; 5,763,800; 5,790,837.
Version 1.00
July 2000
