Hunter 28676 Parts Manual

Hardware
(Drawn to Scale)
x 1
x 2
x 4
x 2
x 3
x 4
x 1
x 4
x 15
Balancing
x 1
Kit
x 13
Wire
x 4
Connector
x 3
Low Profile
Washer
3" Wood Screw
Flat Washer
Hanger
Bracket
Assembly
1.5" Wood Screw
Screw, Low
Profile
Canopy Screw
Setscrew
Mouting Isolator
Blade Grommet Blade Grommet Blade
Assembly
Thumbscrew Thumbscrew
Switch
Housing
Screw, Switch
Assembly
Housing Assembly
Fan Parts
(Not Drawn to Scale)
PARTS GUIDE
PARTS GUIDE
Using this Parts Guide, make sure all Using this Parts Guide, make sure all
parts are included in the box. parts are included in the box.
If parts are missing, DO NOT RETURN If parts are missing, DO NOT RETURN
THIS ITEM TO THE STORE, call 888-830-1326 for assistance. THIS ITEM TO THE STORE, call 888-830-1326 for assistance.
THIS PARTS GUIDE IS FOR REFERENCE ONLY. THIS PARTS GUIDE IS FOR REFERENCE ONLY.
REFER TO THE INSTALLATION MANUAL FOR FULL ASSEMBLY INSTRUCTIONS. REFER TO THE INSTALLATION MANUAL FOR FULL ASSEMBLY INSTRUCTIONS.
Model # 28676

Parts List

Asm. Dwg. # G0820-01
Finish New Bronze
Item Name Qnty Part #
* Hanging System Kit 1 96759-30
Ceiling Plate
Canopy
Canopy Trim Ring
Hanger Ball / Downrod Assembly
Setscrew
Low Profile Washer
Canopy Screw
Wood Screw 1.5"
Wood Screw 3"
Flat Washer
Mounting Isolator
Screw, Low Profile
Switch Housing Assembly 1 99330-30
Blade Set 1 G0761-03
Blade Iron Set 1 G0821-10
Hardware Kit 1 G0820-00-860
Wire Connector
Screw, Switch Housing Assembly
Pull Chain Pendant 1 G0090-01
Pull Chain Pendant 1 G0091-01
Pull Chain 2 63756-41
Globe/Shade 4 77770-05
Thumbscrew 13 03077-07
Light bulb / Bulb 4 77646-03
Balancing Kit 1 65666-01
