Lexmark™ W840

Clearing Jams

Guide

Avoiding jams

The following hints can help you avoid jams:
• Use only recommended print media.
• Do not overload the print media sources. Make
sure the stack height does not exceed the
maximum height indicated by the stack line on
the labels in the sources.
•
Do not load wrinkled, creased, damp, or curled
print media.
•
Flex, fan, and straighten print media before you
load it. If jams do occur with print media, try
feeding one sheet at a time through the
multipurpose feeder.
• Do not use print media that you have cut or
trimmed yourself.
• Do not mix print media sizes, weights, or types
in the same print media source.
•
Make sure the recommended print side is
loaded in the source according to your simplex
or duplex needs.
•
Keep print media stored in an acceptable
environment.
• Do not remove trays during a print job.
• Push all trays in firmly after loading them.
• Make sure the guides in the trays are properly
positioned for the size of print media you have
loaded. Make sure the guides are not placed
too tightly against the stack of print media.
Clearing Jams

Understanding jam messages

Message What to do
200, 201, and 202 Open the side door, and remove
Paper Jam
the jam.
Check Door A
203 Paper Jam
Open the side door and the
Check <Areas A/ Exit 2 door, and remove the jam.
E>
230 Paper Jam
Lower the duplex unit, and
Check Door <A,
remove the jam. Open the side
E, D> door and the Exit 2 door, and
remove the jam.
231 Paper Jam
Lower the duplex unit, and
Check <A, D>
remove the jam. Open the side
door, and remove the jam.
Clearing the
Open each tray, and remove any
2000-sheet high
jammed media.
capacity feeder
(Tray 5)
250 Paper Jam Remove all media from the
Check MP Feeder multipurpose feeder, flex and
stack the media, reload the
multipurpose feeder, and adjust
the guide.
28x Paper Jam
Open the finisher door, bridge
Check Finisher
unit assembly, or output bin,
then remove the jam.
200, 201, and 202 Paper Jam Check
Door A
1
Open Door A by pushing the release latch and
lowering the door.
CAUTION: The inside of the printer might be
hot.
2
Pull the print media up and toward you.
3
Close Door A.
4
Press .
203 Paper Jam Check <Areas A/E>
1
Open Door A by pushing the release latch and
lowering the door.
CAUTION:
The inside of the printer might be
hot.
2
Open Door E by pushing the release latch and
lowering the door.
